- Page 1 Residential Steambath Generator Systems Installation, Operation & Maintenance Manual aquabrass.com...
-
Page 2: Table Of Contents
Residential Steambath Generator Systems Table of contents Aquasteam S elect Your Model ....2 B efore Installing ......3 S team R oom Guidelines . - Page 3 Aquasteam M A D E I N U S A ANSI reserves the right to make changes at any time without notice. LIS T E D S T E AM B ATH GENER ATOR 777D aquabrass.com...
-
Page 4: S Elect Your Aquasteam Model
Note: To convert cubic feet ot cubic meters, divide cubic feet by 35.3. E xample: Total cubic feet required is 155. Divide by 35.3 to obtain 4.39 m3. S elect model ABSC02787 aquabrass.com... -
Page 5: Before Installing
REDUCE THE RISK OF SLIPPING AND FALL INJURY 1. USE CARE WHEN ENTERING OR EXITING THE STEAM ROOM. FLOOR MAY BE SLIPPERY. NOTE: FOR ADDITIONAL SAFETY CONSIDERATIONS SEE OWNER’S MANUAL 100378HDCA 6.4/08 aquabrass.com... -
Page 6: Locating The S Team Generator Unit
IMPORTANT: See pg. 5 & pg.11 for steam head and temperature sensor location information. Steam Generator Field Valve is installed shown open steam supply pipe Steam Head Provideunions asrequired to facilitate (shown with available acrylic shield) installtion and disconnect of piping aquabrass.com... -
Page 7: Installation
Where permitted by local codes, provide an outlet plumbing connection for safety valve. warning To insure proper and automatic safety valve operation: DO NOT connect a shut offvalve or a plug at safety valve outlet. DO NOT connect a shut offvalve in steam supply pipe. aquabrass.com... -
Page 8: Generator Dimensions
14-1/2 (368) (432) __________________________________ 2-1/2 (64) 2-3/8 (60) __________________________________ 6-3/8 (162) 6-3/8 (162) caution M=Optional automatic drain valve system Notes: TO AVOID EQUIPMENT DAMGE DO NOT CONNECT POWER SUPPLY DIRECTLY TO HEATING ELEMENTS !!! For illustrative purposes only. Note: aquabrass.com... -
Page 9: Electrical Specifications
GREEN PURPLE FUSES PURPLE caution GROUND TO PROBE WHITE TO AVOID EQUIPMENT DAMAGE DO NOT LIGHT CONNECT POWER SUPPLY DIRECTLY TO BLUE CONTACTOR HEATING ELEMENTS !!! WHITE GRAY Automatic Drain (optional) WATER FEED CONTROL BOARD SOLENOID HEATING VALVE ELEMENT aquabrass.com... -
Page 10: Field Power Wiring
Check local codes. The unit will refill automatically when the control is activated again. In areas of hard water, a A q u a s t e a m automatic drain valve system is recommended for generator longevity. aquabrass.com... -
Page 11: Optional Automatic Drain System
Do not drain into a steam enclosure or any location where accidental contact with drain water may occur. In the event of a power failure the automatic drain valve will open and discharge hot water. (continued on next page) aquabrass.com... -
Page 12: Installing The R Emote Temperature Probe
4-5 Feet architect or contractor for steam (1.2-1.5 m) room construction details. Steam Head n c h e s 6 - 1 2 I c m ) ( 1 5 - 3 0 Relation of Temperature Probe to Steamhead aquabrass.com... - Page 13 Failure to do so may interfere with the ability to sense temperature and may result in excessive steam room temperatures. Diagram 4 1 ⁄2" (13 mm) Silicone Sealant minimum 3 ⁄4" (90 mm) maximum Cable Wall INSTALLED REMOTE SECTIONAL VIEW TEMPERATURE PROBE aquabrass.com...
-
Page 14: Installing The Aquasteam In-S Hower Control
The holder plate may be used to secure the control if the back of the wall can be accessed. Wall Step 7 Hold the control and press the control against the wall until the adhesive sticks and holds firmly as shown. aquabrass.com... - Page 15 Residential Steambath Generator Systems Connection of Aquasteam Control & TemperatureSensor Temp Probe Main Control Valve should be closed when Note: automatic drain is not installed aquabrass.com...
-
Page 16: Operation Of In-S Hower Control
Do not route the control or temperature sensor wiring inside conduit together with power lines or close to hot water or steam piping. Doing so may result in an inoperative or hazardous installation. Do not alter or modify the control. Doing so may result in an inoperative or hazardous installation. aquabrass.com... -
Page 17: R Eplacement Parts Diagram & List
ABSC02789 (9KW) ABSP02773 ABSC02782 (12KW) ABSP02774 _____________________________________ Liquid Level Circuit B oard ABSP02796 _____________________________________ Transformer ABSP02779 _____________________________________ Water Feed Solenoid ABSP02778 _____________________________________ Contactor ABSC02787 ABSP02775 ABSC02789 ABSP02775 ABSC02782 ABSP02777 _____________________________________ Automatic Drain ABDR02771 _____________________________________ Acrylic S hield ABSP02776 _____________________________________ aquabrass.com... -
Page 18: Warranty
warranty Residential Steambath Limited Lifetime Warranty THIS WARRANTY DOES NOT APPLY TO AQUASTEAM PROD- aquasteam extends to the original consumer purchaser of a UCTS WHICH ARE USED FOR ANY NON-RESIDENTIAL OR aquasteam. RESIDENTIAL STEAMBATH GENERATOR COMMERCIAL PURPOSE. THE FOREGOING IS IN LIEU OF ALL (aquasteam Generator), installed in the United States or EXPRESS OR IMPLIED WARRANTIES AND AQUASTEAM DOES Canada (excluding controls and accessories), a warranty that... - Page 20 aquabrass.com...
