- Page 1 INSTRUCTION MANUAL Cordless Grass Shear / Cordless Hedge Trimmer UM600D / UH201D Read before use.
-
Page 2: Specifications
SPECIFICATIONS UM600D with shear blade for grass shear installed Model: UM600D Cutting width 160 mm Strokes per minute 2,500 min Dimensions 347 mm x 177 mm x 131 mm (L x W x H) Rated voltage D.C. 10.8 V - 12 V max Net weight 1.3 - 1.5 kg UH201D with shear blade for hedge trimmer installed... -
Page 3: Safety Warnings
Noise Vibration The typical A-weighted noise level determined accord- The vibration total value (tri-axial vector sum) deter- ing to EN50636-2-94: mined according to EN50636-2-94: UM600D/UH201D with shear blade for grass shear UM600D/UH201D with shear blade for grass shear installed installed Sound pressure level (L ) : 75 dB(A) Vibration emission (a ) : 2.5 m/s or less... - Page 4 Keep children and bystanders away while Power tool use and care operating a power tool. Distractions can cause Do not force the power tool. Use the correct you to lose control. power tool for your application. The correct power tool will do the job better and safer at the Electrical Safety rate for which it was designed. Power tool plugs must match the outlet.
- Page 5 Method of operation Cordless Grass Shear Safety Warnings Only use the equipment in good light and visibility. During the winter season beware General instructions of slippery or wet areas, ice and snow (risk To ensure correct operation, user has to read of slipping).
- Page 6 When not in use, store the equipment indoors in 13. Hold the tool firmly when using the tool. dry and high or locked-up place - out of the reach of 14. Do not operate the tool at no-load children. Clean and maintain before storage. unnecessarily.
-
Page 7: Functional Description
Makita. Installing the batteries to non-compliant products may result in a fire, exces- sive heat, explosion, or leak of electrolyte. SAVE THESE INSTRUCTIONS. CAUTION: Only use genuine Makita batteries. Use of non-genuine Makita batteries, or batteries that have been altered, may result in the battery bursting causing fires, personal injury and damage. It will also void the Makita warranty for the Makita tool and charger. ► 1 . Red indicator 2. Button 3. Battery cartridge 7 ENGLISH... -
Page 8: Overload Protection
Never use the tool if it starts when you pull the switch trigger without pressing the lock-off button. Ask your local Makita Service Center for repairs. WARNING: Never disable the lock function or tape down the lock-off button. -
Page 9: Indicator Lamp
The shearing height can be set to three levels (15 mm, Indicator lamp 20 mm, and 25 mm) by changing the fixed position of the grass receiver. The shearing height without the The indicator lamp blinks or lights up when the remain- grass receiver is about 10 mm. ing battery capacity is low or empty. The indicator lamp Slide the grass receiver toward the front of the also lights up when the tool becomes overloaded. - Page 10 NOTICE: If the parts other than the shear blades such as the crank are worn out, ask Makita Authorized Service Centers for parts replacement or repairs. ► 1 . Grass receiver...
- Page 11 Removing the shear blades Installing the shear blades Remove the grass receiver and place the tool Prepare the crank, undercover, and new shear upside down. blades. ► 1 . Crank 2. Undercover 3. Shear blades While pressing the lock lever, turn the undercover counterclockwise until on the undercover is aligned Remove the blade cover from the old shear...
- Page 12 Apply a small amount of grease to the periphery Place the undercover so that on the under- of the crank. Attach the crank to the pins with the small cover is aligned with on the lock lever. and large rounds facing up. While pressing the undercover, turn the under- cover clockwise until on the undercover is aligned ► 1 .
- Page 13 Attach the blade cover before removing or installing the shear blades. NOTICE: If the parts other than the shear blades such as the crank are worn out, ask Makita Authorized Service Centers for parts replacement or repairs. Removing the shear blades Place the tool upside down.
- Page 14 Installing the shear blades Apply a small amount of grease to the periphery of the crank. Attach the crank to the pins with the small Prepare the crank, undercover, and new shear and large rounds facing down. blades. ► 1 . Crank ► 1 . Crank 2. Undercover 3. Shear blades Slide the shear blades so that the hole on the Attach the blade cover to the shear blades.
- Page 15 Tighten the two screws firmly with a screwdriver. 10. Make sure that the lock lever fits in the groove on the undercover. ► 1 . Screws ► 1 . Lock lever Place the undercover so that on the under- cover is aligned with on the lock lever. CAUTION: Never use the tool without install- ing the undercover. Remove the blade cover, and then turn on the tool to check that it works properly.
-
Page 16: Operation
Shearing (for grass shear) Turn the tool on after adjusting the shearing height and hold it so that the bottom of the tool rests on the ground. Gently move the tool forward. ► 1 . Levers NOTICE: Never try to remove the chip receiver by an excessive force with its hooks locked in the holes of the blades. - Page 17 NOTICE: NOTICE: Do not trim the wet grass or foliage of Do not cut down dead trees or similar small trees. hard objects. Doing so may damage the tool. NOTICE: Do not trim the grass or weeds while Cutting long lawn using the shear blades. The blades may become tangled in the grass or weeds. Do not try to cut long grass all at once. Instead, cut the lawn in steps. Leave a day or two between cuts until the Hold the tool with one hand, pull the switch trigger while...
-
Page 18: Blade Maintenance
Always be sure that the tool is switched off and the battery cartridge is removed before attempting to perform inspection or maintenance. To maintain product SAFETY and RELIABILITY, repairs, any other maintenance or adjustment should be performed by Makita Authorized or Factory Service Centers, always using Makita replacement parts. Cleaning the tool Clean the tool by wiping off dust with a dry cloth or one dipped in soapy water and wrung out. NOTICE: Never use gasoline, benzine, thinner, alcohol or the like. -
Page 19: Optional Accessories
OPTIONAL ACCESSORIES CAUTION: These accessories or attachments are recommended for use with your Makita tool specified in this manual. The use of any other accessories or attachments might present a risk of injury to persons. Only use accessory or attachment for its stated purpose. If you need any assistance for more details regard- ing these accessories, ask your local Makita Service Center. NOTICE: Do not wash the blades in water. Doing •... - Page 20 Makita Europe N.V. Jan-Baptist Vinkstraat 2, 3070 Kortenberg, Belgium Makita Corporation 3-11-8, Sumiyoshi-cho, Anjo, Aichi 446-8502 Japan 885549B225 www.makita.com 20190214...
