BAT-4
Quick Start Guide
This battery replacement kit is for the latest generation of NextCentury devices
(TR4, TR4-X, RR4, RR4-TR). We are proud to provide the highest quality
electronics with easy-to-replace batteries. Each battery in this kit will power a
NextCentury device for 7-12 years, and you can be automatically notified when
it's time to change the batteries in any of your NextCentury equipment.
Package Contents
CR18505
Battery
Battery Replacement Guide
Transceiver - Indoor (TR4)
Transceiver - Outdoor (TR4-X)
Remote Reader (RR4)
Leak Sensor (LS4)
Tip: If the device has been powered off for an extended amount of time, an updated
IMR (Initial Meter Read) can be entered using the NextCentury Mobile App.
Additional Resources
x 25
For full installation guide, spec sheets, and additional
resources, please visit:
products.nextcenturymeters.com/bat4
Contact Information
Phone: 844.538.8203 opt. 2
Email: support@nextcenturymeters.com
Grease Packet
Page 2
Page 3
Page 4
Page 5
x 2
Advertisement
Summary of Contents for NextCentury BAT-4
- Page 1 BAT-4 Quick Start Guide This battery replacement kit is for the latest generation of NextCentury devices (TR4, TR4-X, RR4, RR4-TR). We are proud to provide the highest quality electronics with easy-to-replace batteries. Each battery in this kit will power a NextCentury device for 7-12 years, and you can be automatically notified when...
- Page 2 BAT-4 Transceiver - Indoor The TR4 Transceiver connects to nearly every meter type and model, instantly adding full wireless smart meter functionality. 1) Press tab to open and remove the old battery. 2) Install the new battery by first attaching the new battery cable.
- Page 3 BAT-4 Transceiver - Outdoor TR4-X The TR4-X Transceiver for outdoor use, includes all the functionality of the TR4 an IP-68 waterproof design. 1) Insert removal tool (or large screwdriver) and rotate left until the cap comes loose. 2) Pull out old battery until wire connector is easily accessible.
- Page 4 BAT-4 Remote Reader The Remote Reader is an advanced meter solution with a high visibility remote display for one or two utility meters. 1) Pull down locking tab and remove Remote Reader from Model: RR3-TR NTEP: 20-012 the mounting plate.
-
Page 5: Leak Sensor
BAT-4 Leak Sensor The LS4 Leak Sensor alerts you of water leaking from appliances or water lines, preventing costly water damage repairs. 1) Press tab to open and remove Leak Sensor the old battery. 2) Install the new battery by first attaching the new battery cable. -
Page 6: Additional Resources
Updating IMR in your NCSS Mobile App After replacing the battery and resetting the device, the meter’s current read (IMR) can be entered on the NextCentury mobile app. This will ensure past usage will be 123 Gallons reflected accurately going forward.
