DISHWASHER
INSTRUCTION MANUAL
Models : WQP4-6204
Every appliance have passed the water test in
factory. It is normal if you found some water
leave in appliance. Please feel free to use it .
Please read this instruction carefully before
using and keep it safe.
This product complies with the standard:
EN 60355-1: 2012+A11+A13+A1+A2+A14
EN 60335-2-5: 2015+A11
Advertisement
Table of Contents
Related Manuals for Merax WQP4-6204
Summary of Contents for Merax WQP4-6204
- Page 1 DISHWASHER INSTRUCTION MANUAL Models : WQP4-6204 Every appliance have passed the water test in factory. It is normal if you found some water leave in appliance. Please feel free to use it . Please read this instruction carefully before using and keep it safe.
-
Page 2: Table Of Contents
CONTENTS Important Safety Instructions A- 01 Product Overview Pa rts of Di shwa sher B- 01 Technica l Inf orma ti on B- 02 Pa cka g e Li st B- 02 Installation Instructions Insta l l a ti on dia g ra m C - 01 Instal l a ti on steps C - 01... -
Page 3: Important Safety Instructions
Important Safety Instructions Warni ng There are some important safety instructions in this manual, Please read carefully before installing and using , This appliance is intended to be used in household and similar applications such as: – staff kitchen areas in shops, offices and other working environments; –... - Page 4 The specialized detergent should be put on the place where kids can not reach. because ● the detergents are contains acidoid and alkaline, which are really dangerous to kids. Utensils will be hot after washing, please take it out after 30 minutes. ●...
- Page 5 WARNING : When using your dishwasher, follow basic precautions, including the following: a) Read all instructions before using the dishwasher. b) Use the dishwasher only for its intended function. c) Use only detergents or wetting agents recommended for use in a dishwasher and keep them out of the reach of children.
-
Page 6: Product Overview
Product Overview Parts of D ishwa she r In terna l t op of di shwasher Water softener Lower spray arm D i shwa sher interi or Filter assembled Upper spray arm Basket Cutlery basket （Pictures for reference only, The actual product shall govern.） B- 01... - Page 7 Te chnica l Inf o rm ation Capacity 3 Place settings Waterproof IPX1 Nominal voltage 220-240V 850W Frequency 50Hz Rated power Water pressure 0.4-10 bar Inlet Water temperature Limited Outline size W440 X D413 X H424mm Implementation EN 60355-1: 2012+A11+A13+A1+A2+A14 EN 60335-2-5: 2015+A11 standards *Due to the continuous improvement of products, such as the technical parameters...
-
Page 8: Installation Instructions
Installation Instructions Insta llation dia g ram Running water inlet This is the default installation mode. It is recommended that this mode be selected for installation in good installation conditions. Refer to Steps installation. NOTICE:When the first time that water in ,the water in appliance turns yellow which is normal;... - Page 9 Installation of drain pipe Drain pipe connector Clamping band Drain pipe 1.Connect the drain and drain 2.The drain pipe should 3.Please put the free end port be fixed by the clamping of the drain pipe into the band sink or sewer. Notes：...
- Page 10 Water ta nk Installa tio n suction pipe connector Turncap Water tank Suction pipe water tank suction pipe connector Insert the water tank After the water tank After the water tank suction suction pipe into the is placed horizontally pipe connector is buckled to water inlet of the water on the table top, lift the water suction pipe...
-
Page 11: Operating Instructions
Operating Instructions C ontrol pa nel instructio n Lock Program Start/Pause Power Delay start Button Indica tor la mps Button : Display“Check Water Supply” : Salt refill indicator : Water tank full indicator : Child Lock Light Operate the dishwasher Close the door of the Change wash programme with dishwasher and start the... - Page 12 Ove rview of pro g ramm es Special dishwasher detergent will remove oil and food residues. It is a must every time you use the appliance. Detergent dosage depends on the amount of and type of soiling. Consumption of detergent Wash Type of soiling Programme...
- Page 13 Water sof tener Water softener is used to soften water, reduce limescale and ensure utensils as bright as new. It is especially suitable for areas with higher water hardness. Adding tips: close open 1.Turn anticlockwise and lift up water softener lid. 2.Fill it up with salt(approx.400-500g).
- Page 14 Utensils selectio n Dishwasher-proof utensils: Ceramic tableware Glassware Stainless steel tableware Utensils notes： 1. Precious metal, aluminium and colored glaze utensils may turn cloudy after being washed in a dishwasher. 2. Cutlery made of bamboo or wood: It may come loose orcrack at high temperatures. 3.
- Page 15 Loa ding the ba sk et Melamine Dessert Plate Dessert Plate Melamine Bowl Soup plate Glass Serving Spoon Saucer Dessert Bowl Tea Spoon Soup Spoon Dessert Spoon Knife Fork D - 05...
-
Page 16: Maintenance And Cleaning
Maintenance and Cleaning Clean the filter assembly After appliance ran a while, there will be some residue and other things left in it. Please clean it when you see the residue and things, also clean the appliance immediately. Make sure the power Use flowing water to flush filter is off. -
Page 17: E Rror Code List
Service Information E rror code list Error code Cause Remedy Thermistor short circuit Please contact the after-sales service department Thermistor open circuit Please contact the after-sales service department 1. Please make sure the utensils be placed correctly. Water will The machine is not be lack if it is in the plate/bow. - Page 18 Problem Cause Remedy 1.If all the lights were off and no reflection when you press the button, there are Please plug the power in and make sure possibilities that you didn't plug in the the power have no issue. power or the power was blackout. No reflection after turn Clean plug the power in and make sure 2.power or the power was blackout...
-
Page 19: Ci Rcuit Dia G Ram
Ci rcuit dia g ram cont rol EG N D EG N D AC N AC N C N 1 9 Floodcock K-YL White AC N Flowmeter AC L AC L D oor DOOR Thermistor Heat Thermistor Heat FUSE Water tank EV- Z1 Salt senser switch K - Y AN... -
Page 20: Af Ter Sal Es Servi Ce
Af ter sal es servi ce Warranty requirements *Provide valid vouchers for purchasing products during the warranty period： Invoice or product SN code. *Free warranty within 24 months based on the date of SN code of the product leaving the factory. *The following conditions do not fall within the scope of free maintenance during the warranty period, ：... - Page 21 The presence of this logo on the product means that the disposal of the device is governed by directive 2012/19/EU dated July 4, 2012 on waste electrical and electronic equipment(WEEE). Any hazardous substance contained in electrical or electronic equipment can have a potential impact on the environment and health during its recycling.
- Page 22 There is no retroactive effect on the sold product. Merax is a trademark of Decobus Handel GmbH used under license by Blitz Distribution GmbH. This product is imported by Decobus Handel GmbH...
