- Page 1 CALEDON & VICTORIA MANUAL THANKS FOR YOUR CHOOSING SLANE EBIKE! PLEASE READ THE MANUAL BEFORE YOU ASSEMBLE & RIDE YOUR EBIKE SLANE EBIKE LTD. www.ebikeslane.ca...
- Page 2 PRECAUTIONS: Obey the local traffic regulation. Never drive too fast to exceed the limited speed(32km/h) Avoid frequently braking and starting and check tire pressure before riding. please charge the battery after riding. If you do not ride for a long time, please ...
-
Page 4: Specification
SPECIFICATION: Model Caledon Victoria Frame Alloy Steel Motor rated power (W) Motor rated voltage (V) Max Speed (Km/h) Range (Km) 30 - 45 30 - 40 Load capacity (LB) Front brake Disk brake Disk brake Rear brake V brake V brake... -
Page 5: Install The Front Wheel
Make sure the minimum insertion mark is hidden inside the steer tube Install the front wheel Insert the front wheel into the fork Make sure that the wheel is seated and centered in the fork, and the brake disc should be fitted in between the brake linings. -
Page 6: Adjustment Of Steering Wheel
Adjustment of steering wheel Inserted depth of vertical tube of wheel should be not lower than minimum depth (red Safety mark); safety mark must be inserted into below hexagonal nut. (See fig. 1) Stand in the front of wheel, clamp the front wheel by both legs and hold the handgrip with both hands to adjust the angle degree at between cross tube of handgrip and vehicle body. -
Page 7: Install Pedals
Install Pedals Check the sign on the pedal L: pedal for the R: pedal for the left pedal-arm right pedal-arm BASKET ASSEMBLY Remove the clips and screws from the box and use a screwdriver and an open-end wrench After completing the above steps,tighten the screws again with the tool Charging Before riding the electric bike for the first time, you must charge the batteries for 4-6 hours... - Page 8 Do not place the battery near heat objects or fire. Do not expose the charger near water. LED indicator of the charger: ：Charging ：Charged Green charging charged Duration of charging The red indication light of the charger means in charging . ...
-
Page 9: Remove The Battery
During charging, if there is bad smell or the charger is overheated, please stop charging immediately and send it back to the dealers. The battery can be charged on the bike or separately . Remove the Battery LOCKED Follow the steps below . - Page 10 Press the switch button for Turn “ON” the power switch of This mark is the battery battery capacity display, In power On ,Keep press the “ + ”for 2s , you will have the front light turned on , and press another 2s to turn off it .
- Page 11 Throttle Throttle is equipped on this electric bicycle. Throttle is operated by rotating the throttle toward the rider much like a motorcycle. The more you twist the throttle, the faster the motor system will propel the bicycle. Donot pedal during the throttle is in function. Gear Shifter &...
-
Page 12: Maintenance And Service
Saddle position Correct saddle adjusted position is an important factor to get the best performance and comfort from your E-Bike. If you find the saddle position is not comfortable, adjust it Up and down adjustment with the quick release . Parking attention: 1. -
Page 13: Problems And Solution
If you break a spoke on a ride, you need ride home much more slowly and carefully because the weakened wheel could break other spokes . Warning: A broken spoke seriously weakens the wheel and may cause it to wobble, striking the brakes or the frame. -
Page 14: Warranty Policy
WARRANTY POLICY : Parts Description Warranty Problem description Motor 1 Year Not working Controller 1 Year Functional failure Charger 1 year Functional failure Lithium-ion battery 1 Year Not working Handlebar, frame, front fork, steering column, rear flat fork 1 Year Broken Special Note: The warranty time above is based on the date of e-bike sold ;...
