Philips Perfect Care Elite GC9642 Service Manual
Hide thumbs
Also See for Perfect Care Elite GC9642:
- User manual (34 pages) ,
- Service manual (32 pages) ,
- Manual (22 pages)
Advertisement
Quick Links
Philips Consumer Lifestyle
Service Manual
Product information
Fast & powerful crease removal
• Soleplate: T-Ionic Glide
• OptimalTemp Technology
• Safe rest
• Silent Steam Technology
• Vertical steam
• Pressure: Up to 7.2 bar
• Variable steam settings
• Steam output control
• Steam tip
• Power: 2400 W
• Constant vertical steam
• Steam boost: 440 g
• Continuous steam output: 135 g/min
Easy to use
• Safe for all fabrics: Even for delicates like silks
• Water tank capacity: 1800 ml
• Filling and emptying water: Detachable water tank,
Extra large filling hole
• Refill any time
• Heat-up time: 2 min
• Ultra light and comfortable
• Safety auto off
• Storage solution: Carry lock
• Cord freedom (swivel): 180 degree cord freedom
• Low water alarm
• Cord storage: Cord storage compartment
Published by Philips Consumer Lifestyle
15/10
• Power cord length: 1.8 m
• Hose storage: hose storage compartment
• Hose length: 1.7 m
• Open handle
Sustainability
• ECO setting
• Energy saving: 50% energy reduction
• Warranty: 2 year(s)
Calc management
• Suitable for tap water
• Calc clean reminder
• Calc clean solution: Easy De-Calc Plus
Technical information
• Voltage
• Dimensions:
• Weight:
Printed in the Netherlands
Perfect Care Elite
: 220 - 240 V
Packaging
: 31 x 35 x 51 cm
Product
: 23.3 x 28.5 x 45.3 cm
Iron
: 0.8 kg
Iron + Base
: 5.1 kg
© Copyright reserved
GC9642
Subject to modification
Advertisement
Related Manuals for Philips Perfect Care Elite GC9642
Summary of Contents for Philips Perfect Care Elite GC9642
- Page 1 • Safety auto off • Storage solution: Carry lock • Cord freedom (swivel): 180 degree cord freedom • Low water alarm • Cord storage: Cord storage compartment Published by Philips Consumer Lifestyle Printed in the Netherlands © Copyright reserved Subject to modification 15/10...
- Page 2 Disassembly advice Iron & Lock assy GC9642 INLAY & LIGHT STRIP 1 FRONT LOCK SLIDER SPRING 16H MICROSWITCH & REFLECTOR ASSY 2 FRONT LOCK CATCH SPRING 16G Remove Screw J1 - J5 TRIGGER SPRING 4 Remove Tray TRIGGER 5 Remove FRONT LOCK SLIDER SPRING 16H Remove Lock assy...
- Page 3 Disassembly advice Stand GC9642 WATER TANK ASSY 15 SAFETY CAP 38B TRAY RUBBER CAP 17 SAFETY VALVE 38A BUNG 51 E-VALVE 37 STAND TOP 19 RINSE CAP ASSY 42 RETURN TUBE 29 SPACER TOP 46 Remove WATER TANK ASSY 15 SPACER BOTTOM 47 Remove TRAY RUBBER CAP 17...
- Page 4 Service parts lists Iron & Stand GC9642 Service code Description Service code Description 4239 021 88451 Inlay & Light strip 4239 021 88631 Water tank assy 4239 026 61311 Refl ector assy 4239 014 55091 Front lock catch spring 4239 021 87002 LED wire assy 4239 014 55011 Front lock slider spring...
- Page 5 Exploded view Iron GC9642 5-13...
- Page 6 Exploded view Stand GC9642 Front lock bracket 6-13...
-
Page 7: Wiring Diagram
Wiring Diagram GC9642 1001 TEA1721AT/N1D 3001 9001 LIVE 8001 4001 47R/2W Drain Source Fusible WW 1.0mH/0.1A GF1M Flex L NOPOP 3045 2001 8002 100nF 1M,0.5W BZG03 275V (1206) C200 1,2,3 3003 2004 3002 2005 3004 2006 9002 18k,1% 10pF/50V 2k21,1% 100nF/50V 1.5,1% Jumper-18mm... -
Page 8: Repair Instructions
Repair instructions GC9642 • Due to the high wattage of the iron, only the specified cord set must be used. • Should damage be observed on the CORDSET 43, it must be replaced. Continued usage is not allowed. • If STAND BOTTOM ASSY 50 is provided without type plate information eg. Type number, voltage etc. When replacing the Stand Bottom Assy, engrave the type number &... - Page 9 Repair instructions GC9642 6.3. Enter Self Check Mode Process Flow Chart If fail to enter Self-Check mode, Start could be due to: No power to PCBA Buttons malfunction Press and hold Power Steam trigger malfunction & ECO buttons 4. Timing incorrect Refer to Trouble shooting tip #9 - trigger press is not detected Turn on mains power /...
- Page 10 Repair instructions 6.4 Perform Self-Check mode Process Flow Chart Power LED (blue) & Tank Empty LED (amber) slow Refer TS tip #2 blink alternately Turn On: • Pump for 2 sec Power LED (blue) & Tank Entered Display software • Buzzer Check zero-crossing Empty LED (amber) slow...
- Page 11 Repair instructions GC9642 6.5. Troubleshooting Tips TS tip #1 No pumping sound, fault could be on: Pump check by apply AC voltage directly Power PCBA check by driving a known good pump Connection check wire continuity No buzzer sound, fault should be on Power PCBA Iron LED does not light up as specified, fault could be on: Iron LED and hose cord wiring ...
- Page 12 Repair instructions GC9642 Lock assy disassembly advise Step 1: Use a screw driver to lift up the spring in the lock assy. Step 2: Remove the lifted spring. Step 3: Slide and lift up the lock assy. 12-13...
- Page 13 GC9642 History Record Added in Section 6 under Repair instruction on Aug Revised Section 6, added in Section 8 under Repair instruction on Oct 13-13...
