Summary of Contents for Restech PLT MOORING 150
-
Page 1: Front Page Mooring 150
® ® ® ® LINE THROWER USERS MANUAL MOORING 150 RESTECH NORWAY AS P.O.Box 624, N-8001 Bodø, Norway +47 7554 2440 +47 7554 2441 E-mail: restech@restech.no Web: www.restech.no... -
Page 2: Warnings
MUST ALWAYS BE TREATED AS A WEAPON AND MUST NOT BE POINTED AT PERSONS. ® THE PLT MUST NOT BE FIRED INDOORS. USE HEARING PROTECTIONS WHEN OPERATING ® THE PLT HAVE QUESTIONS, PLEASE CONTACT YOUR DEALER RESTECH NORWAY AS. Address on first page. -
Page 3: Table Of Contents
® ® ® ® LINE THROWER INDEX Front page Mooring 150 page 1 WARNINGS page 2 Index and Contents page 3 How to use Mooring 150 page 4-5 How to reload the line page 6 Base unit page 7-13 Description of the PLT system page 14 Pivot Support page 15-16... -
Page 4: How To Use Mooring 150
® ® ® ® LINE THROWER HOW TO USE MOORING 150 1. Screw the launching tube on to the base unit (fig 1,1). 2. Make sure that the line is well fastened to the loop on the projectile. 3.Turn the handle of the closing valve (fig 1.2). You will hear the air flow in to the accumulator. - Page 5 ® ® ® ® LINE THROWER Fig 1 Fig 2 Fig 3...
-
Page 6: How To Reload The Line
® ® ® ® LINE THROWER HOW TO RELOAD THE LINE IN TO THE LINEBOX 1. After using the rope, a few steps will ensure optimal function for next use- 2. Rinse the line in fresh water and allow it to dry. A wet or salty line will increase the weight of the line and decrease the shooting length. - Page 7 ® ® ® ® LINE THROWER USERS MANUAL BASE UNIT RESTECH NORWAY AS P.O.Box 624, N-8001 Bodø, Norway +47 7554 2440 +47 7554 2441 E-mail: restech@restech.no Web: www.restech.no...
- Page 8 The air cylinder must periodically, depending on national rules, be inspected and tested. If national rules are not applicable, the air cylinder must be approved every 5 year by licensed authorities, or by RESTECH Norway A/S. REFILLING THE AIR CYLINDER Depending on national rules, the air cylinder can be filled with 200 bars (3000 psi) or 300 bars (4350 psi) compressed air.
- Page 9 ® ® ® ® LINE THROWER TECHNICAL SPECIFICATIONS BASE UNIT WEIGHT / LENGTH, Base UNIT…... 7,5 Kg / 65 cm (16.5lb / 25.5 in) COLOUR ……………………………………………..…..Red and Blue MATERIALS ..….….….Anodised Aluminium and Stainless Steel ACCUMULATOR PRESSURE ....…..…...75 bars (1088 psi) AVERAGE MUZZLE VELOCITY....……..60m/s (200 ft/s) RECOIL, MAX ......………..…..……..5.300 N...
- Page 10 ® ® ® ® LINE THROWER...
- Page 11 - If the safety valve has blown, air leakage has emerged or other abnormal conditions are detected, please contact your dealer or RESTECH NORWAY AS. - The air cylinder should be undamaged and controlled within the period of validity according to national rules.
- Page 12 ® ® ® ® LINE THROWER Art no 1000 Art no 1017 Art no 1013 Art no 1306 Art no 1021 Art no 1307 Art no 1031 Art no 9002 Art no 1050 Art no 1054...
- Page 13 When ordering parts, please use part number and description. Complete parts are not split for sale due to safety reasons. Parts are available from your dealer or directly from Restech Norway A/S. Address on the front page. ® ® ® ®...
-
Page 14: Base Unit
® ® ® ® LINE THROWER ® DESCRIPTION OF THE PLT By opening the closing valve, air flows from the air cylinder through the reducing valve and into the accumulator of the base unit. The pressure in this chamber is 75 bars (1088 psi). -
Page 15: Pivot Support
® ® ® ® LINE THROWER PIVOT SUPPORT Fig 1 Fig 2 Due to the heavy recoil it is necessary to have a good ® ® support for the PLT . The back of the PLT can be used as support. - Page 16 ® ® ® ® LINE THROWER Figure 3 showing how the Pivot Support is mounted. The cover and air cylinder is removed. Pivot pins, Nylon Washers and 6mm Screws are included in the Pivot Support, art no.1502. The screws must be fastened by using thread glue as Loctite-270, or similar.
-
Page 17: Projectile Ranges
® ® ® ® LINE THROWER Picture showing present standard projectiles that can be used with ® the PLT linethrower. We also deliver special projectiles for special needs. For more information, please contact your dealer or RESTECH NORWAY AS. -
Page 18: Product Resgistration
We hope that you will find the time to answer these few questions which is found on our web site under product registration. Address of the web site www.restech.no On the web site you will also find latest news, user manuals, user videos and other useful stuff. By registering your mail address you will receive newsletter.
