Summary of Contents for smart acoustic SWM260
- Page 1 SWM260 WIRELESS MICROPHONE SYSTEM SWM360 WIRELESS MICROPHONE SYSTEM OPERATION MANUAL SWM260 / SWM360 WIRELESS MICROPHONE SYSTEMS...
-
Page 2: Table Of Contents
Contents System Components SWM260 Receiver Functions SWM360 Receiver Functions Receiver Display Functions Receiver Set Up SHM260 Handheld Transmitter SBP260 Bodypack Transmitter Channel Sync ASC Function Installation Racks Important Safety Instructions Troubleshooting Specifi cations... -
Page 3: System Components
System Components Page. 3 SWM260 SYSTEM SWM360 SYSTEM • SWM260 Receiver • SWM360 Receiver • • SHM260 Handheld Transmitter OR SHM260 Handheld Transmitter • • SBP260 Bodypack Transmitter SBP260 Bodypack Transmitter SWM260 WIRELESS MICROPHONE SYSTEM • • Headset Headset (SWM260BP model only) SHM260 •... -
Page 4: Swm260 Receiver Functions
AUTO menu button, for fast frequency sweep SET button, to set up all the functions shown on the LED screen 7. 8. UP and DOWN buttons for fast channel setting SWM260 Receiver Rear Connections DC power socket Antenna jack B XLR output socket Antenna jack A 1/4”... -
Page 5: Swm360 Receiver Functions
SWM260 WIRELESS MICROPHONE SYSTEM SWM360 Receiver Functions Page. 5 SWM360 WIRELESS MICROPHONE SYSTEM Power switch Infrared frequency “IR” window ASC button for infrared frequency sync; Press this key, the screen IR will flash for approximately 10 seconds in the microphone IR window... -
Page 6: Receiver Display Functions
Receiver Display Functions Page. 6 ASC sync indicator Transmitter power RF Transmitter microphone gain adjustment level Noise gate threshold Receiver RF Antenna Current group Current channel Receiver signal strength Audio Level... -
Page 7: Receiver Set Up
Receiver Set Up Page. 7 Frequency number and channel selection: Press “SET” button for two seconds to unlock “ ” and press the “SET”, “GR” flashing, press or to select the appropriate channel, as shown in Figure Then press “SET”, “CH” flashing, press or to select the appropriate channel, such as shown in Figure Then click “SET”, “SQL”... -
Page 8: Shm260 Handheld Transmitter
SHM260 Handheld Transmitter Page. 8 FUNCTIONS SHM260 Microphone capsule and grill LCD (liquid crystal) display Power Switch; Press and hold for 2 seconds to switch ON or OFF. SHM260 Press once to activate or disable the MUTE function. Infrared frequency (IR) port Battery cover CHANGING BATTERIES SHM260... - Page 9 Transmitter Display Function Page. 9 MUTE: Press Power Switch once to activate MUTE function. Mute symbol is displayed on screen. Press Power Switch again to disable MUTE function. Mute symbol will disappear SHM260 from screen. Transmitter intensity power display Battery power display Frequency of use SHM260 Mute symbol...
-
Page 10: Sbp260 Bodypack Transmitter
SBP260 Bodypack Transmitter Page. 10 FUNCTIONS Antenna Power Indicator Light LCD Screen Infrared frequency (IR) Window; Receives the infrared signal, the frequency synchronisation Press the "SET" switch, set by the LCD screen "UP" switch, press the "SET" switch, value is set by the liquid crystal screen display function / MUTE switch;... - Page 11 SBP260 Bodypack Transmitter Setting Page. 11 TRANSMITTER DISPLAY Power & Mute Activation: MUTE button to Power ON. Press and hold MUTE button to Power OF.F Press and hold Click MUTE to activate MUTE. MUTE again to cancel the mute function. Click Manually selecting a frequency or channel: Long press...
-
Page 12: Channel Sync Asc Function
Channel Sync via ASC Function Page. 12 Frequency setting: Press the button; will flash on the receiver screen. Hold the transmitter infrared window at the receiver infrared window. Automatic frequency Sync will be completed. disappears automatically. If the ASC Sync does not connect on the first attempt, please repeat sync steps or try an alternate channel. -
Page 13: Installation Racks
Page. 13 General rooms or close proximity can utilise the 1/4" connection function. For long distance connections, we suggest using a balanced XLR output function. Rack Panel Ears Power Adaptor 1/4" Audio Cable XLR Output connecting cable SWM260 WIRELESS MICROPHONE SYSTEM... -
Page 14: Important Safety Instructions
Important Safety Instructions Page. 14 • Please keep transmitter in direct line with the antenna, without any obstacles between them. • Please do not put the receiver near any metal surface or digital devices (such as mobile phone, computer, etc.) •... -
Page 15: Troubleshooting
Troubleshooting Page. 15 Problem Indicator Solution (lamp) state Transmitter Turn on the main power, confirm the +/ - power light off. mark on the battery and the transmitter terminal of the phase matching. Receiver power Confirm that the AC power adapter is indicator off. -
Page 16: Specifications
Audio Frequency Response (+/-3dB) Image Rejection 60Hz~15KHz >70dB THD (Total Harmonic Distortion) Size (+/- 30khz excursion, 1 khz audio): <1% 44mm* 212mm* 160mm (SWM260) 44mm* 410mm* 160mm (SWM360) Dynamic Range Weight >100dB (A weighted) 880g (SWM260) 1750g (SWM360) Working Range Power Requirements -1 0"C to +50"C...
