- Page 1 ThinkEdge SE70 User Guide...
- Page 2 “Equipment intended for Restricted Access Location” or equivalent. (instruction) First Edition (March 2022) © Copyright Lenovo 2022. LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant to a General Services Administration “GSA” contract, use, reproduction, or disclosure is subject to restrictions set forth in Contract No. GS-...
-
Page 3: Table Of Contents
Access networks ....Call Lenovo ....Connect to the wired Ethernet .. - Page 4 ThinkEdge SE70 User Guide...
-
Page 5: About This Guide
About this guide Thank you for choosing a Lenovo computer! We are dedicated to delivering the best solution to you. Before starting your tour, please read the following information: • This guide applies to Lenovo product model(s) listed below. Product name... - Page 6 ThinkEdge SE70 User Guide...
-
Page 7: Chapter 1. Meet Your Computer
Chapter 1. Meet your computer The new ThinkEdge SE70 provides enterprise-changing AI and computer vision applications that are constrained only by your imagination. With industry-leading engineering, reliability, and scalability, the ThinkEdge SE70 transforms existing camera infrastructure into intelligent automated environments ideal for every industry. - Page 8 System LED status The LEDs change color and blink to indicate status. A slow blink is once every three seconds. A fast blink is once per second. ThinkEdge SE70 - Powered by AWS Panorama LED status Indication The appliance is restoring to the previous software image and keeping all user Slow blinking orange data.
- Page 9 Used to connect to a CANbus enabled device or dongle. For more information about commands, see “Use the I/O tool guide (for ThinkEdge SE70)” on page 18. Note: Connections made to this connector must use the cable (26 AWG-18 AWG / 105°C).
- Page 10 Digital Input and Digital Output connector Used to connect an external modem, a serial printer, or other devices that use a serial connector. For more information about commands, see “Use the I/O tool guide (for ThinkEdge SE70)” on page 18. • Digital Input voltage: –...
- Page 11 Used only to enter Recovery Mode to flash operating system image and delete all user data. You need to enter Recovery Mode before restoring system image to factory image. For more operation information, see “Digital Download for Recovery Media (for ThinkEdge SE70)” on page 18. Chapter 1...
-
Page 12: Rear
Rear ThinkEdge SE70 - Powered by AWS Panorama Figure 3. Rear view 1. Ethernet connectors 1–2 (POE) 2. AC/DC power connector ( DC in 20 V) Connectors/holes with this icon are not available. ThinkEdge SE70 Figure 4. Rear view—1.6 L models (AC version) Figure 5. - Page 13 Connect an external modem, a serial printer, or other devices that use a serial connector. Its default setting is RS232. You can use commands to switch among RS232, RS422, and RS485. For more information about commands, see “Use the I/O tool guide (for ThinkEdge SE70)” on page 18. RS232 Pin definition mapping table...
- Page 14 The Ethernet port provides a standard RJ-45 jack connector with LED indicators on left and right side. LED status Indication The indicator is showing data transfer status. Blinking green on left side The indicator is showing successful POE device connection. Solid orange on right side ThinkEdge SE70 User Guide...
- Page 15 DC power connector (DC in 9-48 V)* Connect the power terminal to your computer for power supply. Notes: • Connections made to this connector must use the cable (24 AWG-14 AWG / 105°C). • Torque the screws at 0.4N.m. * for selected models Chapter 1 Meet your computer...
-
Page 16: Left
Left ThinkEdge SE70 - Powered by AWS Panorama Figure 7. Left view 1. Cable holder (for AC/DC power connector only) Connectors/holes with this icon are not available. ThinkEdge SE70 Figure 8. Left view 1. Cable holder (for AC/DC power connector only) 2. -
Page 17: Right
Right ThinkEdge SE70 - Powered by AWS Panorama Figure 9. Right view 1. Kensington Lock slot Connectors/holes with this icon are not available. ThinkEdge SE70 Figure 10. Right view 2. Kensington Lock slot 1. Wi-Fi antenna slot Wi-Fi antenna slot Used to install the right Wi-Fi antenna cable connector that is available only on some models. -
Page 18: Features And Specifications
The integrated graphics card supports the following: Video features • HDMI out connector • Micro SD card reader* Expansion • M.2 solid-state drive slot • Bluetooth* Network features • Ethernet LAN • Wireless LAN* * for selected models ThinkEdge SE70 User Guide... -
Page 19: Operating Environment
Operating environment Note: The operating environment is not applicable for hardware accessories. The operating temperature of various accessories depends on the corresponding accessory temperature specification. The operating environment for the industrial device must be: • Over Voltage Category II • Pollution degree 2 •... - Page 20 USB device Data rate (Gbit/s) Thunderbolt 3 (USB-C) Thunderbolt 4 (USB-C) ThinkEdge SE70 User Guide...
-
Page 21: Chapter 2. Get Started With Your Computer
Open System Settings and click Displays. Then, you can change display settings as you prefer. Get started with Ubuntu Desktop ThinkEdge SE70 - Powered by AWS Panorama AWS Panorama is a machine learning (ML) software development kit (SDK) that brings computer to on- premises internet protocol (IP) cameras. -
Page 22: Thinkedge Se70
• Press the Super key (with the Windows logo) and type in the name of the application you want to launch. • Open the Activities menu on the top left and click the Show Applications button at the bottom, and select the application you want to launch. ThinkEdge SE70 User Guide... -
Page 23: Access Networks
Launch settings Open the system menu from the top-right corner and click System Settings. Access networks This section helps you access networks through connecting to a wired or wireless network. Connect to the wired Ethernet Connect your computer to a local network through the Ethernet connector on your computer with an Ethernet cable. -
Page 24: Lock The Computer
Use the I/O tool guide (for ThinkEdge SE70) Lenovo provides a tool guide for your computer. You can use the tool guide to develop functions based on your needs. For example, you can collect signals and transfer data with sensors and relay modules... - Page 25 To use the tool guide, do either of the following: • Find the tool guide in the following directory: /opt/lenovo • Use the man se70_tool command and follow the instructions. Chapter 2...
- Page 26 ThinkEdge SE70 User Guide...
-
Page 27: Chapter 3. Cru Replacement
If you intend on installing the CRU, Lenovo will ship the CRU to you. CRU information and replacement instructions are shipped with your product and are available from Lenovo at any time upon request. You might be required to return the defective part that is replaced by the CRU. -
Page 28: Power Terminal
For access, do the following: 1. Remove any media from the drives and turn off all connected devices and the computer. 2. Disconnect all power cords from electrical outlets and disconnect all cables from the computer. Removal steps ThinkEdge SE70 User Guide... -
Page 29: Purchase Accessories
Purchase accessories Lenovo has a number of hardware accessories and upgrades to help expand the capabilities of your computer. Options include memory modules, storage devices, network cards, power adapters, keyboards, mice, and more. To shop at Lenovo, go to https://www.lenovo.com/accessories... - Page 30 ThinkEdge SE70 User Guide...
-
Page 31: Chapter 4. Troubleshooting
2. Use an antivirus program (if any) to see if the computer has been infected by a virus. If the program detects a virus, remove the virus. 3. If the problem persists, contact Lenovo. See Chapter 5 “Help and support” on page 29. Troubleshooting Use the troubleshooting information to find solutions to problems that have definite symptoms. -
Page 32: Audio Problems (For Selected Models)
3. Click on each device to enable and start pairing. • Update or reinstall the Bluetooth driver. Sound does not come from the Bluetooth Select the Bluetooth headset or headphones as the default audio headset or headphones. output device in advanced sound settings. ThinkEdge SE70 User Guide... -
Page 33: Performance Problems
Performance problems Problem Solution • Clean out your Inbox, Sent Items, and Deleted Items folders from your e-mail application. • Clean up your drive space. 1. Click the Search icon on the top left, and launch the Disk The free storage drive space is insufficient. Usage Analyzer application. -
Page 34: Software Problems
• Update the program. • Uninstall the program and then reinstall it. To download a program that is preinstalled on your computer, go to https:// and follow the on-screen instructions. pcsupport.lenovo.com ThinkEdge SE70 User Guide... -
Page 35: Chapter 5. Help And Support
• Setup Guide want. • This User Guide • Regulatory Notice Lenovo Support Web site with the latest support information of the following: • Drivers and software https://pcsupport.lenovo.com • Product and service warranty •... -
Page 36: Call Lenovo
Call Lenovo If you have tried to correct the problem yourself and still need help, you can call Lenovo Customer Support Center. Before you contact Lenovo Prepare the following before you contact Lenovo: 1. Record the problem symptoms and details: •... -
Page 37: Purchase Additional Services
• Installation and maintenance of network operating systems (NOS) • Installation and maintenance of programs For the terms and conditions of the Lenovo Limited Warranty that apply to your Lenovo hardware product, see Safety and Warranty Guide that comes with your computer. - Page 38 ThinkEdge SE70 User Guide...
-
Page 39: Appendix A. Supplemental Information About The Ubuntu Operating System
The LLW also is preinstalled on the computer. To access the LLW, go to the following directory: /opt/lenovo If you cannot view the LLW either from the Web site or from your computer, contact your local Lenovo office or reseller to obtain a printed version of the LLW. - Page 40 GNU General Public License and/or the Lesser General Public License for more information. To view additional information regarding licenses, acknowledgments and required copyright notices for the open source software shipped on your Device, go to /usr/share/doc/*/copyright. ThinkEdge SE70 User Guide...
-
Page 41: Appendix B. Compliance Information
Machine types for Powered by AWS Panorama ThinkEdge SE70 12A6, 12A7, 12A8, 12A9, 12AA, 12AB, 12AN, 12AQ, 12AE, 12AF, and 12AR 12AS, 12AT, 12AU, 12AV, 12AW, and 12BG The latest compliance information is available at: https://www.lenovo.com/us/en/compliance © Copyright Lenovo 2022... - Page 42 ThinkEdge SE70 User Guide...
-
Page 43: Appendix C. Notices And Trademarks
Lenovo representative for information on the products and services currently available in your area. Any reference to a Lenovo product, program, or service is not intended to state or imply that only that Lenovo product, program, or service may be used. Any functionally equivalent product, program, or service that does not infringe any Lenovo intellectual property right may be used instead. - Page 44 Actual results may vary. Users of this document should verify the applicable data for their specific environment. This document is copyrighted by Lenovo and is not covered by any open source license, including any Linux agreement(s) which may accompany software included with this product. Lenovo may update this document at any time without notice.
