Summary of Contents for actionair neo
- Page 1 Installation and Commissioning...
- Page 2 Control Installation Having taken this approach, we have however produced a dedicated online resource with information to assist you with NEO installation and commissioning. Here you will have access to mounting and wiring information and guided videos of Wiring Options NEO’s 5 step commissioning process.
- Page 3 Control Installation 100mm CTR Mounting Bracket Ø36mm Location • ENSURE that the wall controller is installed in a location that is within the range of Please note that there is applicable WiFi access point. The distance is dependent on router model and brand. a return lip on the rear Refer to your unit access point manual.
- Page 4 RJ45 Installation Hard Wired Installation Power Supply - (Yellow Cat5E spec cables with RJ45 connectors & cable boots) Power Supply - (Yellow Cat5E spec cables) 90m max cable length Controller 1 90m max Controller 1 (each) cable length (each) Indoor Board Controller 2 Indoor Board Controller 2...
- Page 5 Easy and intuitive step-by-step commissioning. SAFETY INFORMATION When you power on NEO for the first time you’ll be prompted with our guided step-by-step setup process, making • Only licensed HVAC technicians* should install and service this air conditioning controller. Improper service or alteration by commissioning as simple as a few touches of the wall controller.
- Page 6 Toughened glass front, ABS plastic back Casing colour Jet Black / Ceramic White Maximum zones 8 zones NEO Connect Mobile App Compatible with ActronAir model NTW-1000, NTB-1000 Platform iOS and Android iOS 9 or later – Android Version 6 Marshmallow or later...
- Page 7 Copyright © 2020 All rights reserved. No part or contents of this book may be reproduced or transmitted in any form or by any means without the written permission of Actron Engineering Pty. Ltd. ActronAir is constantly seeking ways to improve the design of its products, therefore specifications are subject to change without notice.
