Medion AKOYA E7212 Quick Reference

QSG E7212_M09L1 MD98160 EN RC1.FH11 Fri Nov 06 14:50:34 2009
Quick Reference
Open Notebook
Left Side
Right Side
Probedruck
Seite 1
C M Y CM MY CY CMY
1 - TFT Display
2 - Power ON/OFF
3 - Keyboard
4 - Device Indicators
5 - Touchpad Buttons
6 - Touchpad
7 - Palm Rest
8 - Stereo Speaker
9 - Webcam
10 - Microphone
Kensington ® Lock
11 -
12 - Power Socket
13 - LAN Port (RJ-45)
14 - Display Port (External Monitor Port)
15 - HDMI Connector
16 - eSATA / USB Port
17 - Express Card Slot 54
18 - Multimedia Card Reader
19 - Microphone*
20 - Audio Out*/
Digital Audio Out* (S/P-DIF, optical)
21 - Line In*
22 - USB Port
23 - Optical Drive
24 - Disc Eject Button
25 - Emergency Ejection
*Ports with dual function. Configuration is set with the included software.
