Dear Costumer,
It is our ultimate desire that you achieve the best performance from our product,
which has been passed through meticulous quality control checks and is
manufactured in modern facilities.
Pieces of packaging (plastic bags, polystyrene etc.) must not be left within reach
of children, as they are potentially dangerous. Please dispose of packaging
thoughtfully by the appropriate means.
To this effect, we recommend that you read the entire guide carefully before
operating the product and keep it as a reference.
THIS APPLIANCE SHALL BE INSTALLED IN ACCORDANCE WITH THE REGULATIONS IN
FORCE AND ONLY USED IN A WELL VENTILATED SPACE. READ THE INSTRUCTIONS
BEFORE INSTALLING OR USING THIS APPLIANCE'
INDEX
INSTALLATION OF YOUR COOKER
TECHNICAL FEATURES OF YOUR COOKER
IMPORTANT WARNINGS
DESCRIPTION OF COOKER & CONTROL PANELS
USING COOKER SECTION
MAINTENANCE and CLEANING
BUILT-IN TABLE HOB GAS COOKER
USER MANUAL
GB
ATTENTION!
CONTENTS
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Simfer H30E02M011
Summary of Contents for Simfer H30E02M011
- Page 1 BUILT-IN TABLE HOB GAS COOKER USER MANUAL Dear Costumer, It is our ultimate desire that you achieve the best performance from our product, which has been passed through meticulous quality control checks and is manufactured in modern facilities. Pieces of packaging (plastic bags, polystyrene etc.) must not be left within reach of children, as they are potentially dangerous.
- Page 2 INSTALLATION OF YOUR COOKER 1- This appliance must be installed by a competent person and with particular attention to air circulation. 2- The housing must be heat resistant to a temperature of 95 ° C as per EEC directives...
- Page 3 ELECTRICAL CONNECTION and SECURITY Your cooker requires a 13 or 16 Amp fuse. If necessary, installation by a qualified electrician is recommended. Your oven is adjusted in compliance with 230Volt AC, 50 Hz (for SA will be 220-240V,50-60 Hz), electrical supply, and requires a 16 Amp (for England 13 Amp) fuse.
- Page 4 BUILT IN BUILT-IN BUILT-IN TABLE TOP GLASS HOB BUILT-IN GLASS BUILT-IN BUILT-IN SPECIFICATIONS HOB 60 cm HOB 60 cm DOMINO 30 GLASS HOB GLASS HOB GLASS HOB 60 cm 90 cm 45 cm 580 mm 580 mm 520 mm 520 mm 520 mm 520 mm 440 mm...
- Page 5 1. The setup conditions is written on the sticker rating label and also you will find your product information about gas type (LPG or NG) 2. If the current rate of the fuse in your installation is less than 16 Amp, make a qualified electrician fit a 16 Amp fuse.
- Page 6 DESCRIPTION OF THE COOKER AND CONTROL PANEL Command Knobs 30 cm Domino Hobs 60 cm Grids Rapid Burner Glass Surface Auxiliary Burner Wok Burner Hob Body Hotplate (1000 W) Hotplate (1500 W) Indicator Semi-Rapid Burner Fish Burner Command Knobs Table top hobs 70 &...
- Page 7 Using Gas Burners : In order to obtain maximum output, be careful that the saucepan which will be used should be flat bottomed, and use the saucepans with dimensions given herein belove. The valves controlling the gas cookers have special security mechanism. In order to light the cooker; 1.
- Page 8 Disconnect the plug supplying electricity for the cooker from the socket and cutoff the gas by closing the gas valve. While cooker is operating or shortly after it starts operating, it is exteremely hot. You must avoid touching heating elements. Never clean the interior part, panel, grids, burner cover and all other parts of the cooker by the tools like hard brush, cleaning mesh or knife.
- Page 11 230Vac 50...
- Page 12 70 cm 90 cm 45 cm 580 mm 580 mm 520 mm 520 mm 520 mm 520 mm 440 mm 510/520 510 mm 510 mm 300 mm 590 mm 690 mm 860 mm mm mm 98/106 105 mm 100 mm 107 mm 107 mm 119 mm...
- Page 13 G30-30 mbar G20-20 mbar 0.85 1,15 3,000 2,770 gr/h m3/h 0,253 0.96 1,30 3,600 3,350 gr/h m3/h 0,332 0.65 0,97 1,780 1,780 0,167 0.50 0,72 0.88 0,990 gr/h m3/h 0,092 . 125...
- Page 14 30 cm Domino Hobs 60 cm (1000 (1500 Table top hobs 70 & 90 cm (1000 (1500...
- Page 15 24 - 28 cm 18 - 22 cm 12 - 18 cm ” 1000 1500 1500 1150 2000 5-10...
- Page 16 10-15 1200W 1800W...
- Page 19 ’...
- Page 20 45 cm 580 mm 580 mm 520 mm 520 mm 520 mm 520 mm 440 mm 510/520 510 mm 510 mm 300 mm 590 mm 690 mm 860 mm 98/106 105 mm 100 mm 107 mm 107 mm 119 mm 119 mm 220- 220-240V,...
- Page 21 G30-30 mbar G20-20 mbar 0.85 1,15 3,000 2,770 gr/h m3/h 0,253 0.96 1,30 3,600 3,350 gr/h m3/h 0,332 0.65 0,97 1,780 1,780 gr/h m3/h 0,167 0.50 0,72 0.88 0,990 gr/h m3/h 0,092 – 125 ’ ’...
- Page 22 30 cm Domino Hobs 60 cm 1000 W 1500 W 70 & 90 cm 1000 W 1500 W...
- Page 23 24 - 28 cm 18 - 22 cm 12 - 18 cm .” 1000 1500 1500 1150 2000 –...
- Page 24 5-10 1200 1800...
