Summary of Contents for Artus PACC60

Page 1 AP PL I ANC ES FO R L I VI NG PACC60 OPERATION MANUAL...
Page 2 Congratulations, you are now the proud owner of an ARTUSI cooking appliance. Thank you for purchasing ARTUSI and welcome to the ARTUSI Family. This instruction manual has been specially created to inform you of the full range of features your ARTUSI appliance has to offer and serves as an introduction to getting the very best out of your ARTUSI appliance.
Page 3: Table Of Contents
Content 1. Foreword ..................4 1.1 Safety Warnings ................. 4 1.2 Installation ................4 1.2.1 Electrical Shock Hazard ..........4 1.2.2 Cut Hazard ..............4 1.2.3 Important safety instructions .......... 4 1.3 Operation and maintenance ............5 1.3.1 Electrical Shock Hazard ..........5 1.3.2 Health Hazard ..............
Page 4: Foreword
1. Foreword 1.1 Safety Warnings Your safety is important to us. Please read this information before using your cooktop. 1.2 Installation 1.2.1 Electrical Shock Hazard • Disconnect the appliance from the mains electricity supply before carrying out any work or maintenance on it. •...
Page 5: Operation And Maintenance
• Failure to install the appliance correctly could invalidate any warranty or liability claims. • This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
Page 6: Health Hazard
• Switch the cooktop off at the wall before cleaning or maintenance. • Failure to follow this advice may result in electrical shock or death. 1.3.2 Health Hazard • This appliance complies with electromagnetic safety standards. • However, persons with cardiac pacemakers or other electrical implants (such as insulin pumps) must consult with their doctor or implant manufacturer before using this appliance to make sure that their implants will not be...
Page 7 its electromagnetic field. • Never use your appliance for warming or heating the room. • After use, always turn off the cooking zones and the cooktop as described in this manual (i.e. by using the touch controls). Do not rely on the pan detection feature to turn off the cooking zones when you remove the pans.
Page 8: Product Introduction
Congratulations on the purchase of your new Ceramic Hob. We recommend that you spend some time to read this Instruction / Installation Manual in order to fully understand how to install correctly and operate it. For installation, please read the installation section. Read all the safety instructions carefully before use and keep this Instruction / Installation Manual for future reference.
Page 9: Before Using Your New Ceramic Hob
Read this guide, taking special note of the ‘Safety Warnings’ section. • Remove any protective film that may still be on your ceramic hob. 2.6 Technical Specification Cooking Hob PACC60 Cooking Zones 4 Zones Supply Voltage 220-240V~ 50Hz or 60Hz...
Page 10: How To Use
Make sure that the base of your pan is smooth, sits flat against the glass, and is the same size as the cooking zone. Always centre your pan on the cooking zone. Always lift pans off the ceramic hob – do not slide, or they may scratch the glass. 3.3 How to use 3.3.1 Start cooking After power on, the buzzer beeps once, all the indicators light up for 1 second then go out, indicating that...
Page 11: Finish Cooking
3.3.2 Finish cooking Touching the heating zone selection control that you wish to switch off. (e.g. zone 3#) Turn the cooking zone off by scrolling down to “ 0 ” or touching “-” and “+” control together Turn the whole cooktop off by touching the ON/OFF control.
Page 12 b) You can set it to turn one or more cooking zones off after the set time is up. • The timer of maximum is 99 minutes a) Using the Timer as a Minute Minder If you are not selecting any cooking zone Make sure the cooktop is turned on.
Page 13 Touch the timer control, the timer indicator show “10” Adjust the timer setting by touch the “-” or “+” control. The minute minder indicator will start flashing and will show in the timer display. Touching the “-” and “+” together, the timer is cancelled, and the “--”...
Page 14: Over-Temperature Protection
a) The red dot next to power level indicator will illuminate indicating that zone is selected. b) If you want to change the time after the timer is set, you have to start from step 1. 3.3.5 Over-Temperature Protection A temperature sensor equipped can monitor the temperature inside the ceramic hob. When an excessive temperature is monitored, the ceramic hob will stop operation automatically.
Page 15: For Stir-Frying
3. Brush both sides of the steak with oil. Drizzle a small amount of oil into the hot pan and then lower the meat onto the hot pan. 4. Turn the steak only once during cooking. The exact cooking time will depend on the thickness of the steak and how cooked you want it.
Page 16: Care And Cleaning
6. Care and Cleaning What? How? Important! Everyday 1. Switch the power to the cooktop off. • When the power to the cooktop is soiling on 2. Apply a cooktop cleaner while the glass is switched off, there will be no ‘hot glass still warm (but not hot!) surface’...
Page 17: Installation
The touch controls are There may be a slight film of Make sure the touch control area is dry difficult to operate. water over the controls or you and use the ball of your finger when may be using the tip of your touching the controls.
Page 18 A(mm) B(mm) C(mm) 600- 750 50 mini 20 mini Air intake Air exit 5mm WARNING: Ensuring Adequate Ventilation Make sure the ceramic hob is well ventilated and that air inlet and outlet are not blocked. In order to avoid accidental touch with the overheating bottom of the hob, or getting unexpectable electric shock during working, it is necessary to put a wooden insert, fixed by screws, at a minimum distance of 50mm from the bottom of the hob.
Page 19: Before Locating The Fixing Brackets
8.2 Before locating the fixing brackets The unit should be placed on a stable, smooth surface (use the packaging). Do not apply force onto the controls protruding from the hob. Fix the hob on the work surface by screw four brackets on the bottom of hob (see picture) after installation.
Page 20: Connecting The Hob To The Mains Power Supply
8.4 Connecting the hob to the mains power supply The power supply should be connected in compliance with the relevant standard, or a single-pole circuit breaker. The method of connection is shown below. 1. If the cable is damaged or needs replacing, this should be done by an after-sales technician using the proper tools, so as to avoid any accidents.
Page 21 The bottom surface and the power cord of the hob are not accessible after installation. This appliance is labeled in compliance with European directive 2012/19/EU for Waste Electrical and Electronic Equipment (WEEE). By ensuring that this appliance is disposed of correctly, you will help prevent any possible damage to the environment and to human health, which might otherwise be caused if it were disposed of in the wrong way.
Page 22 Warranty Card artusi.com.au Dishwashers - Freestanding, Fully Integrated, Semi Integrated and built-in 12 months warranty products: Freestanding Cookers - Gas and Electric Models in 50cm, 54cm and 60cm Widths Portable Appliances* – Benchtop Models and Worldwide Appliances Pty Limited Portable Gas Models A.B.N.
Page 23 Warranty Card continued artusi.com.au 4. Time for Claim under the Warranty for a breach of any express or non-excludable implied term, condition or warranty is limited at You must make any claim under this Warranty the option of Worldwide Appliances to: within twenty eight (28) days after the occurrence of an event which gives rise to a claim pursuant (i) replacing or repairing the defective part of the...
Page 25 DISCLAIMER Worldwide Appliances PTY LTD, trading as ARTUSI, is continually seeking ways to improve the design speciﬁcations, aesthetics and production techniques of its products. As a result alterations to our products and designs take place continually. Whilst every effort is made to produce information and literature that is up to date, this brochure should not be regarded as an infallible guide to the current speciﬁcations, nor does it constitute an offer for the sale of any particular product.
