- Page 1 SOURIS HARGEABLE RECHARGEABLE BLUETOO UETOOTH BLUETOOTH RECHARGE E B O O K M O U S E N O T E B O O K M O U S E POUR ORDINATEUR USER’S MANUAL VP6156...
-
Page 2: Regulatory Compliance
Regulatory Compliance This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. FCC Certification This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. -
Page 3: Declaration Of Conformity
The term “IC” before the certification/registration number only signifies that the Industry Canada technical specifications were met. Declaration of Conformity Hereby, SMK-LINK Electronics Corporation, declares that this product is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. -
Page 4: System Requirements
SySTEM REqUIREMENTS Hardware • Bluetooth-HID enabled computer system Operating System • Windows XP , Vista, 7 (32- and 64-bit) • Mac OS 10.4.6+ Package Contents • Bluetooth notebook mouse • 2 x AAA Alkaline batteries • User’s manual Page ... - Page 5 Installing Batteries (Supplied) • Remove the battery cover. Battery Cover • Insert the two supplied AAA Alkaline batteries (included in the package) into the battery slots. Make sure the positive (+) and negative (-) ends of the batteries match the polarity markings inside the battery compartment. •...
- Page 6 Bluetooth software installed, it may ask you whether you want to use a passkey; please select “no passkey”. • The SMK-Link Bluetooth Notebook Mouse is designed to work with all Bluetooth software stack (protocol) standards. In addition, this mouse supports Macintosh OS with Bluetooth-HID capability.
- Page 7 MICROSOFT Bluetooth Software 1. Make sure your computer’s Bluetooth radio is turned on. 2. Double click on the “Bluetooth Manager” icon in the system tray to open Microsoft Bluetooth GUI. 3. Click “Add a Device” to search for Bluetooth devices. Page ...
- Page 8 LED mouse sensor lights up and the scroll wheel of the mouse flashes. 5. The computer will search for new Bluetooth devices within range and list each device on the screen. Select the “SMK-Link Bluetooth Mouse”. Click “Next”. Page ...
- Page 9 6. If a window appears asking for a passkey. Select “Don’t use a passkey” and click “Next”. 7. Bluetooth stack starts to connect with SMK-Link Bluetooth Mouse and install device driver. Page ...
- Page 10 8. Once the device driver installation is completed, click “Close” to finish installation process. your Bluetooth mouse is set up and ready to go. APPLE Macintosh Bluetooth Software 1. Make sure your computer’s Bluetooth radio is turned on. Open “System Preferences” page. Page ...
- Page 11 2. Double click the Bluetooth icon to open MAC Bluetooth GUI and select “Devices” page. 3. Press “Set Up New Device” to set up new Bluetooth devices. Page 0...
- Page 12 4. “Bluetooth Setup Assistant” page will show up. Click “Continue”. 5. Select “Mouse“ from the device list and click “Continue”. Page ...
- Page 13 LED mouse sensor lights up and the scroll wheel of the mouse flashes blue. 7. Bluetooth Setup Assistant will search for new Bluetooth mouse devices within range. Select “SMK-Link Bluetooth Mouse” and click “Continue”. Page ...
- Page 14 8. The computer will start pairing with the mouse. Click “Continue”. 9. On the Conclusion screen, click “Quit” to exit setup. your Bluetooth mouse is successfully installed. Page ...
- Page 15 Operating Tips & Troubleshoot • Check the on/off switch located at the bottom of the mouse to make sure the mouse is powered on before using it. • Conserve the battery power by switching the on/off switch to “off” position while traveling or if the mouse will not be in use for awhile.
-
Page 16: Warranty
(90) days from the date of service or return shipping, whichever is longer. If the Product becomes defective in materials or workmanship during the warranty period, SMK-LINK will, at its option, either repair or replace it with a more current or upgraded model if the originally purchased model is not available. -
Page 17: Product Support
This warranty does not affect your statutory right and you may also have other rights which vary from state to state. Unless modified in writing, signed by both you and SMK-LINK, this warranty is understood to be the complete and exclusive agreement between the parties, superseding all prior agreements, oral or written, and all other communica¬tions...
