Maxsys PC4164-NB Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

Table of Contents

1.1
Before You Begin ......................................................................................... 3
1.2
How to Use This Manual ........................................................................... 4
1.3
PC4164-NB Specifications .......................................................................... 5
1.4
Wireless Devices .......................................................................................... 5
2.1
Unpack the PC4164-NB .............................................................................. 6
2.2
Find a Mounting Location for the PC4164-NB ....................................... 6
2.3
Connecting the PC4164-NB ....................................................................... 7
2.4
Enroll the PC4164-NB ................................................................................. 8
3.1
A Note about Electronic Serial Numbers (ESN) ..................................... 9
3.2
3.3
Enroll and Program Wireless Keys (WLS909-NB) ............................... 10
4.1
4.2
Test WLS909-NB Reception ..................................................................... 13
4.3
Mount the PC4164-NB and Wireless Devices ....................................... 13
5.1
Replacing Devices ..................................................................................... 14
5.2
Deleting Devices ........................................................................................ 15
5.3
Erasing Device Serial Numbers .............................................................. 15
6.1
Device Supervision ................................................................................... 16
6.2
Trouble Conditions .................................................................................... 17
firealarmresources.com
3
6
9
12
14
16
19
20
23
24

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PC4164-NB and is the answer not in the manual?

Questions and answers

Related Manuals for Maxsys PC4164-NB

Summary of Contents for Maxsys PC4164-NB

  • Page 1: Table Of Contents

    PC4164-NB Specifications ................5 Wireless Devices ..................5 Section 2: Getting Started Unpack the PC4164-NB ................6 Find a Mounting Location for the PC4164-NB ........6 Connecting the PC4164-NB ............... 7 Enroll the PC4164-NB ................. 8 Section 3: Enroll & Program Wireless Devices A Note about Electronic Serial Numbers (ESN) ........
  • Page 2 Smoke detectors that are a part of this system may not properly WARNING Please Read Carefully alert occupants of a fire for a number of reasons, some of which N o t e t o I n s t a l l e r s follow.

  • Page 3: Section 1: Introduction

    Introduction The PC4164-NB is a wireless signal receiver for use with Maxsys PC4010 and PC4020 v3.0 panels. The PC4164-NB receives signals from WLS9XX wireless devices. New features of the PC4164-NB v2.0: • Identification of Wireless Keys (WLS909-NB): Wireless keys 1 to 16 can be identified as user numbers 0101 to 0116 (respectively) for identified openings/ closings and command output activation.

  • Page 4: How To Use This Manual

    1.2 How to Use This Manual To install and set up the PC4164-NB and wireless devices, follow these steps: 1. Enroll and temporarily mount the PC4164-NB module (see Section 2) 2. Enroll and program wireless devices using zones, wireless keys and handheld keypads (see Section 3) 3.

  • Page 5: Pc4164-Nb Specifications

    1.4 Wireless Devices Please refer to the Installation Instruction sheets of the following devices for more information. The PC4164-NB v2.0 can receive signals from the following devices: This unit is listed as a single or multiple station smoke detector accessory. •...

  • Page 6: Section 2: Getting Started

    Make sure that electrical wires will not run over the antenna(s) of the module when it is mounted. When mounting the PC4164-NB in a basement, place the module as high and as close to the underside of the first floor as possible. The range of the module will be smaller if the unit is mounted below ground level.

  • Page 7: Connecting The Pc4164-Nb

    The PC4164-NB is connected to the control panel via the Combus. CAUTION: Remove all power from the panel while connecting modules to the Combus. Wire the PC4164-NB to the Combus of the PC4010/PC4020 according to diagram 1: Diagram 1 firealarmresources.com...

  • Page 8: Enroll The Pc4164-Nb

    PC4164-NB after you have enrolled all the hardwire zone expander modules. For example, if you enroll the PC4164-NB first on a PC4020, it would use up zones 17 to 80, leaving only 48 spots left for hardwire zone expander modules.

  • Page 9: Section 3: Enroll & Program Wireless Devices

    1. At a system LCD keypad, enter [*][8][Installer’s code]. 2. Enter Ref #[001300] to go to the Enroll Device programming section. This section will only be available if you have enrolled the PC4164-NB with the panel (see Section 2.5). The LCD keypad will display Enroll Device Serial # [ 3.

  • Page 10: Enroll And Program Wireless Keys (Wls909-Nb)

    3.3 Enroll and Program Wireless Keys (WLS909-NB) For wireless keys to work on the system, you need to enroll them and then program the function buttons. You can enroll up to 16 wireless keys on the PC4164-NB. Step 1: Enroll Wireless keys 1.
  • Page 11 I N S T A L L I N G W I R E L E S S D E V I C E S Step 2: Program the WLS909-NB Function Buttons WLS909-NB wireless keys have four programmable function buttons. When you press and hold a button for two seconds, the programmed function will be executed.

  • Page 12: Section 4: Testing & Mounting Devices

    If several wireless devices produce BAD test results, you may need to move the PC4164-NB to a better location. (See section 2.3 for tips on finding a location for the PC4164-NB.) 4.1 Test the Placement of WLS904-NB and WLS907-NB Devices...

  • Page 13: Test Wls909-Nb Reception

    PC4164-NB receiver. Moving the PC4164-NB higher will usually improve the reception. If you move the PC4164-NB, repeat the tests described in sections 4.1 and 4.2 on all the wireless devices. Continue to test the devices until you have found locations...

  • Page 14: Section 5: Deleting & Replacing Devices

    Deleting & Replacing Devices If a device is not working, or you need to change the setup of the system, you may need to replace or delete wireless devices. Follow the appropriate procedure in this section. 5.1 Replacing Devices Wireless devices are divided into the following classes: Class Model WLS907-NB...

  • Page 15: Deleting Devices

    5.2 Deleting Devices This section describes how to delete any of the enrolled wireless devices from the PC4164-NB, and from the system. 1. At a system LCD keypad, enter [*][8][Installer’s code]. 2. Enter Ref #[001301] to go to the Delete Device section. The LCD keypad will...

  • Page 16: Section 6: Additional Programming Notes

    A zone supervisory is a test transmission that each wireless zone sends to the PC4164-NB. When the PC4164-NB receives the supervisory transmission from the zone, the PC4164-NB will transmit this information to the control panel. If the control panel does not get a supervisory transmission from a zone within the Device Fail time, the zone will be considered “missing”...

  • Page 17: Trouble Conditions

    LCD keypad “Trouble” light will turn on and the keypad will beep. Press [*][2] to display the trouble conditions. The following trouble conditions apply to the PC4164-NB. For a description of all troubles, please see Section 16 “Diagnostics and Troubleshooting” in the PC4010/4020 Installation Manual.
  • Page 18 Enable RF Jam Detect Trouble The RF Jam Detect trouble condition will be generated and logged when the PC4164-NB module detects an attempt to block RF signals. This tells the user that the PC4164-NB is not receiving wireless device transmissions. The panel will transmit the General System Trouble reporting code.

  • Page 19: Section 7: Troubleshooting

    • Verify that the correct ESN was entered when the device was enrolled • Verify that the device is in range of the PC4164-NB. Try testing the device in the same room as the receiver. • Confirm that the PC4164-NB is properly connected to the Combus (see section 2 for PC4164-NB set up and wiring instructions).

  • Page 20: Programming Worksheets

    Programming Worksheets [001300] Enroll Device (see section 3.2) • Default = 000000 • 6-digit entry is required; for 5-digit serial numbers, enter [0], then the number (See section 3.1 “A Note About Electronic Serial Numbers”.) System PC4164 Serial No. System PC4164 Serial No.
  • Page 21 WLS909-NB Wireless Key Options (see section 3.3) [001300] Enroll Device Default = 000000 Wireless Serial Wireless Serial Key No. Key No. l _ ____ l _ ____ l _ ____ l _ ____ l _ ____ l _ ____ l l _ ____ l _ ____ l _ ____ l _ ____ l _ ____ l _ ____ l l _ ____ l _ ____ l _ ____ l _ ____ l _ ____ l _ ____ l l _ ____ l _ ____ l _ ____ l _ ____ l _ ____ l _ ____ l...
  • Page 22 Device Supervision (see section 6.1) [001306] Device Supervision Default = ON NOTE: Wireless Keys are NOT supervised. Zone Supervision Zone Supervision Zone Supervision ON/OFF ON/OFF ON/OFF l _ ____ l _ ____ l _ ____ l l _ _______ l l _ ____ l _ ____ l _ ____ l l _ _______ l l _ ____ l _ ____ l _ ____ l...

  • Page 23: Index

    Buttons contact 12 test 12 programming 11 motion detector 12 Mount wireless key 13 devices 13 Trouble conditions 17 Connect PC4164-NB 13 Troubleshooting 19 Combus 7 PC4164-NB 7 Number Wireless key serial 9 enrolling 10 Default Wireless 15 slot 10...

  • Page 24: Limited Warranty

    Digital Security Controls Ltd.’s liability for failure to LIMITED WARRANTY repair the product under this warranty after a reason- Digital Security Controls Ltd. warrants the original able number of attempts will be limited to a replace- purchaser that for a period of twelve months from ment of the product, as the exclusive remedy for the date of purchase, the product shall be free of de- breach of warranty.
  • Page 25 Security Products ©1999 Digital Security Controls Ltd. 1645 Flint Road, Downsview, Ontario, Canada M3J 2J6 (416) 665-8460 • 1-800-387-3630 www.dscgrp.com Printed in Canada 29004102 R001 firealarmresources.com...
  • Page 26 PC4164-NB v2.0 • Installation Manual WARNING: This manual contains information on limitations regarding product use and function and information on the limitations as to liability of the manufacturer. The entire manual should be carefully read. firealarmresources.com...
  • Page 27 FCC COMPLIANCE STATEMENT CAUTION: CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY DIGITAL SECURITY CONTROLS LTD. COULD VOID YOUR AUTHORITY TO USE THIS EQUIPMENT. This equipment generates and uses radio frequency energy and if not installed and used properly, in strict accordance with the manufacturer’s instructions, may cause interference to radio and television reception.
