Wired
PresentationPro
Public Address System
PA310 Owner's Manual
Shown with
optional MB-PA3W
wall mounting bracket
and TP-30 tripod sold
separately
califone.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Wired Presentation Pro PA310 and is the answer not in the manual?

Questions and answers

Summary of Contents for Califone Wired Presentation Pro PA310

  • Page 1 Wired PresentationPro ™ Public Address System PA310 Owner’s Manual Shown with optional MB-PA3W wall mounting bracket and TP-30 tripod sold separately califone.com...
  • Page 2 We encourage you to visit www.califone.com/registration.php, to register your product for its warranty coverage, to sign up to receive our newsletter, download our catalog, and learn more about the complete line of Califone audio visual products, including portable and installed wireless PA systems, multimedia players and recorders, headphones and headsets, computer peripheral equipment, visual presentation products and language learning materials.
  • Page 3: Recommended Set-Up Procedure

    • Connect and audio source. Plug a microphone into either the XLR MIC input jack or the ¼” phone mic input or a wireless Califone microphone. An audio source can be plugged into the AUX or LINE IN jacks. • Turn the power switch “ON” (the red LED on the rear panel should light).
  • Page 4 Continued from page 2 Volume Control When the main power switch is turned on, the Volume Control is at the lowest level to prevent accidental damage to the amplifier. The volume can be controlled by using the Vol+/Vol- buttons on the rear panel or the PI-RC Infrared remote volume control.
  • Page 5 PA310 PA310 shown with PI-RC Remote 1. Rugged steel-reinforced handle for easy mobility 2. Volume up / Mute / Volume down controls 3. Volume inidicator 4. Power switch, LED indicator & DC power input jack 5. Separate bass, treble controls for quality sound 6.
  • Page 6 Sold separately. Make sure to have a qualified installation professional install the hardware for wall mounting. Califone will not be held responsible for any damage resulting from improper installation. V i s i t u s o n l i n e a t c a l i f o n e . c o m...
  • Page 7: Specifications

    Specifications Rated power output: 30 watts RMS at 1% THD Sensitivity for rated output: Line: 125 mVrms Microphone:: 4 mVrms Auxiliary: 250 mVrms Frequency response: 60 Hz – 20 kHz+ 3dB Treble: +10dB, -10dB, 10kHz Bass: +5dB, -4.5dB 70Hz Speakers: Woofer: 6”...
  • Page 8: Important Safety Instructions

    TAKEN SO THAT THE GROUNDING OR POLARIZATION MEANS OF THE APPLIANCE ARE NOT DEFEATED. Califone® International Inc. • 1145 Arroyo Avenue, # A • San Fernando, CA 91340 USA Toll Free 800.722.0500 | Toll Free Fax 877.402.2248 International Customers call 818.407.2400 or Fax 818.407.2405 califone.com...
