Richelieu TXRF24B2 Operating Instructions

Operating Instructions 2-Button Hand-Held Transmitter
2-Button Hand-Held Wireless Transmitter 2.4GHz
• Function •
Selectively opening and engaging locks
Light signal after pressing button
• Special function •
Switching over to automatic locking.
Pressing a combination of buttons on the hand-held transmitter, you can switch the furniture lock over
to automatic locking. Please refer to the operating instructions for the electronic unit for the applicable
time spans.
Important note!
All electronic units to which the hand-held transmitter is programmed will be switched to the same state.
Do not place your hand-held transmitter in the furniture when automatic locking is set.
If you wish to return to standard mode again, repeat steps 1-5.
• Changing the batteries •
Carefully prise apart the
two casing halves.
Attention!
If the battery has been inserted correctly, a light-emitting diode will briefly light up.
If this is not the case, insert the battery again, making sure it is fitted the right way round.
Type: TXRF24B2
Open lock
1. Press and hold down both buttons on the hand-held transmitter.
2. The indicator begins to flash for a while.
3. When the indicator switches back to steady light,
programming has been completed.
4. Now let both buttons go again.
5. Observe the sight signals on the furniture. If the signal flashes
red / green, you have successfully switched over.
Slide the battery out of the battery holder in the
direction of the arrow and replace it with a new one.
BDA-2-Tasten Funk Handsender 2-4 GHz -EN- (Rev-10) 21-11-2011
Engage lock
Only use battery type:
Cr2032 3V
