Installation Guide & Owner's Manual
Model NSVC-1
1
For
Autoclave
Direct-to-Drain Thermal Reduction
System for Autoclave Wastewater
Model NSVC-2
2
For
Autoclaves
VistaCool can be used with:
Midmark/Ritter M3
Midmark/Ritter M9*
Midmark/Ritter M11*
* Requires Model V7502 and S7560 adapter kit
SciCan STATIM 2000
SciCan STATIM 5000

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Vistacool NSVC-1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Duraline Systems Vistacool NSVC-1

  • Page 1 Installation Guide & Owner’s Manual Model NSVC-1 Model NSVC-2 Autoclave Autoclaves VistaCool can be used with: Midmark/Ritter M3 SciCan STATIM 2000 Direct-to-Drain Thermal Reduction Midmark/Ritter M9* SciCan STATIM 5000 System for Autoclave Wastewater Midmark/Ritter M11* * Requires Model V7502 and S7560 adapter kit...
  • Page 2: Table Of Contents

    Table of Contents Introduction ��������������������������������������������������������������������������������������������������������������������������������������������������������������������3 Important Information ��������������������������������������������������������������������������������������������������������������������������������������������������3 Preparation - V7501 �������������������������������������������������������������������������������������������������������������������������������������������������������4 Preparation - V7502 ������������������������������������������������������������������������������������������������������������������������������������������������������5 Typical Installation - V7501 ������������������������������������������������������������������������������������������������������������������������������������������6 Typical Installation - V7502 ������������������������������������������������������������������������������������������������������������������������������������������7 Plumbing ������������������������������������������������������������������������������������������������������������������������������������������������������������������������� 8 Cabinetry ��������������������������������������������������������������������������������������������������������������������������������������������������������������������������9 Connecting the System ����������������������������������������������������������������������������������������������������������������������������������������������10 Tank Positioning �����������������������������������������������������������������������������������������������������������������������������������������������������������12 Starting & Using the System ���������������������������������������������������������������������������������������������������������������������������������������12 Autoclave-Specific Instructions ��������������������������������������������������������������������������������������������������������������������������������13 Maintenance ������������������������������������������������������������������������������������������������������������������������������������������������������������������14 Troubleshooting �����������������������������������������������������������������������������������������������������������������������������������������������������������14...
  • Page 3: Introduction

    Introduction VistaCool is a patent-pending system designed to eliminate the VistaCool can be used with: need for autoclave condenser/waste bottles and condensation tanks by cooling the exhaust water and automatically sending it Midmark/Ritter M3 directly down the drain� With the use of a simple adapter kit, the Midmark/Ritter M9* VistaCool Model V7502 is designed to enable the Midmark/Ritter Midmark/Ritter M11*...
  • Page 4: Preparation - V7501

    Preparation / V7501 Autoclave Remove all contents from the VistaCool product carton to make certain all items needed for installation are present and undamaged� S6155 Water Supply Valve S7570 S7506 M3 Mono Plug Drain Line Assembly S7508 VC250-A Inline Thermal VistaCheck Dual Check Sensor Assembly Backflow Preventer...
  • Page 5: Preparation - V7502

    Preparation / V7502 Autoclaves Remove all contents from the VistaCool product carton to make certain all items needed for installation are present and undamaged� S6155 Water Supply Valve S7570 S7506 M3 Mono Plug Drain Line Assembly S7508 VC250-A Inline Thermal VistaCheck Dual Check Sensor Assembly Backflow Preventer...
  • Page 6: Typical Installation - V7501

    Typical Installation / V7501 Autoclave AUTOCLAVE Cold Alternate Cold Water Line Fitting Installation Drain Line S6155 TU753 Water Supply Valve Condensate Drain Line VC250-A TU755 Sink Drain VistaCheck Backflow Preventer Coolant Overflow Drain Line S7506 TU751 Manifold Coil Assembly Drain Line Assembly Cold Water Feed Line S6119 or S6135 S7508...
  • Page 7: Typical Installation - V7502

    Typical Installation / V7502 Autoclaves AUTOCLAVE AUTOCLAVE Cold Alternate Cold Water Line Fitting Installation Drain Line S6155 TU753 Water Supply Valve Condensate Drain Line VC250-A TU755 Sink Drain VistaCheck Backflow Preventer Coolant Overflow Drain Line S7506 TU751 Manifold Coil Assembly Drain Line Assembly Cold Water Feed Line S6119 or S6135...
  • Page 8: Plumbing

    Plumbing Whether installing a single or double-autoclave VistaCool unit, the cold water (coolant) supply and drain (condensate and coolant overflow) connections are exactly the same� Turn off water supply� Provide for a 1/4” connection Measure the drain tee adapter to the cold water supply� This is usually accomplished assembly for placement into the using a compression fitting or one of the supplied fittings drain piping�...
  • Page 9: Cabinetry

    Cabinetry VistaCool systems are typically installed in the base/sink cabinet of sterilization centers� The systems should always be installed as close to the drain system and cold water supply line as possible� The 1/4” O�D� Teflon high temperature tubing will need to run from the output port of the autoclave directly to the VistaCool system�...
  • Page 10: Connecting The System

    Connecting the System • All tubing cuts must be even and clean� • Most fittings are a push-to-connect design� Use a twisting motion when pushing tubing into the fittings to ensure ends are fully inserted through the collet and into the internal “O” ring� •...
  • Page 11 V7501 TO AUTOCLAVE MANIFOLD 2� Connect the cold water supply to the water tank using the blue, semi-transparent (1/4” OD x 1/8” ID) polyurethane tubing to the system� Continue the tubing from the outlet of the VistaCheck to the top stainless hose barb on top of the brass water valve on the thermal regulator� Optional: warm the end of the tubing with hot water before pushing it over the barb and make sure it is pushed down completely over the stem of the barb and is flush with the hex stainless base of the barb�...
  • Page 12: Tank Positioning

    Tank Positioning The VistaCool system should be set on a hard, level surface and installed so that the top of the water tank is above the coolant overflow fitting on the drain adapter assembly, and below the autoclave outlet� If the tank is below the level of the coolant overflow fitting, the system may not operate properly�...
  • Page 13: Autoclave-Specific Instructions

    Autoclave-Specific Instructions For questions regarding the performance of an autoclave, please contact the autoclave manufacturer� Connecting to a SciCan STATIM 2000/5000 Use of the VistaCool systems with SciCan STATIM 2000 & 5000 autoclave units requires no additional steps beyond the general instructions outlined in pages 6-12 of this guide� Connecting to a Midmark/Ritter M3 Insert the 3�5mm mono plug provided with Shut off the M3 and disconnect its power cord�...
  • Page 14: Maintenance

    Maintenance The VistaCool direct-to-drain thermal reduction systems for autoclaves have been designed to require virtually no maintenance� However, it’s recommended that operators periodically verify that the tubing and connections remain leak-free, are free of mineral deposits or debris, and are not compromised in any way� The system includes several fail-safe devices designed to stop the flow of exhaust water from the autoclave in the event of a problem�...
  • Page 15: Vistacool Limited Warranty

    VistaCool Limited Warranty PRODUCT IMPROVEMENTS: VRG reserves the right to change or improve its products or any portions thereof without being obliged to provide such change During the time period and subject to the conditions or improvement of units sold and/or shipped prior to hereinafter set forth, Vista Research Group, LLC such change or improvement�...
  • Page 16: Vistacool System Information & Specifications

    VistaCool System Information Thank you for choosing the VistaCool Direct-to-Drain Thermal Reduction System for Autoclave Wastewater for your practice! The following chart is for necessary information for future reference� Please fill it out completely and keep this manual in a convenient place for ready access and reference� Be sure to use our convenient online warranty registration form at vrg.support/register�...
