- Page 1 AP-DJ283X IONIZING BLOWER Intelligent Static Removal High speed Self-balancing LCD Display Shanghai Anping Static Technology Co.,Ltd...
- Page 2 Multi models available Suitable for different production environments AP-DJ2834 AP-DJ2833 AP-DJ2832 AP-DJ2831 Durable Intelligent remote control Network monitoring One-button start CE certification...
- Page 3 Industry Application Widely used in electronics, optoelectronics, and semiconductor industries Static removal Prevent adhesion of objects Prevent material splash Prevent static electricity Prevent blockage of feeder...
-
Page 4: Network Monitoring
Network Monitoring Multiple ways of networking, monitoring the working status of ionizing air blower online Wireless communication IMS monitoring software RS485 communication IMS monitoring software USB wire link AP-DY6703 IMS monitoring software USB wire link AP-KT3701 AP-DY6704... -
Page 5: Intelligent Remote Control
Intelligent Remote Control Cleaning time /Air volume output/Ion balance adjustable Cleaning time setting Set a reminder for the cleaning time at will. Blue light flashes indicates cleaning is required. The electrode needle cleaning cycle should be set according to the working environment when using the ionizing air blower. Cleaning cycle should be shorten appropriately in environment with more moisture and dust. - Page 6 Pulse DC Discharge effect is better compare to frequency AC ionizing air blower Pulse DC VS Traditional AC Positive voltage working time Pulse DC method generate ions with two polarity by （Positive high voltage） Positive pulse Negative pulse applying "+" and "-" high voltage alternately on Pulse DC positive and negative electrode needles.
- Page 7 High Efficiency Static Removal Keep a clean production environment and stay away from static electricity Test Length (mm) Test Length (mm) Discharge Time(s) -150 Ion Balance(V) -150 Ion balance distribution diagram of AP-DJ2831 Discharge time distribution diagram of AP-DJ2831 Test Length (mm) Test Length (mm) Discharge Time(s) -275...
- Page 8 High Efficiency Static Removal Keep a clean production environment and stay away from static electricity Discharging time: Discharge speed within 2.5 sec when vertical installation distance is 450mm Discharging distance: Up to 1050mm width.
- Page 9 Features Safe / Easy to use / Durable No.1 Magnetic net cover The power is cut off immediately and the fan is in the standby (STOP) state when the net cover is separated , which is convenient for disassembly and maintenance. No.2 High air volume fan five speed adjustment...
- Page 10 Features Safe / Easy to use / Durable No.6 LED display LED display shows the equipment address (e.g.A00), wind speed gear (e.g.S1), cleaning cycle (e.g.T04), temperature and humidity, cleaning indication (Cleaning), fan fault alarm (Fan Fault!!) and HV fault alarm (HV Fault!!). The balance voltage of each air outlet displays in real time, which alarms (Ion Fault!!!) when the set threshold is exceeded, alarms fault when the high voltage is 0V.
- Page 11 Panel function instructions Rich functions, more intelligent use AP-DJ2831 Front Back Front cover Cleaning switch Power switch Back cover Ground Stud Status Indicator Air volume adjustment Bakelite screw handle (M5×8) Communication antenna RJ45 power/communication interface U-shaped bracket LCD display AP-DJ2832/2833/2834 Front Back Cleaning switch...
-
Page 12: Lcd Display Parameters
LCD display parameters LCD parameter display description Display content Description Sample graph RUN/STOP Run / Pause Green light：Running Working address of the device：00 The current wind speed gear: 4 (5 gears in total, wind speed in gear 1 is the largest) Blue light：Pause / Standby Cleaning cycle：04（Unit：H）... -
Page 13: Specification
Specification Technical Parameters / Product Size Technical Parameters Model AP-DJ2831 AP-DJ2832 AP-DJ2833 AP-DJ2834 DC 24V（RJ45 interface）/ Three in one socket（220VAC 50/60Hz） Input voltage DC 24V（RJ45 interface） Output voltage DC±4KV → ±6KV 42.5W Power Ion emission Pulses DC Emitter electrode Tungsten alloy Discharge range 750*300mm（L*W）... - Page 14 AP-DJ2831 Product Size Unit：mm 70.5 98.5 200.5 Installation accessories 1 pair of U-shaped aluminum powder spraying mounting brackets, 1 pair of bakelite screw handles（M5×8） AP-DJ2832/2833/2834 Product Size Unit：mm 1037 1011 1000 Installation accessories 1 pair of L-shaped aluminum powder spraying mounting brackets, 1 pair of bakelite screw handles（M5×8）...
-
Page 15: Installation Steps
Products Use Installation steps/technical tips/Packing accessories Installation steps 1. Install the ionizing air blower and the matching power adapter firmly in the best discharge position. 2. Insert the power network cable into the adapter and the ionizing air blower RJ45 network port, and insert the power cable of the adapter into the row socket. -
Page 16: Safety Warning
Safety warning 1. Read the operating instruction carefully before installing and using the device. 2. The whole set of equipment must be reliably grounded during use, and the connection resistance of the electrical connection to the AC equipment ground should be less than 1 ohm. 3. -
Page 17: Maintenance
Maintenance 1. In order to ensure the good performance of the product, the fan should be cleaned and maintained in time according to the use environment and the required electrostatic protection requirements, that is, using electrostatic brush, dust-free cotton swab, dust-free cloth dipped in anhydrous alcohol to gently remove the dust on the electrode, discharge bracket, fan and metal mesh cover. - Page 18 AP&T Professional electrostatic intelligent monitoring/analysis and elimination solution provider 专 业 创 造 价 值 S p ecia lit y C r ea t es Va l u e Shanghai Anping Static Technology Co.,Ltd Tel : +86-21-64517676 Fax : +86-21-64517673 AP&T Postcode : 200233 Website : www.ap-static.com...
