ELECTRONIC CONTROL PANEL
FOR TWO 230VAC MOTORS
UNIK2E230
(COMPLETE)
UNIK2E230SK
(
W I T H O U T B O X A N D T R A N S F O R M E R )
TECHNICAL INSTALLATION MANUAL
FOR AUTOMATIC GATES
Before installing, thoroughly read this manual that is an integral part of this
Kit. Prastel S.p.A. declines any responsibility in the event current standards
in the country of installation are not complied with
The symbol CE conforms with European Directive R&TTE 99/05CE
_ V2
_ V2
WARNING!
ISUNIK2E230v2_GB_10_12.doc
BOX IP 54
Advertisement
Table of Contents
Summary of Contents for PRASTEL UNIK2E230 V2
- Page 1 WARNING! Before installing, thoroughly read this manual that is an integral part of this Kit. Prastel S.p.A. declines any responsibility in the event current standards in the country of installation are not complied with The symbol CE conforms with European Directive R&TTE 99/05CE...
-
Page 2: Table Of Contents
ISUNIK2E230v2_GB_10_12.doc ENGLISH UNIK2E230 1. INTRODUCTION ..................3 2. MAIN FEATURES ..................3 3. TECHNICAL SPECIFICATIONS ..............3 4. CONNECTION AND SET UP OF THE CONTROL UNIT ......4 GENERAL DIAGRAM OF SETTINGS AND CONNECTIONS ........5 SIMPLIFIED LEARNING PROCEDURE (also see pages 8-10) ......6 PROFESSIONAL LEARNING PROCEDURE (see also pages 8-10) ...... -
Page 3: Introduction
Built to European reference Directive Standards (R&TTE 99/05/CE) DECLARATION OF CONFORMITY Prastel S.p.A. declares that UNIK2E230 IS IN ACCORDANCE with the 99/05/EC (R&TTE) direcitve The complete declaration of conformity is available in Prastel or to the internet address www.prastel.it 3. TECHNICAL SPECIFICATIONS... -
Page 4: Connection And Set Up Of The Control Unit
ISUNIK2E230v2_GB_10_12.doc ENGLISH UNIK2E230 4. CONNECTION AND SET UP OF THE CONTROL UNIT Before installing the UNIK2E230 control unit, read the “General safety warnings and notes” (page 15). Mount a differential thermo-magnetic circuit breaker 6A (IC=30mA) on the mains supply as specified in the current reference standards (IC = differential current). Fix the box using the special fixing holes. -
Page 5: General Diagram Of Settings And Connections
ISUNIK2E230v2_GB_10_12.doc ENGLISH UNIK2E230 GENERAL DIAGRAM OF SETTINGS AND CONNECTIONS 30 31 32 33 34... -
Page 6: Simplified Learning Procedure (Also See Pages 8-10)
ISUNIK2E230v2_GB_10_12.doc ENGLISH UNIK2E230 SIMPLIFIED LEARNING PROCEDURE (also see pages 8-10) 1. Verify the initial settings. 2. Program the remote controls (if needed) with the gate stopped (green LED GC turned on) according to the following: a) Press the program button P2/RAD for two seconds: the red LED “RAD” lights up. b) Press the desired button on each transmitter. -
Page 7: Professional Learning Procedure (See Also Pages 8-10)
ISUNIK2E230v2_GB_10_12.doc ENGLISH UNIK2E230 PROFESSIONAL LEARNING PROCEDURE (see also pages 8-10) Using the professional learning procedure the installer can determine: a) the instant in which the opening and closing slow-down starts b) the pedestrian function c) the safety device trigger mode. When the motor and safety devices are connected and the initial set-up has been completed, programme the remote controls that will be used (see page 8) with the gate stopped (green LED GC turned on). -
Page 8: Control Unit Operating Logic (Analytic Exam)
ENGLISH UNIK2E230 5. CONTROL UNIT OPERATING LOGIC (ANALYTIC EXAM) PROGRAMMING AND CANCELLATION OF THE REMOTE CONTROLS With the receiver built into the control box, Prastel dip-switch, fixed code and rolling code remote controls can be indifferently learned. 5.1.1 Programming Power the control panel and with the automation stopped (green LED GC turned on): •... -
Page 9: Trimmer "For"- Motor Speed
ISUNIK2E230v2_GB_10_12.doc ENGLISH UNIK2E230 - when the gate is open the closing commands are inhibited, Using the professional learning, the PED input can be set as internal photocell: - in closing phase it provokes an inversion of direction when cleared, - in opening phase it provokes a STOP and opening continues when cleared, - when the gate is closed it delays opening until it is cleared, - when the access is open it inhibits the closing commands. - Page 10 ISUNIK2E230v2_GB_10_12.doc ENGLISH UNIK2E230 drives the two motors without 2 motor delay if the DEL trimmer is turned fully counter-clockwise, with a 2 motor delay of 3 seconds for all the other positions of the DEL trimmer. - activates the operator for one second at maximum speed and then at the speed set with the “FOR” trimmer. - the opening terminates when the limit switch or the obstacle detection device are triggered or the manoeuvre time has elapsed.
-
Page 11: Pedestrian Opening" Function
ISUNIK2E230v2_GB_10_12.doc ENGLISH UNIK2E230 When the automation is completely open, to start the closing manoeuvre give a radio or manual command and the control unit: - carries out a fixed one second pre-flash drives the two motors with a 2 motor delay as set on the DEL trimmer - if a command is issued during closure, the control unit carries out a complete re-opening. -
Page 12: Electric Lock
ISUNIK2E230v2_GB_10_12.doc ENGLISH UNIK2E230 5.11 ELECTRIC LOCK There is an output (EL) for the electric lock 12V max 15VA. The command is given before every opening manoeuvre for 2 seconds, and before every re-opening caused by the triggering of a photocell or safety device. Using dip-switch 4 on the card, the kick-back and the final stroke at the end of the closing manoeuvre can be enabled or not. -
Page 13: Programming Through Gtsystem
ENGLISH UNIK2E230 7. PROGRAMMING THROUGH GTSYSTEM The GTSYSTEM is an autonomous multi-functional terminal that can be used on various Prastel products both for testing and function modification. In the case of UNIK2E230 control unit, it allows: • modification or visualisation of operating parameters, •... -
Page 14: Troubleshooting
ISUNIK2E230v2_GB_10_12.doc ENGLISH UNIK2E230 9. TROUBLESHOOTING PROBLEM PROBABLE CAUSE REMEDY 230 volt mains voltage absent Check master switch Check for any STOP commands Emergency STOP present connected to the STP input. On giving a command with the There is no jumper between the STP If not used, check if there is a remote control or with the key- input and the common. -
Page 15: Safety Warnings For Installation And Use
Nor does the warranty cover parts subject to wear (batteries, oil etc.). Products returned to PRASTEL S.p.A. for repair shall only be accepted carriage paid. Prastel S.p.A. shall return the repaired product to the sender carriage forward. Otherwise the goods will be refused on receipt.
