Sunmi NK010 Quick Start Manual

Keyboard introduction
Programmable key area
Users can program and customize key functions
Combination key are A
Single key : Value below the key silk screen
Shift + Key : Value above the key silk screen
Fn + Key : Value at the bottom right of the key silk screen
Combination key are B
Single key or Shift + Key: Value at the top of the key silk
screen
Fn + Key: Value at the bottom of the key silk screen
Numeric key area
Numeric key: Enter values
Cash key: The key value is 07/8A. It can program on its
own to drive the money box
Keyboard interface
Connect devices via the Type-c interface data cable
Basic parameters
Keyboard interface : USB
Working voltage : DC 5V
Working current : less than 20 mA
Dormancy current : less than 5 mA
Number of keys : 89 keys
Key life : > 10 million times
Product weight : ~410g
Waterproof grade : IP55
Product size : 275.8*113.1*26.4mm
Operating platform : windows / Android
Packaging contents
One keyboard
One User Guide
One Type-c data cable
Disclaimer
Due to product update, some details of this document may
not conform to the real product. Please refer to the real
product. Our company shall reserve the right to interpret this
document and amend this User Guide subject to no prior
notice.
Manufacturer: Shanghai Sunmi Technology Co.,Ltd.
Address: Room 505, KIC Plaza, No.388 Song Hu Road,
Yang Pu District, Shanghai, China
Keyboard
QUICK START GUIDE
NK010
Table for names and contents of toxic and harmful substances in this product
Part Name
Pb
Circuit Board
Structural
Packaging
○：indicates that the content of the toxic and hazardous substance in all
homogeneous materials of the component is below the limit specified in
SJ/T 11363-2006.
X：indicates that the content of the toxic and hazardous substance in at
least one homogeneous material of the component exceeds the limit
stipulated in SJ/T 11363-2006. However, as for the reason, because
there is no mature and replaceable technology in the industry at present.
The products that have reached or exceeded environmental protection
service life should be recycled and reused according to the Regulations on
Control and Management of Electronic Information Products, and should not
be discarded randomly.
Reminder
If the keyboard is accidentally contaminated with hot water and coffee, etc.,
please dry it in time so as to prevent keyboard abnormalities.
Combination key are A
Combination key are B
Keyboard interface
Toxic or Hazardous Substances and Elements
Hg Cd Cr(VII) PBB PBDE
Programmable key area
Numeric key area
DEHP DBP BBP DIBP
