Ram Mounts RAM-B-166 Manual

Model # - RAM-B-166
Ram Mounts
Quick Grip Charger
1. Can be customize
2. Diameter=50mm,can be customized
3. Input Power:10W 5V-2A; 9V-1.67A
4. Output: 5W / 7.5W / 10W
5. Conversion Efficiency: 85% Max
6. Transmitting Distance: 5-8mm
7. Working Frequency: 115-205KHz
8. Product Standard: WPC v.1.2.4
9. Protective measures: FOD,DPL,SCP,Over temperature,over
voltage protection, software/hardware dual over current protection
enhanced VRVS;Dedicated high power low loss MOS & MOS driver
10. Compatible for:QC2.0/QC3.0

Wireless Charging

Phone case that contain metal, magnets,
or are thicker than 3mm will interfere with
wireless charging.
Position your phone in the center of the
designated charging area. You phone will
indicate when charging begins.
MANUAL
This charger is designed for Qi-compatible
devices. If your phone does not have built-in
wireless charging capabilities, please use a
certified Qi wireless charging case or receiver.
Refer to your phone's user manual for detailed
features and functions.
1.We suggest to use QC2.0 or QC3.0 adapter
for fast charging.
2.Do not place metal objects, magnets,
magnetic stripe cards, and hard drive based
devices near the wireless charger. It may
cause data corruption.
3.Do not attempt to modify, disassemble, or
repair this product.
4.Do not expose to water, moisture,
or extreme temperatures
( below 40℉ or above 90℉)
