Extreme USB SP3001-15 Quick Start Manual

This product works with AIA USB3 Vision™ compliant devices.
Before you get started, install any software required to operate your USB 3.0 device(s).
The SP3001-15 cable is not backward compatible with USB 2.0/1.1 devices. Per USB-IF speci cation, USB 3.0 devices must attempt enumeration on USB
3.0 rst. If your USB 3.0 device enumerates on USB 2.0 rst, then your device is out of spec and will not operate with this cable.
1 1
Plug the SP3001-15's USB 3.0 host connector into a USB 3.0 port on your computer.
It is recommended to plug the SP3001-15's USB power connector into any USB port on your computer.
2
This step is essential if your USB 3.0 device is not self-powered or draws more than 2.5W of power.
Attach your USB 3.0 device into the SP3001-15's USB 3.0 receptacle. AIA USB3 Vision
3
are supported if needed.
Computer
Conveniently secure your configuration by wrapping the included cable tie around the USB 3.0 receptacle's two mounting slots.
USB 3.0 SP3001-15
1-Port USB 3.0 15m Active Copper Extension Cable
Quick Start
Guide
USB Power
USB 3.0 SP3001-15
Connector
Active Cable
2 2
1 1
USB 3.0 Host
Connector
mounting slots for cable tie
™ locking USB connectors
USB 3.0 Locking
Receptacle
USB 3.0 Device
3 (e.g. Camera)
