VERSION # 21-09-29
1 / 11
MODEL #
CM6495
Questions?
GIVE US A CALL: 1-888-980-5122
MON-FRI 8:30AM - 5:30PM (PT)
Phillips
Screwdriver
(Not Included)
2 - People
Recommended
EASY
The Assembly Rating is a
5-point system showing the
level of effort needed to
assemble a specific product.
DIFFICULT
Advertisement
Related Manuals for Furniture of America CM6495
Summary of Contents for Furniture of America CM6495
- Page 1 MODEL # CM6495 Questions? GIVE US A CALL: 1-888-980-5122 MON-FRI 8:30AM - 5:30PM (PT) Phillips Screwdriver (Not Included) 2 - People Recommended EASY DIFFICULT The Assembly Rating is a 5-point system showing the level of effort needed to assemble a specific product.
- Page 2 America Furniture FOA Intro Thank you for your purchase! We hope you enjoy this new addition to your home for many years to come. Our commitment to providing quality products does not simply end when you purchase our product. We fully stand behind our products from start to finish. Our customer service department is available Monday –...
- Page 3 PRE ASSEMBLY INTRODUCTION We understand building ready-to-assemble furniture can be a challenging experience for some. To help avoid confusion, we have provided some helpful tips that may speed up the process. Teamwork ALWAYS have at least two people to help with transporting and assembling the product to avoid potential injury and/or damage.
- Page 4 4 / 11...
- Page 5 SOFA CM6495 #2 1pc #1 1pc #3 1set Chaise Seat Frame Arm(L&R) Sofa Seat Frame #6 8pcs #4 1pc #5 1pc Backrest (Short) Backrest (Long) Legs #7 1pc #A 34pcs Screw #8 x 60mm 5 / 11...
-
Page 6: Exploded View
Exploded View 6 / 11... - Page 7 CM6495 is packed in 5 cases Disignation Part Hardware Carton Sofa Seat Frame CM6495-1 Legs(4pcs) Backrest (Long) CM6495-2 Chaise Seat Frame #A x 34pcs Legs(4pcs) CM6495-3 CM6495-4 Backrest (Short) CM6495-5 Arm(L&R) (2pcs) 7 / 11...
- Page 8 ASSEMBLY INSTRUCTIONS Remove parts from the hidden compartments of the chaise (#1) and sofa (#2). #6 x4pcs #6 x4pcs #7 x1pc #A x34pcs Part #3 x1pc Part #4 x1pc Align and attach the brackets of the arm (#3L) to the bracket of the backrest (#4).
- Page 9 ASSEMBLY INSTRUCTIONS Align and attach the brackets of the chaise (#1) to the brackets of the arm (#3L) and backrest (#4). Part #1 x1pc Align and attach the bracket of the Part #3 x1pc arm (#3R) to the bracket of the Part #5 x1pc backrest (#5).
- Page 10 ASSEMBLY INSTRUCTIONS Part #2 x1pc Align and attach the brackets of the arms/backrest (#3R,5) to the brackets of the sofa (#2). Align and attach the brackets of the sofa (#2) to the brackets of the chaise (#1). 10 / 11...
- Page 11 ASSEMBLY INSTRUCTIONS Part #6 x8pcs Part #7 x1pc Hardware #A x34pcs Align legs (#6,7) to the bottom of the sectional, then secure by using screws (#A). There may not be pre- drilled holes. 11 / 11...
