- Page 1 MOP-TFT480272-43A-BLM-TPC Hardware Manual Revision 1.0...
-
Page 2: Revision History
Revision History Revision Date Description Author May 26, 2017 Initial Release Divino MOP-TFT480272-43A-BLM-TPC... -
Page 3: Table Of Contents
12.3 Static Charge Precaution .............................. 13 12.4 Packing ..................................13 12.5 Precautions during Operation ..........................13 12.6 Storage Recommendations ............................. 14 12.7 Safety Precautions ..............................14 13 Ordering ....................................15 13.1 Part Numbering Scheme ............................... 15 13.2 Options ..................................15 14 Contact ....................................15 MOP-TFT480272-43A-BLM-TPC... -
Page 4: General Information
The LED Life-time is defined as the estimated time to 50% degradation of initial brightness at Ta=25°C and IF =40mA. The LED lifetime could be decreased if operating IF is larger than 40mA, and increased if IF is less than 40mA. MOP-TFT480272-43A-BLM-TPC... -
Page 5: Touch Panel Characteristics
(at Ta=25°C) Item Description IC solution on TP Model GT911 Touch Count Max 5 point Display Resolution* 480*272 Interface Type * I2C Slave Address* 0x5D Origin of Coordinate* Top left corner Parameter Unit Interface Signal Voltage* Power Voltage* Power ripple* MOP-TFT480272-43A-BLM-TPC... -
Page 6: External Dimensions
6 External Dimensions Figure 1: MOP-TFT480272-43A-BLM-TPC Drawing MOP-TFT480272-43A-BLM-TPC... -
Page 7: Electro-Optical Characteristics
Instruments or compatible. For contrast ratio, Surface Luminance, Luminance uniformity and CIE, the testing data is based on TOPCON’s BM-7 or BM-5 photo detector or compatible. *Note 7: For TFT module, Gray scale reverse occurs in the direction of panel viewing angle. MOP-TFT480272-43A-BLM-TPC... -
Page 8: Interface Description
No connection YD(NC) No connection XL(NC) No connection YU(NC) No connection 8.2 CTP Interface Description Interface No. Name I/O Pin Connections Description RESET Reset low VDD/VCC Power Supply of CTP Ground State change interrupt Serial interface clock Serial interface date MOP-TFT480272-43A-BLM-TPC... -
Page 9: Ac Characteristics
VSD width Tvwh VSD setup time Tvsu VSD hold time Tvhd Data setup time Tdasu Data hold time Tdahd DE setup time Tdesu DE hold time Tdehd Time from VSD to 1 line HV mode By HDL[4:0] data input setting MOP-TFT480272-43A-BLM-TPC... -
Page 10: Data Timing
Symbol Unit Min. Typ. Max. DCLK frequency fclk VSD period time VSD display area VSD back porch VSD front porch Tvfp HSD period time DCLK HSD display area DCLK HSD back porch Thbp DCLK HSD front porch Thfp DCLK MOP-TFT480272-43A-BLM-TPC... -
Page 11: Power Sequence
10 Power Sequence 10.1 Power Up Sequence Figure 5: Power On Sequence 10.2 Power Down Sequence Figure 6: Power Off Sequence MOP-TFT480272-43A-BLM-TPC... -
Page 12: Inspection Criterion
11 Inspection Criterion 11.1 Description This specification is made to be used as the standard acceptance/rejection criteria for the MOP-TFT480272-43A-BLM-TPC. 11.2 Sample plan Sampling plan according to GB/T2828.1-2003/ISO 2859-1: 1999 and ANSI/ASQC Z1.4-1993, normal level 2 and based on: Major defect: AQL 0.65 Minor defect: AQL 1.5... -
Page 13: Lcd Pixel Defect
1. If the fold mark and linear scar for polarizer is visible with operating condition, the defect is judged with line judge 2. If the fold mark and linear scar for polarizer is visible with non-operating condition, the defect is judged with the above judgment standard. MOP-TFT480272-43A-BLM-TPC... -
Page 14: Handling Precautions
If the display area is pushed hard during operation, some font may be abnormally drawn but the LCD will return to normal after it is reset. Slight dew depositing on terminals can cause an electro-chemical reaction, damaging traces and resulting in an open circuit. Usage under the maximum operating temperature, 50%Rh or less is required MOP-TFT480272-43A-BLM-TPC... -
Page 15: Storage Recommendations
If any liquid leaked out of a damaged glass cell, and comes in contact with your hands, please wash it off well with soap and water MOP-TFT480272-43A-BLM-TPC... -
Page 16: Ordering
TFT 480 13.2 Options Table 2: Parallel Part Options Designator Options Product Line MOP: Matrix Orbital Parallel Display Screen Type TFT: Graphic TFT Display Columns 480: Four Hundred Eighty Pixel Columns Display Rows 272: Two Hundred Seventy Two Pixel Rows Display Size 43: 4.3”... - Page 17 TFT Displays & Accessories Click to view products by manufacturer: Matrix Orbital Other Similar products are found below : OAI-80038AA-2013-A HDA430T-3G1H EA CARREDIPTFT02 NL6448BC20-21D NB7W-KBA04 NB-ATT01 NB5Q-ATT01 NB5Q- KBA04 NB-CN001 NL12880BC20-05 NL8060BC26-35C TCG104SVLQAPNN-AN20 OAI-80038AA-2008-A 315-U004B15300 UMSH- 8596MD-34T (REV D) 98-0003-3490-8 1044278 1029309 1060549 DE 127-TU-30/7,5 DE 128-TU-20/7,5 EP-LK007TFTPCAP FR7.0A00 RC2002A-TIG-CSX NL6448BC2021C TX14D23VM5BAA TCG121WXLRXVNNANX35 EIC-LCD-1080P T272480C07VR01 1060632 TCG070WVLPAANN-AN50 TCG035QVLPDANN-GN50 1060630 RFE430V-AIW-DNG T-55619GD065J-LW-ABN NHD-1.8-128160EF-...
