B8-S manual
Specification:
Processor
Memory
Storage
Display
OS
Audio
Reader
Magnetic Card Reader
Smart Card Reader
Contactless
I/O
RS-232/USB
AUX
LAN
DC in
SAM
Debug console
LED indicator
Buttons
Communication
Ethernet
Environment
Operating Temperature
Storage Temperature
Humidity
Reliability Requirements
MTBF
ESD
Button
UIC
BEZEL8-S Credit card Reader
Specification
Microchip SAMA5D23
DDR3 256MB
QSPI-Flash 32MB
Graphic LCD @ 128 x 64
Linux
Buzzer≧70dB @ 10cm
Bi-directional, support triple tracks
ISO7811
Speed 5 to 40 IPS
1,000,000. swipe times
ISO7816, T=0 , T=1
EMV Level 1, Support 5V/3V
500,000. inserted times
Support ISO 14443 Type A/B and Mifare with 4 LEDs, EMV contactless L1
USB(VCOM) or RS232, Cable-select
RS232, as auxiliary port
10BASE-T/100BASE-T ethernet
5V, 500mA
x 1
Special cable through auxiliary port
x 4 for RFID, 1 set for MSR, 1 set for ICC
Rubber button x 2
x 1 (Optional)
-20°C to +70°C
-30°C to +80°C
5% to 90%
50,000 hours
Contact：+/- 8KV
Air：+/-15KV
Centurion/ Metal card：+/- 8KV(insert half of the card)
1M times
BEZEL8-S
Page 1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for UIC BEZEL8-S
Summary of Contents for UIC BEZEL8-S
- Page 1 B8-S manual BEZEL8-S BEZEL8-S Credit card Reader Specification: Specification Processor Microchip SAMA5D23 Memory DDR3 256MB Storage QSPI-Flash 32MB Display Graphic LCD @ 128 x 64 Linux Audio Buzzer≧70dB @ 10cm Reader Bi-directional, support triple tracks ISO7811 Magnetic Card Reader Speed 5 to 40 IPS 1,000,000.
- Page 2 B8-S manual IP Level IP54 IK Level IK06 UV exposure resistance Installation guide(RS232 Interface) Plug the RS232 cable to the port of PC or system The reader will boot up automatically Photos: Page 2...
- Page 3 B8-S manual FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
