- Page 1 MTA-3080 8" Risc-based IoT Terminal User's Manual Version 1.0...
- Page 2 This page is intentionally left blank. - II -...
- Page 3 Revision History Version Release Time Description 2015.11 Initial release - i -...
- Page 4 Copyright Copyright © 2015 Midas Touch, Inc. All Rights Reserved. This document contains proprietary information protected by copyright. No part of this manual may be reproduced by any mechanical, electronic, or other means in any form without prior written permission of the manufacturer.
-
Page 5: Table Of Contents
Contents Contents Preface ......................v Declaration of Conformity ................... v CE ....................... v FCC Class B ....................v RoHS ......................vi SVHC / REACH ..................vi Safety Symbols ....................vii Important Safety Instructions ................vii General Cleaning Tips ....................ix Cleaning Tools ..................... - Page 6 Contents 3.2.1 Using the Quick Settings Panel ............18 3.3 Configurations .................... 19 3.3.1 Configuring Your SIM Card (Optional) ..........19 3.3.2 Enabling Wi-Fi and Connecting to a WLAN ........20 3.3.3 Enabling Bluetooth and Pairing with Bluetooth Device ....20 3.3.4 Enabling the Ethernet Feature ............
-
Page 7: Preface
This product has passed the CE test for environmental specifications when shielded cables are used for external wiring. We recommend the use of shielded cables. This kind of cable is available from Midas Touch. Please contact your local supplier for ordering information. -
Page 8: Rohs
Consult the dealer or an experienced radio/TV technician for help. RoHS Midas Touch, Inc. certifies that all components in its products are in compliance and conform to the European Union’s Restriction of Use of Hazardous Substances in Electrical and Electronic Equipment (RoHS) Directive 2002/95/EC. -
Page 9: Safety Symbols
Preface Safety Symbols This symbol of “CAUTION” indicates that there is a danger of injury to the user or a risk of damage to the product, should warning notices be disregarded. This symbol indicates electrical warning. Important Safety Instructions Read these safety instructions carefully: Read all cautions and warnings on the equipment. - Page 10 Preface 13. If the equipment will not be used for a long time, disconnect it from the power source to avoid damage by transient overvoltage. 14. Never pour any liquid into openings. This may cause fire or electrical shock. 15. Never open the equipment. For safety reasons, the equipment should be opened only by qualified service personnel.
-
Page 11: General Cleaning Tips
Preface Do not use the power adapter that isn’t made for the equipment. Supplying the equipment with inappropriate voltage may cause harm to or burn the equipment. To prevent possible hearing damage, do not listen at high volume levels for long periods General Cleaning Tips You may need the following precautions before you begin to clean the device. -
Page 12: Recommended Cleaning Procedures
Preface • Cloth: A piece of cloth is the best tool to use when rubbing up a component. Although paper towels or tissues can be used on most hardware as well, we still recommend you to rub it with a piece of cloth. •... -
Page 13: Disposing Of The Equipment
Preface Disposing of the Equipment • Within the European Union EU-wide legislation, as implemented in each Member State, requires that waste electrical and electronic products carrying the mark (left) must be disposed of separately from normal household waste. This includes monitors and electrical accessories, such as signal cables or power cords. -
Page 14: Additional Information & Technical Support
Preface Additional Information & Technical Support You can download the related technical documents such as datasheet and user’s manual as well as driver on our website. Please do not hesitate to call or e-mail our customer service when you still cannot get the information you need. -
Page 15: Chapter 1 Introduction
Chapter Introduction Chapter 1 Introduction - 1 -... -
Page 16: Product Highlights
Upon opening the package, carefully inspect the contents. If any of the items is missing or appears damaged, contact your local dealer or distributor. The package should contain the following items: MTA-3080 8" Risc-based IoT Terminal Terminal Block 2-pin DC Terminal Block, Plug, Green... -
Page 17: Optional Accessories
Introduction 1.3 Optional Accessories Power 12V/2A AC/DC Power Adapter w/ 2-pin power terminal Antenna 3G / 4G UMTS/HSDPA/HSUPA 900(850)/2100(1900)MHz ,GSM/ 3G Module GPRS/EDGE 850/900/1800/1900MHz FDD LTE:Band 1, Band 3, Band 8 TDD LTE: Band 39, Band 40, Band 41 (38) DC-HSPA+/HSPA+/HSPA/UMTS:Band 1, Band 9, Band 5, 4G Module Band 8... -
Page 18: Parts Of The Device
18 Wi-Fi / Bluetooth antenna connector Micro SIM (3FF) slot 19 3G/4G antenna connector* 10 UART connector 20 VESA 75 mounting holes (M3 size) *3G, 4G and NFC are optional modules and your MTA-3080 may not come with these components. - 4 -... -
Page 19: Dimensions
Introduction 1.5 Dimensions 218.16 46.50 200.31 45.00 176.64 13.90 11.1 9.42 35.8 55.6 188.20 141.10 7.12 47.10 75.00 4.00 67.40 35.33 169.00 180.20 Unit: mm 202.44 - 5 -... -
Page 20: Specifications
Introduction 1.6 Specifications System Quad-core ARM Cortex-A9 1.6GHz Android™ v4.4 Memory 1GB LPDDR3 Flash 16GB eMMC Peripherals and Devices Front Camera 2.0 megapixel camera 1 x built-in speaker (2W) Audio 1 x built-in microphone Wireless WCDMA / CDMA / TDSCDMA / LTE 1 x micro SIM (3FF) slot (optional) GPS + BeiDou... - Page 21 Introduction one MIC-fidelity audio input update hole updade program hole Power on switch on/off switch able ,Toggle Switch LCD Display Physical size 8 inches Resolution 1024(W) x 600(H) Technology High definition and high brightness LCD display Colors 16M Colors,24bit Touchscreen GG Capacitive, 5-points Multi-touch Power Input 2-pin terminal block...
-
Page 22: Chapter 2 Installation
Installation Chapter Installation Chapter 2 Installation - 8 -... -
Page 23: Microsd Card Installation
To remove the microSD card, just push the microSD card in to eject it from its slot. 2.2 Wi-Fi/Bluetooth Antenna Installation The MTA-3080 comes with a Wi-Fi/Bluetooth antenna to help increasing the signal strength. To use the antenna, attache the Wi-Fi/Bluetooth antenna to the Wi-Fi/Bluetooth antenna connector as shown below. -
Page 24: Sim Card And 3G/4G Antenna Installation (Optional)
SIM card and antenna to the MTA-3080. The MTA-3080 accepts micro SIM (3FF) card. To install a SIM card to the device, locate the SIM card slot on the side and insert the card following the direction as shown in the icon. -
Page 25: Power Connection
DC power connection. 2.4.1 Using the DC Terminal Block Connector The MTA-3080 comes with one 2-pin DC terminal block connector to connect power to DC power connector on the device. To use the block connector: 1. -
Page 26: Using The Power Adapter (Optional)
Installation 2.4.2 Using the Power Adapter (Optional) If your MTA-3080 comes with the optional AC-DC power adapter, just connect the 2-pin terminal block plug of the power adapter to the 2-pin terminal block receptacle on the device. Then connect the adapter to a power source. -
Page 27: Mounting The Device
Using the Device 2.6 Mounting the Device The device is VESA 75-compliant and can be mounted on a VESA 75-compliant mounting kit using M3 screws. Or you can use the mounting holes on either side of the device to mount it. 75 mm Mounting holes... - Page 28 This page is intentionally left blank. - 14 -...
-
Page 29: Chapter 3 Using The Device
Using the Device Chapter Using the Device Chapter 3 Using the Device - 15 -... -
Page 30: Turning On/Off The Device
Using the Device 3.1 Turning On/Off the Device Once the device is connected to a power supply, toggle the power switch to ON to turn on the device. Then the device will enter the Android system directly. To turn off the device, toggle the power switch to OFF. When prompted, tab Power off and then OK to shut down the device. - Page 31 Using the Device The table below describes the elements on a typical Home screen: Element Descriptions • Tap an item on this screen to launch that item. • To delete an icon or widget, tap and hold that item until the remove symbol X appears on the top of the screen.
-
Page 32: Using The Quick Settings Panel
Using the Device 3.2.1 Using the Quick Settings Panel Swiping down the Status Bar will bring up a Quick Settings panel where you can quickly access some most commonly used settings and features. To enable/disable a feature or switch between available options , simply tap the intended tile. It appears dimmed when disabled and brightened when enabled. -
Page 33: Configurations
3.3.1 Configuring Your SIM Card (Optional) After you insert the SIM card to the MTA-3080 for the first time and power on the MTA-3080, depending on your mobile network carrier you might be guided to activate the account and connect to your mobile network. -
Page 34: Enabling Wi-Fi And Connecting To A Wlan
Using the Device 3.3.2 Enabling Wi-Fi and Connecting to a WLAN Before using the Wi-Fi feature, make sure your device is connected with the Wi-Fi antenna. To use the Wi-Fi feature, switch on the Wi-Fi function on the Settings page. Then tap a network to connect to it. - Page 35 AVAILABLE DEVICES list, tap SEARCH FOR DEVICES in the upper right corner. The MTA-3080 proceeds to scan for any Bluetooth device in range. Then it displays the names of the device(s) found. 3. Tap the device you want to pair with. When the Bluetooth pairing request dialog box appears, tap Pair.
-
Page 36: Enabling The Ethernet Feature
Using the Device 3.3.4 Enabling the Ethernet Feature If the device is connected to a network through the LAN port, you will need configure the network settings according to your network environment. To configure the network settings: 1. On the Settings page, tap More > Ethernet. 2. -
Page 37: Enabling Location Service (Optional)
3.3.6 Enabling and Using the NFC Features (Optional) The NFC reader is at the lower left corner of the MTA-3080. When you tap other NFC devices, tags, or readers, the NFC areas of both devices should be close to one another so that the connection can be established. - Page 38 NFC-enabled and unlocked. Then bring the NFC areas of the two devices together. When prompted with a message "Touch to beam", touch the screen of the MTA-3080 to begin the beaming process. By turning on NFC feature, you are ready to use the tap & pay feature to pay for purchases at merchants that accept contactless payments.
