MEDIUM FULL MOTION MOUNT
REDMC60
INSTRUCTION MANUAL
MANUAL DE INSTRUCCIONES
MANUEL D'INSTRUCTIONS
CAUTION: DO NOT EXCEED MAXIMUM
LISTED WEIGHT CAPACITY. SERIOUS
!
CAUTION:
INJURY OR PROPERTY DAMAGE MAY
THE MAXIMUM LOADING WEIGHT
OCCUR!
IS 60 LBS. USE WITH PRODUCTS HEAVIER THAN
THE MAXIMUM WEIGHT INDICATED MAY RESULT IN
Large Full Motion Mount
INSTABILITY AND POSSIBLE PERSONAL INJURY.
Max Scree n Size: 70"
Max Screen Size: 55"
Max weight: 125lbs
V4
V1
P 1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for RED ATOM REDMC60
Summary of Contents for RED ATOM REDMC60
- Page 1 MEDIUM FULL MOTION MOUNT REDMC60 INSTRUCTION MANUAL MANUAL DE INSTRUCCIONES MANUEL D’INSTRUCTIONS CAUTION: DO NOT EXCEED MAXIMUM LISTED WEIGHT CAPACITY. SERIOUS CAUTION: INJURY OR PROPERTY DAMAGE MAY THE MAXIMUM LOADING WEIGHT OCCUR! IS 60 LBS. USE WITH PRODUCTS HEAVIER THAN...
-
Page 2: Tools Needed
DISCLAIMER – WARNING INFORMATION Disclaimer –. RED ATOM has extended every effort to ensure to accuracy and completeness of this manual. However, RED ATOM does not claim that the information covers all installation and or operational variables. The information contained in this document is subject to change without notice or obligation of any kind. Regarding the information contained herein, RED ATOM makes no representation of warranty, expressed or implied, and assumes no responsibility for accuracy, sufficiency, or completeness of the information contained in this document. - Page 3 MONITOR PLATE AND ADAPTERS Use diagrams to determine which mounting configuration is needed to attach Monitor Plate (with or without adapters) to the back of flat panel. Please check flat panel wall mounting compatibility before proceeding with installation. Pay attention to below the correct installation pattern of adapters A and B.Confuse them may cause TV enable to be mounted correctly.
-
Page 4: Hardware Part Numbers
HARDWARE PART NUMBERS M4 x 12 M5 x 12 M6 x 15 M8 x 15 M4 x 25 M5 x 25 M6 x 25 M8 x 25 STEEL SQUARE 8 mm LAG PHILLIPS STEEL ANCHOR END COVER WASHER WASHER SPACER SCREWS BOLTS WASHER... - Page 5 STEP 1- REMOVE MONITOR PLATE FROM MOUNT Remove and save Phillips head screws and washers. Screws and washers will be used to reattach monitor plate in step 4. STEP 2A- MONITOR PLATE ATTACHMENT Connect monitor plate to flat panel Conecte el adaptador al monitor Connectez l'adaptateur au moniteur...
- Page 6 STEP 2B- MONITOR ADAPTERS ATTACHMENT TO MONITOR PLATE Connect monitor plate with adapters to flat panel Conecte el adaptador al monitor Connectez l'adaptateur au moniteur STEP 2C- CURVED BACK FLAT PANEL (MONITOR PLATE) Connect monitor plate to flat panel Conecte el adaptador al monitor Connectez l'adaptateur au moniteur 5mm spacers to be used when back of panel is curved or when...
- Page 7 STEP 2D- USE M8 STEEL WASHER IF THE PHILLIPS SCREWS FROM THE MONITOR KIT ARE TOO LONG Diagrams show three options for using additional washers if hardware screws are too long to properly tighten into back of flat panel television. B or C B or C B or C...
- Page 8 STEP 3A- WOOD STUD (CONCRETE INSTALLATION SKIP TO 3B) Find stud and mark edge and center locations Ubique el panel y marque las ubicaciones de los bordes y el centro. DRILL BIT Repérez l'emplacement d'une poutre, puis marquez l'emplacement des bords et du centre de cette poutre. NOT INCLUDED STEP 3A- DRILL PILOT HOLES AND MOUNT WALL PLATE Mount wall plate...
- Page 9 STEP 3 B – SOLID CONCRETE Drill pilot hole Solid Concrete Realice el agujero piloto Concreto sólido Percez le trou de guidage Béton massif DRILL BIT NOT INCLUDED 3/8” STEP 3B – DRILL PILOT HOLE AND MOUNT WALL PLATE Slide plastic end cap on top and bottom if wall plate...
- Page 10 STEP 4- ATTACH PANEL TO MOUNT Hang with monitor attached Heavy, Assistance Cuelgue con el monitor adherido. Required Accrochez avec le moniteur installé. TRES LOURD ! Cette etape requiert deux personnes !PESADO! Necesitara ayuda para realizar esta operacion ARM ASSEMBLY, LEVEL, AND TILT STEP 4- ADJUST TILT TENSION/ POST INSTALLATION LEVEL Locking mechanism Mecanismo de fijación...
-
Page 11: Warranty Information
Para obtener el servicio de garantía, comuníquese con el servicio de Atención al cliente de RED ATOM. Escribanos an info@redatomproducts.com. Deberá proporcionar el recibo original. Si fuera necesario enviar el producto a RED ATOM para revisarlo, los gastos de envío correrán por su cuenta. El producto de reemplazo que se le envíe se le devolverá... - Page 12 Page 12 is intentionally blank...
