Land Pride Accu-Z ZT360 Operator's Manual
  1. Manuals
  2. Brands
  3. Land Pride Manuals
  4. Lawn Mower
  5. Accu-Z ZT360
  6. Operator's manual
Land Pride Accu-Z ZT360 Operator's Manual

Land Pride Accu-Z ZT360 Operator's Manual

Zero turn mowers
Hide thumbs

Advertisement

Quick Links

Download this manual
Zero Turn Mowers
ZT360 & ZT372
35371
Table of Contents
Read the Operator's Manual entirely. When you
!
see this symbol, the subsequent instructions and
warnings are serious - follow without exception.
Your life and the lives of others depend on it!
Cover photo may show optional equipment
not supplied with standard unit.
© Copyright 2017
Accu-Z
357-610M
Operator's Manual
Printed
3/16/17
Parts Manual QR Code
®

Advertisement

loading
Need help?

Need help?

Do you have a question about the Accu-Z ZT360 and is the answer not in the manual?

Questions and answers

Related Manuals for Land Pride Accu-Z ZT360

Summary of Contents for Land Pride Accu-Z ZT360

  • Page 1 Table of Contents Zero Turn Mowers ® ZT360 & ZT372 Accu-Z 35371 357-610M Operator’s Manual Read the Operator’s Manual entirely. When you see this symbol, the subsequent instructions and warnings are serious - follow without exception. Your life and the lives of others depend on it! Cover photo may show optional equipment not supplied with standard unit.
  • Page 2 Land Pride assumes no responsibility for errors or omissions. Neither is any liability assumed for damages resulting from the use of the information contained herein. Land Pride reserves the right to revise and improve its products as it sees fit. This publication describes the state of this product at the time of its publication, and may not reflect the product in the future.
  • Page 3 The QR code below will link you to Manual for this equipment. Download the appropriate App on your camera phone, available dealers for Land Pride open the App, point your phone on the QR code, and take a picture. products.
  • Page 4 Table of Contents Important Safety Information These are common practices that may or may not be applicable to the products described in this manual. Avoid High Prepare for Emergencies Tire Safety Pressure Fluids Hazard  Tire changing can be dangerous ...
  • Page 5 Table of Contents Important Safety Information These are common practices that may or may not be applicable to the products described in this manual.  Repairs or maintenance requiring engine Practice Safe Maintenance power should be performed by trained  Understand safe and correct maintenance personnel only.
  • Page 6 Spray soapy water onto the cleaned area. all damaged or missing labels. Order new labels from your Peel backing from label and press label firmly onto the nearest Land Pride dealer. To find your nearest dealer, surface. visit our dealer locator at www.landpride.com.
  • Page 7 Table of Contents Important Safety Information 35374 838-307C Warning: Moving Parts 35374 838-310C Warning: General 838-815C 35373 Warning: Rollover Hazard ® 3/16/17 ZT360 & ZT372 Accu-Z Zero Turn Mowers 357-610M...
  • Page 8 Table of Contents Important Safety Information 838-308C Warning: Rotating Blade Hazard 35373 838-306C Warning: Do not operator without deflector 35373 838-833C Warning: Fuel (Imbedded in Fuel Tank) 35375 840-335C Anti-slip step pad 35374 ® ZT360 & ZT372 Accu-Z Zero Turn Mowers 357-610M 3/16/17...
  • Page 9 Table of Contents Important Safety Information 35406 Beneath Pulley Shields 35374 818-543C Danger: Guard Missing 3 - Places On The Deck 1 - Place Beneath Floor Pan Beneath Floor Pan 848-268C Warning: Safe Operating Instructions 35373 838-444C Danger: Muffler Hot (Both Sides of Engine) 33763 ®...
  • Page 10 Table of Contents Introduction Introduction Land Pride welcomes you to the growing family of new Terminology product owners. “Right” or “Left” as used in this manual is determined by facing forward while sitting in the operator seat unless This mower has been designed with care and built by otherwise stated.
  • Page 11 2. If you are still not satisfied, seek out the owner or general manager of the dealership, explain the problem, and request assistance. 3. For further assistance write to: Land Pride Service Department 1525 East North Street P.O. Box 5060 Salina, Ks. 67402-5060 E-mail address lpservicedept@landpride.com...
  • Page 12 Table of Contents Section 1: Assembly & Set-up Section 1: Assembly & Set-up Uncrating Instructions The shipping crate is assembled together with nails. It can be disassembled by prying or cutting the lumber apart. Be careful not to scratch, dent, or cut the mower and seat while uncrating.
  • Page 13 Table of Contents Section 1: Assembly & Set-up Spring Loaded Seat Release Latch Discharge Chute Assembly Refer to Figure 1-2: Refer to Figure 1-3: The Zero Turn Mower is shipped with carriage bolts (#2) and hex flange locknuts (#3) attached to the deck in the WARNING location shown.
  • Page 14 Table of Contents Section 1: Assembly & Set-up Folding ROPS Electrical Cable Connection Refer to Figure 1-5: DANGER WARNING Low structures can make contact with the ROPS and flip the mower over backwards. Fold ROPS down when driving under Incorrect battery cable connections can damage the mower’s low structures such as tree limbs and doorways.
  • Page 15 Table of Contents Section 1: Assembly & Set-up Engine Preparations Check engine oil level at the dipstick. Add oil if below full mark. Do not overfill. Refer to Engine Operator’s Manual for oil recommendation and to “Engine Oil & Oil Filter” on page 44 in this manual. NOTE: Mowers are shipped from the factory without fuel in the fuel tanks.
  • Page 16 Table of Contents Section 2: Operating Procedures Section 2: Operating Procedures Mower Features Refer to Figure 2-1: Your Zero Turn Mower is designed with innovative and comfortable. Below is a list of major features to be state-of-the-art features. Knowing the location and how reviewed in this section.
  • Page 17 Table of Contents Section 2: Operating Procedures Operating Checklist pulling back on the control levers. Reduce engine rpm only when mower is not traveling and just before Hazard control and accident prevention are dependent engaging the cutting blades. upon awareness, concern, prudence and proper training involved in operation, transport, maintenance, and IMPORTANT: Always operate throttle at full engine storage of the riding mower.
  • Page 18 Table of Contents Section 2: Operating Procedures Park Brake 35403 Blade Engagement Switch (OFF) Refer to Figure 2-3 & Figure 2-4: The park brake lever is linked to the wheel motors. The Park Brake (ON) rear wheels are kept from turning when park brake lever is pulled back or to the (ON) position.
  • Page 19 Table of Contents Section 2: Operating Procedures Accessing Area Beneath Floor Pan Hand Holds Refer to Figure 5-2: Deck components located under the floor pan (#2) can be accessed easily by raising the floor pan up. WARNING The floor pan must always be in the down position before starting the mower.
  • Page 20 The following steps are correct procedures for starting indicator (#4) is from 1" to 5" in 1/4" increments. the engine. If difficulty is encountered, contact your local Land Pride dealer. Set deck at transport height. See “Transport Height” instructions above.
  • Page 21 Rapid movement of control IMPORTANT: The operator must be on the seat levers could result in a reaction that can cause serious injury. when testing switches. Contact your local Land Pride dealer if the problem cannot be resolved. DANGER Start mower engine per instructions in the section on Never make sudden speed changes from reverse to forward.
  • Page 22 Table of Contents Section 2: Operating Procedures Front of Mower Faces This Direction 25880 Figure 2-9 To Start and Increase Speed To Steer Refer to Figure 2-9 on page 20: Refer to Figure 2-9: • After starting the engine, release park brake, and engage To Steer Straight While Traveling Forward control levers by moving handles fully (IN).
  • Page 23 Table of Contents Section 2: Operating Procedures Towing Using The Rear Hitch DANGER Do not mow with people present in the mowing area. WARNING Projectiles can suddenly, without warning, discharge from under the mower deck causing serious injury or death. Do not attach a trailer, implement, or other device to the mower hitch that will produce negative tongue weight.
  • Page 24 Table of Contents Section 2: Operating Procedures  Do not drive too close to water. The surface near water is often soft, wet and unstable. The grass can be wet WARNING and slippery. Use a walk behind mower or string Always wear hearing protection, safety glasses, clothing that trimmer when close to water.
  • Page 25 Manual and completing the Operator’s Checklist, you are open bypass valves on the transaxles. almost ready to begin mowing. The Land Pride Zero Turn Mowers are designed to deliver Approach mower from the front and spread steering professional cutting quality, while delivering high levers fully apart.
  • Page 26 Some repairs require the assistance of a trained service 1/8" from end of threaded mount (#6). mechanic and should not be attempted by unskilled personnel. Consult your Land Pride service center when 3. Tighten jam nut (#4) against engine support plate assistance is needed.
  • Page 27 Table of Contents Section 3: Adjustments 5. If brake lever (#1) applies too hard, continue with step 5a below: a. Loosen nut (#3) one-half turn at a time until applied brake lever pressure (#1) is satisfactory and then tighten nut (#2) against lever housing. b.
  • Page 28 Table of Contents Section 3: Adjustments 3. If needed, remove fan mounting hardware and fan (#4) if jam nuts (#3) are not easily accessible. 4. Loosen jam nuts (#3) at both ends of linkage rod (#1) by 5 or more full turns (approximately 1/4"). One jam nut will be right-hand thread and the other will be left-hand thread.
  • Page 29 Table of Contents Section 3: Adjustments Upper Control Lever IMPORTANT: Make sure lower control levers have been adjusted before adjusting upper control levers. See page 26 for lower control lever adjustments. The upper control levers may be adjusted while in neutral position for height, reach, and forward travel to fit the operator’s steering comfort zone.
  • Page 30 Table of Contents Section 3: Adjustments Belt Tensioning There are two drive belts on the ZT3 mower. The ground drive belt is the upper belt that powers the rear wheels (see Figure 3-8). The deck drive belt is the lower belt and powers the deck blades (see Figure 3-10).
  • Page 31 Table of Contents Section 3: Adjustments Left Blade Spindle 3" 35385 Deck Cutting Height & Leveling (60" Deck Shown) Figure 3-11 Refer to Figure 3-11: 6. Refer to Figure 3-12 on page 30: Remove all tension on deck lift assist springs (#7) as follows. IMPORTANT: To remove &...
  • Page 32 Table of Contents Section 3: Adjustments 35388 Anti-Scalp Roller Adjustment Figure 3-13 Anti-Scalp Rollers Refer to Figure 3-13: Spring tension eyebolts (#3) may need The mower has four anti-scalping rollers. Their purpose adjusted for customer preference. 35387 is to minimize scalping of the ground when mowing on rough, uneven terrain.
  • Page 33 Table of Contents Section 3: Adjustments 5. Reattach anti-scalp rollers (#8B & #8C) to mounting Hand Holds bracket (#2), with carriage bolt (#5), flat washer (#7), and hex nylock nut (#6). Tighten nylock nut to the correct torque. 6. At the left-hand anti-scalp roller (#8A), remove nylock jam nut (#6) and carriage bolt (#4).
  • Page 34 Land Pride’s Light Kit. Z Mower Light Kit ..... . 357-160A...
  • Page 35 Table of Contents Section 4: Options & Accessories Lift Jack Refer to Figure 4-4: Make accessing the underside of your deck easier with a front mount Lift Jack. It is especially useful for cleaning the deck underside, accessing the cutting blades and making front tire repairs.
  • Page 36 Regular maintenance is the best prevention for costly downtime or expensive, premature repair. The following Do not alter or replace parts with other brands on Land Pride pages contain suggested maintenance information and products. Other brands may not fit properly or meet OEM schedules which the operator should follow on a routine specifications.
  • Page 37 Otherwise, replace every 200 hours or 2 years whichever comes first. 5. Inspect transaxles for oil leaks. Have your nearest Land Pride service center make repairs as needed. 6. Replace air cleaner filter element if damaged, every 200 hours or every season (whichever comes first). Replace more frequently when used in dusty conditions.
  • Page 38 Table of Contents Section 5: Maintenance & Lubrication Tires Electrical System Refer to Figure 5-2: IMPORTANT: Use only tires recommended by Land The mower is equipped with a 12 volt negative ground Pride. Solid fill tires are not to be used on Zero Turn electrical system powered by a battery located under the Mowers.
  • Page 39 Table of Contents Section 5: Maintenance & Lubrication WARNING Do not overfill battery. Electrolytes may overflow and damage paint, wiring and structure. Use soap and water when cleaning the battery. Be careful not to get soap and water into 20 Amp Fuse the battery.
  • Page 40 Table of Contents Section 5: Maintenance & Lubrication Belt Maintenance Deck Drive Belt Removal & Installation Refer to Figure 5-6: DANGER Park mower on a flat surface. Before raising floor pan or removing pulley guards, make 2. Make sure blade engagement switch is (OFF), certain blade engagement switch has been shut off, deck has control levers are fully (OUT), park brake is (ON) and been properly blocked up, engine has been shut off, and switch...
  • Page 41 Table of Contents Section 5: Maintenance & Lubrication 6. Release tension on ground drive belt (#10) by pulling Ground Drive Belt Removal & Installation on pump idler arm (#1) and carefully removing Park mower on a flat surface. belt (#10) from take-up pulley (#8). 2.
  • Page 42 If expansion tanks are properly filled with oil, have your nearest authorized Land Pride service department check the units and make necessary repairs before putting the mower back into service.
  • Page 43 (#4). See “Hydrostatic Transaxle filters are required with each oil change. They may be Specifications & Capacities” on page 53 for purchased from your nearest Land Pride dealer. See specified oil type and quantity. page 53 for filter part numbers.
  • Page 44 10% ethanol. Do not mix oil with gasoline. 3. Close both bypass valves by rotating them horizontally to “RUN”. Land Pride recommends adding correct amounts of gas 4. With engine running and control levers in neutral, stabilizer/conditioner in the fuel. For best results, follow slowly move levers forward and rearward 5 to 6 times.
  • Page 45 Drain Fuel Tank System Refer to Figure 5-11: All Land Pride Zero Turn Mowers are EPA compliant as of Park unit on a flat surface. Make sure blade January 1, 2012 production date and include a decal engagement switch is (OFF), both control levers are located on right side of engine stating the following: “This...
  • Page 46 Table of Contents Section 5: Maintenance & Lubrication Engine Oil & Oil Filter Change Engine Oil See “Engine Specifications & Capacities” on page 53 Refer to Figure 5-12: and “Engine Operator’s Manual” for oil type, capacity, Park unit on a flat surface. Make sure blade and maintenance schedule.
  • Page 47 Table of Contents Section 5: Maintenance & Lubrication Engine Air Filter Rain Cap - Positioned Vertically Refer to Figure 5-13: on Top of Air Filter Canister. A specially designed dry filter is standard equipment and supplies clean combustion air to the engine. Perform Air Filter Inner Element engine air filter maintenance per the Engine Operator’s Manual and “Maintenance Schedule”...
  • Page 48 The air filter warranty expires upon cleaning of a dust induced engine damage. See “Engine or servicing a used filter in any manner. Land Pride Specifications & Capacities” on page 53 for Land Pride does not warranty a dust induced engine damage if a air filter replacement numbers.
  • Page 49 Table of Contents Section 5: Maintenance & Lubrication Mower Blade Maintenance Blade Sharpening Blade Inspection Check mower blades daily, they are the key to power DANGER efficiency and a well groomed turf. Keep them sharp as a Keep blades balanced when sharpening. An unbalanced blade dull blade will tear rather than cut grass, leaving a brown may come loose and fly out from under the deck.
  • Page 50 Table of Contents Section 5: Maintenance & Lubrication Refer to Figure 5-18: Refer to Figure 5-20: 6. Remove an equal amount of material from each end NOTE: New mower blades are furnished with of the blade to keep blade in balance. Check blade cutting edge parallel with back of blade.
  • Page 51 A coating of oil may also be mower after storing it for a season: applied to the deck underside to minimize oxidation. 3. Clean and touch up all scrapes with Land Pride spray IMPORTANT: Do not use a high pressure washer on paint.
  • Page 52 Table of Contents Section 5: Maintenance & Lubrication Lubrication Points Lubrication Multi-purpose Multi-purpose Multi-purpose Intervals in hours at which Legend spray lube grease lube oil lube lubrication is required Hours Left Blade Spindle Access through rubber slit in pulley cover. 1 - Zerk Type of Lubrication: Multi-purpose Grease Quantity = As required...
  • Page 53 Table of Contents Section 5: Maintenance & Lubrication Hours Deck Struts Located beneath floor pan 2 - Zerks (One on each deck strut) Type of Lubrication: Multi-purpose Grease Quantity = As required 35400 100/M Hours Deck Lift Points Located above deck (Deck removed for clarity) 4 - Zerks (2 per side) Type of Lubrication: Multi-purpose Grease Quantity = As required every 100 hours or monthly,...
  • Page 54 Table of Contents Section 5: Maintenance & Lubrication Hours ® Tele-Caster Spindle Zerk Located on spindle of caster wheel 2 - Zerks (One on each caster wheel) Quantity = As required (See note in illustration) 35399 Note: Remove Slotted Hex Head Screw. Pump Multi-purpose Grease in Grease Zerk Until Grease comes out of this Screw hole.
  • Page 55 Table of Contents Section 6: Specifications & Capacities Section 6: Specifications & Capacities Engine Specifications & Capacities Mower Model No ZT360 & ZT372 Engine Manufacture Kawasaki Horsepower Engine Model Type FX850V 54.3 ft. lbs. Max Torque (73.6 N.m) Charging System 12-volt, 13 amp w/Kawaski Engine Starter 12-volt (.8 KW) electric starter w/Kawaski Engine...
  • Page 56 Table of Contents Section 6: Specifications & Capacities General Specifications & Capacities Mower Model No ZT360 ZT372 Overall Width (Chute Down) 74 1/4" 86 1/2" Overall Width At Rear Tires 52" 56" At Deck 74 1/4" 86 1/2" Overall Length With ROPS Up 90 1/4"...
  • Page 57 Table of Contents Section 6: Specifications & Capacities ZT360 = 74 1/4" 74-1/4 " ZT372 = 86 1/2" " 90 1/4" 90-1/4 " " 75" 49-1/4 " 49 3/4" 95 1/2" " 35405 ® 3/16/17 ZT360 & ZT372 Accu-Z Zero Turn Mowers 357-610M...
  • Page 58 Table of Contents Section 7: Features & Benefits Section 7: Features & Benefits ZT360 & ZT372 Models Features Benefits Cutting width of 60" or 72" Sized right and priced right for ranch, estate owners, and commercial operators. Cutting height of 1" to 5" Provides a good range of cutting heights in 1/4"...
  • Page 59 Table of Contents Section 7: Features & Benefits ZT360 & ZT372 Models Features Benefits Muffler is hidden and tucked down under to reduce noise and provide protection against Isolated exhaust muffler burns. Ergonomically designed Instrumentation and console controls are positioned for easy visual or fingertip access. control console Hour meter Measure actual engine run time to monitor service intervals.
  • Page 60 Increase engine rpms to full speed (3600 Cutting blades are not operating at full rpm) engine speed. Check engine speed with Land Pride Inductive Tachometer, Part No. 890-909C. Grass cutting is ragged or Belt over center take-up is loose. Tension over center take-up.
  • Page 61 Table of Contents Section 8: Troubleshooting Troubleshooting Chart Symptoms Probable Causes Suggested Remedies Air intake screen or cleaning fins Clean screen and fins. clogged. Engine is overheating. Not operating engine at rated speed. Increase engine speed to 3600 rpm. Other causes. See Engine Operator’s Manual.
  • Page 62 Table of Contents Section 9: Torque & Tire Inflation Charts Section 9: Torque & Tire Inflation Charts Torque Values Chart Bolt Head Identification Bolt Head Identification 10.9 Bolt Size Bolt Size (inches) Grade 2 Grade 5 Grade 8 (Metric) Class 5.8 Class 8.8 Class 10.9 in-tpi...
  • Page 63 Table of Contents Section 9: Torque & Tire Inflation Charts Tire Inflation Chart Tire Inflation PSI Rear Drive Wheels 8 to 12 Front Caster Wheels 8 to 12 ® 3/16/17 ZT360 & ZT372 Accu-Z Zero Turn Mowers 357-610M...
  • Page 64 Filters and Plugs are considered maintenance items. This Warranty is limited to the repair or replacement of any defective part by Land Pride and the installation by the dealer of any such replacement part, and does not cover common wear items such as blades, belts, tines, etc.
  • Page 65 Table of Contents Section 10: Warranty Evaporative Emission Control Components Refer to Figure 10-1: CAP, NON-VENTED FUEL GAS TANK FITTING W/NUT&WASHER CLAMP PINCH FOR .50 OD HOSE CLAMP WRM DRV (.21-.63) HFSS 3/8-16X5/8 GR5 YELLOW DIE LH FUEL TANK, COMPLIANT RH FUEL TANK, COMPLIANT VALVE, FUEL SELECTOR TEE 1/4HB POLYPROP...
  • Page 66 Corporate Office: P.O. Box 5060 Salina, Kansas 67402-5060 USA www.landpride.com...
