Summary of Contents for Chimera F2X
- Page 2 Outline - F2X Assembly Instructions Basic Information Layout the parts, grouping by color codes. Poles are bundled in specific groups for your convenience. Align tubes carefully as to not cross thread. Laying on the floor or a flat surface is helpful. Do not force if you encounter undue resistance.
- Page 3 Position all the bottom perimeter tubes first. Cross Brace Assembly (10x20’ and 10x30’ only) Layout a corner with a bottom long side tube, an assembled bottom end cross tube, one upright and an end cap. As you assemble, the threaded studs will all be pointing in the same direction. Repeat this for the opposite side.
- Page 4 You can put clean material down over a dirty surface - tape it securely so it doesn’t move. Raise your F2X frame off the ground at this stage, but not too high, approximately 2 feet, either on short light stands or apple boxes, etc.
