Summary of Contents for tradetec TR2789
- Page 1 Android Car Multimedia User’s Manual...
-
Page 2: Table Of Contents
User’s Manual Contents ANOUNCEMENTS........................3 OPERATION..........................4 SETUP............................6 Wallpaper ..........................6 Startup picture ......................... 7 Common setup ........................ 7 Display Setup ........................8 Sound options ........................9 Video options ........................9 Bluetooth .........................10 Navigation ........................11 Steering wheel control ....................11 ANDROID SETUP........................12 RADIO FUNCTION........................ -
Page 3: Anouncements
User’s Manual ANNOUNCEMENTS For your safety, please try not to watch the video and operate the machine while driving; please turn the volume to the level less than the outside sound. Before you start, please read this manual and other manuals of this system to understand the safety instructions and warning signs on this manual and the machine. -
Page 4: Operation
User’s Manual OPERATION System Reset 1） When using the unit for the first time, press and hold the "RESET" button for more than 3 seconds to restore the machine to the factory settings. 2） When the abnormal operation caused by improper operation and other abnormal phenomenon, please press the reset "RESET"... - Page 5 User’s Manual DISC ESP electronic shock function (disc is optional) The machine has an electronic shock function, so the car even if the road is not very good road and vibration, the machine's audio and video playback will not be affected much, of course, the length of the shock time will play different discs vary.
-
Page 6: Setup
User’s Manual SETUP In the touch screen, click on the main interface settings icon to enter the system settings interface, click on the corresponding option to enter the corresponding settings options, you can drag the bar up and down to find the desired settings. Note: Set the switch slider in the description. -
Page 7: Startup Picture
User’s Manual 2. STARTUP PICTURE In the general setting options, click "boot picture", in the pop-up password box, enter the password (5678), you can enter the boot screen settings option. Press and hold up and down the flip page, select the favorite boot picture, select, click "OK"... -
Page 8: Display Setup
User’s Manual 4. DISPLAY SETUP 4-1. Daytime Backlight Set Drag the right slider to select the daylight screen brightness value. 4-2. Nighttime Backlight Set Drag the right slider to select the nighttime screen brightness value Note: Reasonable adjustment of day and night screen brightness helps you to use this equipment safely and comfortably. -
Page 9: Sound Options
User’s Manual 5. SOUND OPTIONS 5-1. Sound setting You can enter the audio setting screen by clicking on the "Sound Options" of the setting interface, clicking the sound icon " " in the mode, or by pressing the "EQ" button on the panel. The machine provides 10 DSP sound effects, to bring you an excellent hearing ... -
Page 10: Bluetooth
User’s Manual 6-2. Reversing video image Turn on or off the reverse video image image mode, please choose according to the actual installation of the camera on or off. 6-3. Reversing trajectory This feature only supports some vehicles. Select "open", in the reverse screen, turn the steering wheel, the screen will be rotated with the steering wheel to show the track. -
Page 11: Navigation
User’s Manual 8. NAVIGATION 8-1. Autostart Navigation Whether to automatically start navigation map software after switch on. 8-2. File Path The user can select an already installed navigation application to match the external navigation button. The system will automatically list all the apps that have been installed. -
Page 12: Android Setup
User’s Manual ANDROID SETUP 1．Enter the Andrews setup interface In the main interface to find the Andrews universal settings icon , click into the main interface to install Andrews. As shown below: 2．Wifi connection In the settings interface to find the item , confirm the right of the wifi switch is turned on, click to enter: As shown above, in the wifi hot list to select the hotspot you want to connect, you... - Page 13 User’s Manual The system acquiescence from the internet and GPS information automatically get time information to calibrate the host time. If the customer does not need this feature, you can automatically determine the date and time function after the closure, and then in this interface, to set their own date and time.
-
Page 14: Radio Function
User’s Manual RADIO FUNCTION Enter the radio mode Short press the "BAND" key on the panel or touch the "Radio" icon in the main screen to enter the radio mode Band selection Click " ", band selection: FM1, FM2, FM3, Search for radio Short press the "Search"... -
Page 15: Disc Playback(Optional)
User’s Manual the user can GPS positioning and supporting the electronic map of the guidelines, fast, efficient and quick to reach the destination. To achieve accurate navigation, GPS positioning and navigation map both are indispensable, for the GPS requirements are high positioning accuracy, speed of operation; for navigation map requirements is large amount of information, data accuracy, path planning ability. - Page 16 User’s Manual When the power is turned on, if the dish has a disc, press the "DVD" button on the panel or click on the main interface "DVD" icon to enter the disc reading mode. Note: Some discs may not be available depending on the disc configuration and characteristics, or because the disc recording conditions and editing use the software.
-
Page 17: U-Disk/Sd Card Playback
User’s Manual Subtitle language switching function DVD discs may contain subtitles in multiple languages. During the playback process, click the " " key to toggle the subtitle language you need. Note: 1） Not all DVD discs can convert subtitle language while playing; some discs are selected by subtitle language via DVD menu 2）... - Page 18 User’s Manual files. Note: For this Android system, it doesn’t have SD card slot. Note: The unit supports FAT16 / FAT32 / EXFAT / NTFS format file system. Enter the media playback mode Insert the U disk or SD, the unit will automatically detect the device inserted. ...
-
Page 19: Ipod Playback(Optional)
User’s Manual IPOD PLAYBACK(OPTIONAL) The unit supports IPOD, IPHONE through Apple's own USB data cable directly to play the internal music. Because the use of Apple's certification chip, so you can support the latest IPOD and IPHONE models. Note: iPod function is not included in default unit. List switch Click to enter the playlist selection screen, click... -
Page 20: Bt Hf Operation
User’s Manual drive your vehicle more safely. In the main interface, click the " " icon to enter the Bluetooth interface, as shown below. Unit and mobile phone for the first time with the connection To use the Bluetooth handsfree feature, you must first connect the unit to the phone. 1）... -
Page 21: Bt Music (A2Dp)
User’s Manual Note: Due to the compatibility of the Bluetooth protocol, the unit does not guarantee to support all models of mobile phones, if found Bluetooth connection problems, please let us know. BLUETOOTH MUSIC（A2DP） The unit supports Bluetooth music playback, the phone can be stereo audio through the Bluetooth transmission to the car speakers, while supporting the "last song", "next song", "pause / play"... - Page 22 User’s Manual 1. Use precautions Do not place the monitor for long periods of time at direct sunlight or at high temperatures. Otherwise it may cause the LCD screen failure. If do not use the unit, please avoid direct sunlight to the monitor. ...
-
Page 23: Gps Antenna Installation
User’s Manual INSTALL GPS ANTENNA GPS antenna can be installed inside the car, such as installed on the dashboard; can also be installed in the vehicle outside, such as roof. GPS antenna must have an open "vision" towards the sky. If the vehicle's glass is equipped with an explosion-proof membrane, the insulation film may greatly impair the strength of the GPS antenna's acceptance of the satellite signal;... -
Page 24: Trouble Shooting
User’s Manual TROUBLE SHOOTING If you encounter the following problems in use, troubleshooting will help you quickly solve the problem, if the problem is still not resolved, please contact the professional or to the sales office advice, not privately open the machine, so as to avoid serious consequences! Problem Reason... - Page 25 User’s Manual The navigation system will consider various aspects of the road Navigation system search, in addition to distance will also consider the level of the the selected road "far road, cross regulation, viaduct, the main road, in short, to away"...
