4CH(2CH) ENCODER COUNTER
ER4C-04A
User's Manual
No.4011 (Rev.0)
APPLICATION OF ELECTRONIC DEVICES
Tsuji Electronics Co.,Ltd.
3739 Kandatsu-machi, Tsuchiura-shi, Ibaraki-ken, 300-0013, Japan
TEL: +81-29-832-3031(Representative) / FAX: +81-29-832-2662
URL http://www.tsujicon.jp
E-mail info2@tsuji-denshi.co.jp
Advertisement
Table of Contents
Related Manuals for TSUJI ELECTRONICS ER4C-04A
Summary of Contents for TSUJI ELECTRONICS ER4C-04A
- Page 1 4CH(2CH) ENCODER COUNTER ER4C-04A User's Manual No.4011 (Rev.0) APPLICATION OF ELECTRONIC DEVICES Tsuji Electronics Co.,Ltd. 3739 Kandatsu-machi, Tsuchiura-shi, Ibaraki-ken, 300-0013, Japan TEL: +81-29-832-3031(Representative) / FAX: +81-29-832-2662 URL http://www.tsujicon.jp E-mail info2@tsuji-denshi.co.jp...
-
Page 2: Table Of Contents
Contents １．Specification・・・・・・・･････････････････････････････････････････・・・・・････ ２．Panel Layout･･・・・・・・･･････････・・・・･････････････････････････････ ３．SETUP Mode・・・・･････････・・・・・・・・・・・･････････････････････････ ４．Communication Command・・・・・･････････・・・・・・・・・・・･････････････････････････ ５．Firmware Version Up･･・・・・・・・・・・・･････････････････････････... -
Page 3: １．Specification
4CH(2CH) ENCODER COUNTER <<ER4C-04A, ER2C-04A>> User's Manual 1． Specification 1) Power Supply AC100V-220V 50/Hz 2) Power Consumption 100V Maximum 3) Backup Memory backup by internal Batteries during power off state. (More than 5years) 4) Counter 32bit 10decimal digit (-2147483648 ～ 2147483647) 5) Preset Data of LCD indicator are set as present data by Preset SW. -
Page 4: ２．Panel Layout
2. Panel Layout 1) Front Panel (4CH) ① ② ④ ⑤ ⑥ ⑦ ③ ① POWER SW for Power on/off ② LCD indicator ● Scaling Parameter is default value LCD indicate encoder pulse count. (the least significant 7 decimal digit) * if count value is more than +2147483647 or less than -2147483648, the polarity will be reversed upper ：current counter value... - Page 5 2) Rear Panel (4CH) ① ② ③ ④ ① LAN Connector for LAN(10/100BASE-T) ② F3A Fuse holder for AC220V if necessary use 3A midget fuse ③ A,B,C,D ENCORDER Encoder input connector for A,B-phase type incremental Encoder Encoder type selections between Line driver and Open collector are available individually by setting.
-
Page 6: ３．Setup Mode
３．SETUP mode You can setup Encorder Counter in SETUP mode. *When SETUP mode, Encorder Counter stops counting. １） Setting Preparation and Completion Turn on the Power ON SW, and you can use Encorder Couneter in a few seconds. Setting values(MULT-P, DIR, Z-LED, ENCTYPE, LANCTRL, LAN IP:1, LAN IP2, Port no) are kept by battery backup. -
Page 7: ４．Communication Command
SD±□□・・・□□ If the value is over the range, (must be in within 10digit) maximun(or minimum) value is set. Firmware version read request VER? 1.00 20-10-06 ER4C-04A (in case of Ver.1.00) current FROM read FROM? FROM0 or FROM1 FROM select FROM0, FROM1 (□... - Page 8 Additional Command(Rev.3～) explanation command type reply A position counter read request RA±□□・・・□□ (10 digit) (10 digit format) B position counter read request ＲＢ±□□・・・□□ (10 digit) (10 digit format) C position counter read request ＲＣ±□□・・・□□ (10 digit) (10 digit format) D position counter read request ＲＤ±□□・・・□□...
-
Page 9: ５．Firmware Version Up
５． Firmware Version Up You can update firmware. When you update firmware, cut connection between Encorder Counter and Encorder for safety. Download version-up software(for Windows) from Tsuji Electronics Homepage(https://www.tsujicon.jp/). ① ③ ⑤ ② ④ Download version-up file fromTsuji Electronics Homepage and extract it. - Page 10 For safety reasons, unplug the appliance from the outlet when you open cover. If you warry, please contact us. ① Turn off POWER ON SW and open the cover. There is DSW1 on Printed Curcuit Board"TEP178". Set DSW1's switch1 on. ②...
