Indoor/outdoor &
indoor/outdoor Tall Models
BL-10-IO
BL-10-IOT
BL-12-IO
BL-12-IOT
BL-14-IO
BL-14-IOT
BL-16-IO
BL-16-IOT
This is a vented decorative gas appliance: not
a source of heat; not for use with solid fuel.
Installation/Operator's Manual
www.acucraft.com
888-317-6499
WARNING:
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly could
result in serious injury, death, or property damage.
- Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any oth-
er appliance.
- WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use
any phone in your building.
• Leave the building immediately.
• Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the
fire department.
- Installation and service must be performed
by a qualified installer, service agency or the
gas supplier.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference
BL_IO_10-16_INSTL_RevA_4.08.19
Advertisement
Table of Contents
Related Manuals for Acucraft Blaze BL-10-10
Summary of Contents for Acucraft Blaze BL-10-10
- Page 1 888-317-6499 Indoor/outdoor & WARNING: indoor/outdoor Tall Models FIRE OR EXPLOSION HAZARD Failure to follow safety warnings exactly could result in serious injury, death, or property damage. BL-10-IO BL-10-IOT - Do not store or use gasoline or other flammable BL-12-IO...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Introduction ................. pg 3 Safety / Warnings ..............pg 4-6 Installation Guide System Illustration ..............pg 7-9 Wiring Diagrams ..............pg 10-11 Positioning the Fireplace ............pg 12 Framing and Clearances ............pg 13-17 Installing the Ventilation System ........... pg 18-20 Installing the Media ............... -
Page 3: Introduction
Please review this manual carefully before installing your new fire- place. Blaze Commercial Series Indoor/Outdoor Linear Gas Fireplaces MODELS: BL-10-IO, BL-12-IO, BL-14-IO, BL-16-IO Blaze Commercial Series Indoor/Outdoor Tall Linear Gas Fireplaces MODELS: BL-10-IOT, BL-12-IOT, BL-14-IOT, BL-16-IOT Acucraft Fireplaces 19672 172nd Street Big Lake, MN 55309 www.acucraft.com 888-317-6499 BL_IO_10-16_INSTL_RevA_4.08.19... -
Page 4: Safety / Warnings
INSTALLATION SAFETY CODES: SAFETY STATEMENTS: Safety is very important and is referenced throughout - Acucraft does not install fireplace systems. These instructions should be used as a guideline only, and - Contact a licensed installer for proper installation. this manual in different ways. There are two different do not supersede local codes in any way. - Page 5 SAFETY WARNING FIRE & EXPLOSION HAZARD Gasoline or flammable vapors can ignite or explode. Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance. Follow lighting instructions provided on the label of the fireplace and in this manual. If the information in these instructions are not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life.
- Page 6 SAFETY Due to high temperatures, the appliance should be located out of traffic and away from furni- ture and draperies. Clothing or other flammable material should not be placed on or near the appliance. Children and adults should be alerted to the hazards of high surface temperature and should stay away to avoid burns or clothing ignition.
-
Page 7: Installation Guide
½ psi (3.5 k/Pa) Acucraft requires you to build an access panel within 4’ of the gas and electric stubs (the ADC100 must also be accessible). - Page 8 INSTALLATION GUIDE COMPONENT ILLUSTRATION BLAZE 10 IO/IOT BL_IO_10-16_INSTL_RevA_4.08.19...
- Page 9 INSTALLATION GUIDE COMPONENT ILLUSTRATION BLAZE 12-16 IO/IOT BL_IO_10-16_INSTL_RevA_4.08.19...
-
Page 10: Wiring Diagrams
INSTALLATION GUIDE Blaze 10 IO/IOT Wiring Diagram BL_IO_10-16_INSTL_RevA_4.08.19... - Page 11 INSTALLATION GUIDE Blaze 12-16 IO/IOT Wiring Diagram BL_IO_10-16_INSTL_RevA_4.08.19...
-
Page 12: Positioning The Fireplace
INSTALLATION GUIDE Positioning the Fireplace Using a hand truck or other appropriate equipment, that is rated to handle the weight of the fireplace safely move the fireplace into position. Refer to fire- place specifications for weight. Note: The appliance should be positioned in a manner that planned electrical and gas line access is available with adequate clearance for servicing. -
Page 13: Framing And Clearances
INSTALLATION GUIDE Framing Clearances Top of appliance to bottom of framing material = 4” Clearance to combustibles: Sides of appliance to side of framing material = 2” Top of appliance = 4” Back of appliance to framing material = 2” Sides of appliance = 2”... - Page 14 INSTALLATION GUIDE • The non-combustible backer board should tie into the framing around the unit as shown above. • The backer board may be fastened to the unit with fasteners that do not penetrate the fireplace more than 1”. • There should NOT be any fasteners in the 3”...
- Page 15 INSTALLATION GUIDE The shaded area in the drawing above is the non-combustible zone. All finishing material in this area is to only be non-combustible. BL_IO_10-16_INSTL_RevA_4.08.19...
- Page 16 INSTALLATION GUIDE • Non-combustible backer board Wood Stud Framing can be directly fixed to the in- sulated panels of the fireplace. • Fasteners are not to pene- trate more than 1” Steel Stud Framing *Wood stud framing re- quires a 4” clearance from the top of the unit.
- Page 17 INSTALLATION GUIDE Distance to any side adjacent wall must be at least 12” inches from the outside of the glass frame. BL_IO_10-16_INSTL_RevA_4.08.19...
-
Page 18: Installing The Ventilation System
INSTALLATION GUIDE Vent terminal locations to intersecting walls, overhangs or eaves, window openings, air intakes, above-ground grade or deck shall maintain the clearances specified as shown below. Vent terminals shall not be recessed into a wall or siding. Installing the Ventilation CAUTION: The entire ventilation system, including Class A Combustion air supply: It is always recommended... - Page 19 INSTALLATION GUIDE Canadian installations US installations Clearance above grade, ve- 12 in (30 cm) 12in (30 cm) randa, porch, desk or balcony Clearance to window or door 6 in (15 cm) for appliances ≤ 10,000 6 in (15 cm) for appliances ≤ 10,000 that may be opened Btuh (3 kW), 12 in (30 cm) for appli- Btuh (3 kW), 9 in (23 cm) for applianc-...
- Page 20 50 feet or less. to combustible materials to prevent a fire. Do not fill air spaces with insulation. You must have your venting scenario approved by Acucraft Fire- • Minimum Vent Configurations (elbow directly off place Systems fireplace) •...
-
Page 21: Installing The Media
INSTALLATION GUIDE Installing the Media WARNING Always wear protective equipment when dealing with open flames. Failure to follow this warning may result in serious injury. This fireplace burner requires a layer of media to cover the burner tube, allowing proper dispersion of the gas flow and propagation of the flame. -
Page 22: Installing The Glass Panel
INSTALLATION GUIDE WARNING Always wear protective equipment when dealing with hot surfaces. Failure to follow this warning may result in serious injury. Place Inner Glass Panel into track as shown. Place middle frame assembly into opening, push tight up to permanent glass frame. Place bolts in spaces provided to attach middle frame assembly to firebox. -
Page 23: Siliconing The Outside Panel
INSTALLATION GUIDE Siliconing the Outside Frame and Glass Once the glass pane is properaly installed, seal the space between the frame and glass with high temp silicone. Make sure to use an adequate amount of silicone to completely seal the fireplace from the elements. BL_IO_10-16_INSTL_RevA_4.08.19... -
Page 24: Gas Valve & Ignition Module
INSTALLATION GUIDE Connecting the Gas Valve & Ignition System The stubbed gas line port and electrical pass through IMPORTANT: All connections and components should be made port are located on the side of the unit. The ignition system must be just outside of the fireplace. Location and installed by qualified persons only and checked not to exceed 5’... -
Page 25: Draft Switch
INSTALLATION GUIDE Draft Switch Mechanical Installation INSTALLATION OF DRAFT SWITCH INSTALLATION OF STACK PROBE FOR PDS 1: A stack probe is used with the Draft Switch. The Draft The Draft Switch is for indoor installation only. The Switch monitors the pressure inside the stack and sig- Draft Switch must be installed in a vertical position nals the control to shut down the appliance if insuff- with the pressure connection pointing down. - Page 26 INSTALLATION GUIDE Draft Switch For all installations, the stack probe must be placed so the flow through the stack is perpendicular to the tip of the probe. Locate the probe at least the distance “A” away from any elbows or tees in the stack. The distance “A”...
-
Page 27: Chimney Fan
INSTALLATION GUIDE Chimney Fan Dimensions & Capacities 1. Junction Box 2. Conduit / Cord 3. Motor 4. Motor Housing 5. Cooling Plates 6. Bird Screen 7. Base Plate 8. Locking Nut 9. Inlet 10. Axial Vane 11. Hinges 12. Capacitor (Inside Junction Box) BL_IO_10-16_INSTL_RevA_4.08.19... - Page 28 INSTALLATION GUIDE Chimney Fan CAUTION Step 1: Prepare fan location The steel chimney adapter (SCA) slides right into the Under conditions with extremely strong winds chimney, where the long collar engagement ensures surrounding the top of the chimney, the chimney fan safe anchoring.
- Page 29 INSTALLATION GUIDE Chimney Fan The combustion air inlet and flue gas outlet of a direct CAUTION vent appliance or the flue gas outlet of an appliance other than a direct vent appliance shall terminate at least 1 ft (0.3 m) from the soffit of the roof of the A safety device that prevents the heating appliance structure and at least 3 ft (0.9 m) from an inside operation, in case of a power failure or inadequate...
- Page 30 INSTALLATION GUIDE Chimney Fan Start-Up and Configuration CARE AND CLEANING SYSTEM TESTING Before any adjustments are made to the system, The Chimney Fan System is designed for prolonged use. The fan should be inspected at least once a year follow these procedures: when the chimney is inspected.
- Page 31 INSTALLATION GUIDE Chimney Fan Maintenance (cont.) CHIMNEY CLEANING INTERVALS It is extremely important to keep the chimney flue clean from products of combustion and deposits. Unburned oil residues can cause a chimney fires. Cleaning intervals depend on the use of the appliance. The more the appliance is used, the more often the chimney flue needs cleaning.
-
Page 32: Component Quick Reference Guide & Replacement Parts
This fireplace system consists of several components that are designed specifically for this appliance. No parts on this appliance may be substituted or replaced with anything other than original components. Replacement parts as listed below can be obtained by contacting Acucraft Service by phone or email. Acucraft Customer Service Contact Information: •... - Page 33 PRODUCT SPECIFICATIONS BLAZE 10 IO/IOT 1" REVEAL DETAIL A SCALE 1 : 8 CLASS A FLUE B-VENT FOR HEAT RELIEF 2" 2" 4" GAS AND 2 " ELECTRIC STUBS 11" GLASS COOLING COMBUSTION AIR 2 " INTAKE INTAKE *This drawing shows outdoor view of the fireplace BLAZE SERIES DIMENSIONS MODEL BL-10-IO...
- Page 34 PRODUCT SPECIFICATIONS BLAZE 12-16 IO/IOT 1" REVEAL DETAIL A SCALE 1 : 8 CLASS A FLUE B-VENT FOR HEAT RELIEF 2" 2" 4" GAS AND 2 " ELECTRIC STUBS 11" GLASS COOLING COMBUSTION AIR 2 " INTAKE INTAKE *This drawing shows outdoor view of fireplace. BLAZE SERIES DIMENSIONS MODEL BL-12-IO...
-
Page 35: Operation Guide Specifications
OPERATION GUIDE FOR YOUR SAFETY, READ BEFORE OPERATING WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY, OR LOSS OF LIFE • If you cannot reach your gas supplier, call the fire A. -
Page 36: Operation Guide
OPERATION GUIDE Basic Sequence of Operation Turning gas off to the appliance Listed below is a sequence of operation when the Please check with local codes.In the absence of local fireplace is functioning properly. If you are experi- codes, use the current National Fuel Gas Code – encing problems with the fireplace not operating ANSI Z223.1 (NFPA 54) or CAN/CGA B149 normally, see the Troubleshooting section. -
Page 37: Troubleshooting
TROUBLESHOOTING PROBLEM SOLUTION If the appliance does not light within 20 seconds, the gas valve will lock Appliance does not light within out automatically. Turn off switch, wait 10 seconds, and try 20 seconds. turning it on again. If there is still no ignition, turn off switch and visually inspect wiring harness for loose connections and check to be sure the gas supply is connected and all valves are open. - Page 38 3. If the Proven Draft Switch has not been made within 15 seconds, the auxiliary out contact opens and an alarm condition exists. 4. If the Proven Draft Switch closes, the control automatically resumes normal operation at set speed. *If further assistance is needed contact Acucraft service department Phone: (763) 263-3156 Email: service@acucraft.com...
- Page 39 TROUBLESHOOTING Gas Valve & Ignition Module FIG. 7 - CHANGING INSERT ORIFICES CHANGE INSERT ORIFICES (See Fig. 7) 1. Disconnect pilot tubing from the pilot burner and remove insert orifice. Sometimes a light force is INSERT ORIFICE required to remove the orifice. 2.
- Page 40 TROUBLESHOOTING Gas Valve & Ignition Module FIG. 9 EXAMPLES OF UNSATISFACTORY PILOT FLAMES APPEARANCE CAUSE SMALL BLUE FLAME CHECK FOR LACK OF GAS FROM: • CLOGGED ORIFICE FILTER • CLOGGED PILOT FILTER • LOW GAS SUPPLY PRESSURE • PILOT ADJUSTMENT AT MINIMUM LAZY YELLOW FLAME CHECK FOR LACK OF AIR FROM: •...
-
Page 41: Maintenance & Care
MAINTENANCE & CARE Always use proper precautions and turn off fireplace before performing any maintenance. Do not clean appliance when hot. We recommend the fireplace to be cleaned and inspected by a certified technician after 3-6 months of op- eration. The technician will be able to assess the fireplace and recommend a cleaning schedule. If the fire- place is not going to be cleaned by a technican, ensure to clean the tempered glass with a basic household glass cleaner on average every 3 months to a year (depending on frequency of use). -
Page 42: Warranty
The coverage of this warranty is limited to all components of the gas appliance manufactured by Acucraft. If the components of the gas appliance covered by this warranty are found to be defective within the time stated. Acucraft, at its option, will replace or repair defective components of the gas appliance manufactured by Acucraft at no charge, and may also choose pay for reasonable labor costs incurred in repairing components requiring approval prior to work commencing.This warranty covers only parts and labor as provided above. - Page 43 FIRE IS OUR PASSION www.acucraft.com 888-317-6499 Acucraft Fireplaces 19672 172nd Street Big Lake, MN 55309 BL_IO_10-16_INSTL_RevA_4.08.19...
