- Page 1 INDUSTRIAL BENCH GRINDER OPERATOR’S MANUAL TM400-150 Ver: 1.2 www.itmtools.com.au...
- Page 2 TM400-150 OPERATOR’S MANUAL TABLE OF CONTENTS Safety Information ....................3 Warranty ..........................Safety Information ....................... Package Contents ....................8 Parts Diagram........................Preparation ......................8 Parts List..........................Assembly Instructions ..................9 Safety Rules ........................Operating Instructions ..................11 Wheel Dressing ........................
- Page 3 Users of these tools should review the chemical composition of the work surface chemicals prior to engaging in any activity that creates dust and/or microscopic TM400-150 OPERATOR’S MANUAL and any products in conjunction with the operation of these tools for any such particles.
- Page 4 TM400-150 OPERATOR’S MANUAL PARTS DIAGRAM www.itmtools.com.au...
- Page 5 TM400-150 OPERATOR’S MANUAL PARTS LIST DIA. NO DESCRIPTION SPEC. DIA. NO DESCRIPTION SPEC. Philips screw M5x46 Capacitor support Spring washer Capacitor 6uF/450v Philips screw with Left wheel cover M6x20 spring washer Hex nut M12-Left Baffle Flange Rubber foot Philips screw with big Stone wheel 36# 150x25x12.7 1...
- Page 6 TM400-150 OPERATOR’S MANUAL GENERAL SAFETY RULES FOR OPERATION WARNING! Read all instructions. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. The term “power tool” in all of the warnings listed below refers to your mains- operated (corded) power tool or battery-operated (cordless) power tool.
- Page 7 TM400-150 OPERATOR’S MANUAL Power tool use and care Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for which it was designed.
- Page 8 TM400-150 OPERATOR’S MANUAL Keep guards in place and in good working order. With the machine disconnected from the mains supply check that the guards are secure and fitted correctly. Always keep the tool rest as close to the grinding wheel as possible. The gap between the tool rest and the grinding wheel should be no more than 3mm.
- Page 9 TM400-150 OPERATOR’S MANUAL GETTING STARTED Accessories The bench grinder is supplied with the following accessories: 2 eye shields with mounting brackets and 2 tool rests CAUTION. Always ensure that the bench grinder is switched off and plug is removed from the power point before making any adjustments.
- Page 10 TM400-150 OPERATOR’S MANUAL TROUBLESHOOTING SYMPTOM CAUSE CORRECTIVE ACTION 1. Low Voltage. 1. Check power source for proper voltage. 2. Open circuit in motor or loose 2. Inspect all lead connection on motor for loose or open connections. Motor will not start.
