- Page 1 USER MANUAL TUNJKTRLY05 5 TONNE TROLLEY JACK LONG & LOW PROFILE...
- Page 2 The information in this document is to the best of our knowledge true and accurate, but all recommendations or suggestions are made without guarantee. Since the conditions of use are beyond their control, Tundra Industrial ® disclaim any liability for loss or damage suffered from the use of this data or suggestions.
-
Page 3: Safety Guidelines
No responsibility is accepted for incorrect use of this equipment. Incorrect use can result in damage to the equipment and danger to the user. Warranty will be void in the event of incorrect use. Hydraulic products are only repaired by Tundra Industrial authorised engineers. -
Page 4: Specifications
USER MANUAL TUNJKTRLY05 2. SPECIFICATIONS Model Number TUNJKTRLY05 Maximum Load: 5 Tonne Minimum Height: 150mm Maximum Height: 583mm Length: 1305mm Weight (NW/GW): 71kg / 84kg 3. DESCRIPTION European style trolley jack manufactured to current EC manufacturing standards. Lifting arm equipped with two speed lifting and lowering;... -
Page 5: Troubleshooting
USER MANUAL TUNJKTRLY05 6. TROUBLESHOOTING Symptom Possible Causes Solution Jack will not lift the load 1. Overloaded 1. Be sure to use jack with adequate capacity 2. Low oil level 2. Top up oil lever 3. Release valve not correctly closed 3. - Page 6 USER MANUAL TUNJKTRLY05 7. PARTS LIST & EXPLODED PARTS DIAGRAMS No. Description No. Description No. Description Retaining Ring Washer (PTFE) Oil Plug Filter Net U-Ring Elastic Collar Retaining Valve Core Pump Core Base Retaining Ring Returning Spring Washer O-Ring Steel Ball...
- Page 7 USER MANUAL TUNJKTRLY05 No. Description Spring Washer Flat Washer Wheel Spacer Front Wheel Retaining Ring Adjustment Plate Side Plate, Right Lifting Frame Retaining Nut Retaining Nut Return Spring Hex Nut Spring Pin Block Plate Retaining Ring Pump Core Axle Spring Axle...
-
Page 8: Maintenance
USER MANUAL TUNJKTRLY05 8. MAINTENANCE NOTICE: Use high grade hydraulic oil only. Never use brake fluid, motor oil, transmission fluid, turbine oil or any other fluids. ISO-VG22 or equivalent hydraulic oil is recommended. Check and Refill Oil • With the jack fully lowered and in a level location, if unit cover is provided, remove unit cover, then remove oil filler plug. -
Page 9: Ec Declaration Of Conformity
USER MANUAL TUNJKTRLY05 EC DECLARATION OF CONFORMITY We, Tundra Industrial, as the authorised European Community representative of the manufacturer, declare that the following equipment conforms to the requirements of the following Directives: BS EN 1494:2000+A1:2008 Mobile or movable jacks and associated lifting equipment... -
Page 10: Limited Warranty Statement
Upon inspection of the equipment, if no defect can be found or the equipment is not covered under the terms of the Tundra Industrial warranty, the customer will be liable for any labour and return transportation costs incurred. - Page 11 Where repair is not covered by the warranty a quotation for repair, labour costs and return delivery will be sent to the customer (normally within 7 working days). Note: If the repair quotation is not accepted Tundra Industrial will invoice 1 hour labour time at £30 per hour plus return carriage costs (plus VAT).
- Page 12 USER MANUAL TUNJKTRLY05...
