Jackson 440DL Operating, Safety And Parts Manual

4 leg v-head pipe stand
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
4 Leg V-Head Pipe Stand
Operating, Safety and Parts Manual
This manual is free of charge. All personnel who operate the Pipe Stand should have a copy of this manual and
read and understand its contents. To request a copy of this manual or replacement safety decals, or for technical
assistance, call or write to the address below. All information, specifications and product designs may change
due to design improvements or updates and are subject to change without notice. Jackson Tool does not
assume any liability for damages resulting from misuse or incorrect application of its products.
JACKSON TOOL • P. O. BOX 5701 • GREENVILLE, SC 29606
877-522-8995 or 864-721-4235 • FAX 864-721-4236 • www.jacksontoolinc.com
Model 440DL
Read and understand this material before operating
or servicing the Pipe Stand. Failure to understand how
to safely operate and service this unit may result in
property damage, serious injury or death.
02/2021

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 440DL and is the answer not in the manual?

Questions and answers

Related Manuals for Jackson 440DL

Summary of Contents for Jackson 440DL

  • Page 1 All information, specifications and product designs may change due to design improvements or updates and are subject to change without notice. Jackson Tool does not assume any liability for damages resulting from misuse or incorrect application of its products.

  • Page 2: Table Of Contents

    Exploded View and Parts List – 440DL . . . . . . . . . . . . . . . . .

  • Page 3: Safety Information

    CAUTION and the roll pin is in place. DANGER WARNING ONLY use Jackson Tool replacement parts on the Pipe Stand. Use of parts DANGER CAUTION not supplied by Jackson Tool WILL NOT work properly on the Pipe Stand and could result in serious personal injury or death.

  • Page 4: Features

    2,500 lb. working load capacity Powder coat finish Base legs made from 1" square tubing SPECIFICATIONS Model No. 440DL Pipe Size Capacity 1/2" to 12" Max. Weight Capacity 2500 lbs. per Stand Overall Dimensions L18½" W18½" H32½" (fully retracted) Min. Stand Height 30½"*...

  • Page 5: Operating Instructions

    OPERATING INSTRUCTIONS 1. Inspect the Pipe Stand before each use. NEVER use if any legs or other part of the stand is bent, deformed, broken or has been modified. 2. Place the Pipe Stand on a smooth, level, firm surface that will support the weight of the load. Be sure all feet of the stand make contact with the floor.

  • Page 6: Exploded View And Parts List - 440Dl

    EXPLODED VIEW — 440DL 4 LEG PIPE STAND PARTS LIST — 440DL 4 LEG PIPE STAND COMPONENTS LIST ITEM# PART# DESCRIPTION 186-20 PIN – ROLL (3/16" × 1.25") 2508-581 T-SCREW 436-088 LOCK RING 436-112 SCREW, BUTTON HEAD SOCKET – 1/4-20 × 1/2"...

  • Page 7: Optional Hold Down Device Operating Instructions

    DANGER OPTIONAL HOLD DOWN DEVICE 436DL-200 OPERATING INSTRUCTIONS WARNING Hold down device is only to secure pipe to the Pipe Stand. DO NOT use for any other purpose. CAUTION 1. Place the hold down device on top of the pipe, in line with the center of the pipe stand base (See photo 1).
  • Page 8 OPTIONAL HOLD DOWN DEVICE #436 DL-200 OPERATING INSTRUCTIONS – CONTINUED 5. Turn hold down device handle/nut to tighten chain. As you tighten the chain with the handle/nut, check to ensure that the full length of the chain tightens against the pipe. (See photo 5).

  • Page 9: Exploded View And Parts List - 436Dl-200

    HOLD DOWN DEVICE #436DL – 200 EXPLODED VIEW AND PARTS LIST ITEM# PART# DESCRIPTION 1 ....636-7 ....1 ....Handle/Nut 2 ....636-858 ....1 ....Hold Down Bracket 3 ....436DL-201 ....1 ....Acme Screw/Chain Assembly...
