Summary of Contents for TONGFANG PH6ARX2

  • Page 1 User Manual PH6ARX2 PH6AQE2 PH6AQF2 PH6AG02 PH6AQ72 PH6AQI2...

  • Page 2: Notice

    Notice The information in this user’s manual is protected by copyright laws, all parts of this manual, including the products and software described in it, can not be reproduced, transmitted, transcribed, stored in a retrieval system, nor translated into any language. THE MANUFACTURER OR RESELLER SHALL NOT BE LIABLE FOR ERRORS OR OMISSIONS CONTAINED IN THIS MANUAL AND SHALL NOT BE LIABLE FOR ANY CONSEQUENTIAL...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Notice ...................... 2 Preface ....................5 1.1 Regulations Information..............6 1.2 Safety Instructions ................10 1.3 Conventions for this Manual .............11 1.4 Release History ................12 Getting to know the basics ..............13 2.1 Product Specification ............... 14 2.2 Preparing your Computer ...............
  • Page 4 4.1 About BIOS Setup ................35 4.1.1 When to Use BIOS Setup ? ............35 4.1.2 How to Run BIOS Setup ? ............35 4.2 BIOS Setup Menu................36 4.2.1 Main Menu ..................37 4.2.2 Advanced Menu ................39 4.2.3 Security Menu................41 4.2.4 Boot Menu ..................

  • Page 5: Preface

    Chapter 1 Preface Notebook Manual 5...

  • Page 6: Regulations Information

    1.1 Regulations Information CE compliance ¤ This device is classed as a technical information equipment (ITE) in class B and is intended for use in living room and office. The CE-mark approves the conformity by the EU-guidelines: - EMC Directive 2014/30/EU, - Low Voltage Directive 2014/35/EU(equals A2 : 2013) , - RF Directive 2014/53/EU SAR/DAS refers to the rate at which the body absorbs RF energy.
  • Page 7 Rechargeable Battery Notice Do not 1. Throw into fire or a hot oven, or mechanically crush or cutting of a BATTERY 2.Throw or immerse into water 3.Heat to more than 60°C 4.Repaire or disassemble 5.Leave in an extremely low air pressure environment 6.Leave in an extremely high-temperature environment A power cord is connected to a socket-outlet with earthing connection.
  • Page 8 FCC Information FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 9 RF Exposure Information(SAR) This device meets the government’s requirements for exposure to radio waves. This device is designed and manufactured not to exceed the emission limits for exposure to radio frequency (RF) energy set by the Federal Commu- nications Commission of the U.S. Government. The exposure standard employs a unit of measurement known as the Specific Absorption Rate, or SAR.

  • Page 10: Safety Instructions

    1.2 Safety Instructions Do not apply heavy pressure to the computer or subject it to any form of strong impact as this can damage the computer's components or otherwise cause it to malfunction. Never cover or block the air vents including those located at the base of the computer.

  • Page 11: Conventions For This Manual

    1.3 Conventions for this Manual CAUTION : This message contains important information that must be followed for safe operation. NOTE : This message contains information for special situations. Notebook Manual 11...

  • Page 12: Release History

    1.4 Release History Version Date Revision Initial release 11/2021 Notebook Manual 12...

  • Page 13: Getting To Know The Basics

    Chapter 2 Getting to know the basics Notebook Manual 13...

  • Page 14: Product Specification

    Dimension  357.56 x246.53 x 18.1mm 1.82kg +/- 5% (62.32whr w/o SSD and RAM) for PH6ARX2 1.87kg +/- 5% (80whr w/o SSD and RAM)(option) 1.93kg +/- 5% (62.32whr w/o SSD and RAM) for PH6AQE2/PH6AQF2 1.98kg +/- 5% (80whr w/o SSD and RAM)(option) ・CPU...
  • Page 15 ・I/O Port DC-in USB Type A*2: Right: (Gen1)*1 (Power off mode support USB power, & w/bc1.2 protocol ) Left: (Gen1)*1 (Power off mode support USB power, but w/o bc1.2 protocol ) USB Type C *2: Right: TBT4 (only w/ 5V@3A output ) +w/type-C Adaptor(40W~100W) Left: USB3.1(Gen2)&w/DP 1.4&w/type-C Adaptor(40W~100W) (HDMI 2.1: 4K120Hz) HDMI...
  • Page 16 ・Webcam Infrared capability for facial reconition camera  IR Camera w/ D-MIC*2 ,4mm HD webcam with D-MIC*1 ,4mm ・Communication Port Wireless LAN +BT  *M.2 2230 w/ CNVI interface (Intel Wi-Fi 6 AX201) IEEE802.11 a/b/g/n/ac/ax support (Design for WiFi6E should be reserved) ・Input Keyboard ...
  • Page 17 ・Power AC Adapter  Automatics Voltage adjustment between 100 and 240VAC 50/60Hz, 90 Watts(19V/4.74A), 3 Pins (PH6ARX) 120 Watts (19V/6.32A), 3 Pins (PH6AQE2 / PHAQF2) Battery  Li- polymer Battery, SW Gas Gauge IC, soft pack, * 4 cells (4s1p 4000 mAh) 62.32 Wh * 4 cells (4s1p 5168 mAh) 80 Wh CAUTION: MODEL IS DESIGNED TO USE WITH THE DC INPUT: 90 Watts(19V/4.74A)

  • Page 18: Preparing Your Computer

    2.2 Preparing your Computer Connect the AC adapter’s DC output plug to the DC IN jack. The display panel can be opened to a wide range of angles for optimal viewing. Press the power button to turn on your notebook computer. Notebook Manual 18...

  • Page 19: Product Overview

    2.3 Product Overview Please become familiar with each component before you operate the computer. Top-Open View NOTE: The product’s color/ LED color, I/O port, indicator location, and specifi- cation will depend upon the actually shipping product. Notebook Manual 19...
  • Page 20 Camera Status LED The Camera Status LED shows the Camera status. Camera A device that allows you to record video or take photographs with your computer. Infrared capability for facial reconition camera can be used to identify and authenticate user to unlock notebook, conduct payment and other security functions.
  • Page 21 Keyboard The keyboard provides keys with comfortable travel (The keyboard legend will depend on the spec / region) Caps Lock Status LED Default: ON (White) Touchpad LED indicator/ Touchpad switch Click twice left corner will open or close touchpad functionality Touchpad/Click pad Touch-sensitive pointing device which functions like the mouse.
  • Page 22 Right Side View Thunderbolt™4 (USB Type C 3.1) Connects an USB device. (such as USB Zip drive, keyboard or mouse) into this jack. USB Port Connects an USB device (such as USB Zip drive, keyboard or mouse) into this jack. With charging function. HDMI port Connected to the screen, or home theater system.
  • Page 23 Left Side View Kensington® Lock Port To be secured using Kensington® Lock Port security products. USB Port (Type C) Connects an USB device. (such as USB Zip drive, keyboard or mouse) into this jack. USB Port Connects an USB device (such as USB Zip drive, keyboard or mouse) into this jack.
  • Page 24 Bottom Side View NOTE : The product’s thermal vent will depend upon the actually shipping product. Vents The thermal vents are designed to cool the internal components and avoid overheating. Speaker CAUTION: To reduce the possibility of heat-related injuries or of overheating the computer, do not place the computer directly on your lap or obstruct the computer air vents.
  • Page 25 Compartment View NOTE: Specification will depend upon the actually shipping product. SSD   BATTERY If need to upgrade SATA SSD to PCIE SSD, Please contact technical support and after-sales service . Notebook Manual 25...
  • Page 26 Front Side View Back Side View Notebook Manual 26...

  • Page 27: Getting Started

    Chapter 3 Getting started Notebook Manual 27...

  • Page 28: Ac Adapter

    3.1 AC Adapter Please be noted that it is strongly recommended to connect the AC adapter and use the AC power while using this notebook for the first time. When the AC adapter is connected, the battery is being charged immediately. Attach the AC adapter when you need to charge the battery or you want to operate from AC power.

  • Page 29: Knowing The Keyboard

    3.2 Knowing the Keyboard The following defines the hot keys on the Keyboard. The commands can only be accessed by first pressing and holding the function key while pressing a key with a command. NOTE: The design of the number of keys available on the keyboard, printing color or backlight depends on the country (region) in which the keyboard was designed and built.in which the keyboard was designed and built.

  • Page 30: For Keyboard Users

    3.2.1 For keyboard users To activate these functions, press the hot key associated with the desired function as below : Function Keys Keypad Function Description Press this key combination (Fn+F1) Suspend: to enter sleep mode. Windows Press this key combination (Fn+F2) Windows to turn Lock/On .
  • Page 31 Function Keys Keypad Function Description Keyboard Press this key combination (Fn+F6) Brightness Keyboard to decrease brightness of down: Keyboard Press this key combination (Fn+F7) Brightness Keyboard. to increase brightness of Press this key combination (Fn+F8) MUTE: to enter MUTE mode. Volume Press this key combination (Fn+F9) down:...
  • Page 32 Function Keys Keypad Function Description Search For a full list of Windows keyboard Charm : shortcuts, please visit the Microsoft (Optional) official website https://support.microsoft.com/en-us/ Notebook Manual 32...

  • Page 33: Using The Touchpad / Clickpad

    3.3 Using the touchpad / clickpad The touchpad / clickpad is a rectangular electronic panel located just below your keyboard. Click twice left corner will open or close (Green light) touchpad functionality.You can use the static-sensitive panel of the touchpad / clickpad and slide it to move the cursor. You can use the buttons below the touchpad as left and right mouse buttons.

  • Page 34: Bios Setup

    Chapter 4 BIOS setup Notebook Manual 34...

  • Page 35: About Bios Setup

    4.1 About BIOS Setup 4.1.1 When to Use BIOS Setup ? You may need to run the BIOS Setup when: ・ An error message appears on the screen during the system booting up and is requested to run SETUP. ・ You want to change the default settings for customized features.

  • Page 36: Bios Setup Menu

    4.2 BIOS Setup Menu Once you enter the BIOS Setup Utility, the Main Menu will appear on the screen. Select the tags to enter the other menus. Main Menu Show system overview about memory size and setting of system time and date. Advanced Menu To select the XD feature enable or disable XD feature only work with Intel platform + Windows.

  • Page 37: Main Menu

    4.2.1 Main Menu ・System Time This item allows you to set the system time. There is a small internal (CMOS) battery which is designed to maintain your system clock. It is designed to maintain time even when the PC is powered down or in sleep mode. The time format is [hour:minute:second].
  • Page 38 Day of the week, from Sun to Sat, which is determined by BIOS (read-only). The month from 01 (January) to 12 Month (Month) (December). Date (Date) The date from 01 to 31. Year (Year) The year can be adjusted by users. ・Total Memory This allows you to see the total amount of memory.

  • Page 39: Advanced Menu

    4.2.2 Advanced Menu ・Operating system support [UFEI OS] If will support UEFI mode compaatible operating systrems. ・NVME Device AHCI NVME SSD info will be displayed Notebook Manual 39...
  • Page 40 ・Intel Virtualization Technology When enabled, VMM can take advantage of additional hardware features provided by Vanderpool technology ・Operating mode (Optional) Blance mode/20dB mode ・For details of Control center, please refer to the following instructions Notebook Manual 40...

  • Page 41: Security Menu

    4.2.3 Security Menu ・Change Administrator Password When this item is selected, a message box shall appear on the screen as below: Enter New Password Type a maximum of 20-digit password and press [Enter]. The password typed now will replace any previously set password from CMOS memory.
  • Page 42 Select Change User Password to give or to abandon password setting same as Change Administrator Password item above. Note that Administrator Password field allows users to enter and change the settings of the BIOS SETUP UTILITY, while User Password field only allows users to enter the BIOS SETUP UTILITY without having the authorization to make any change.

  • Page 43: Boot Menu

    4.2.4 Boot Menu ・Boot Configuration Configure Settings during System Boot. ・Set Boot Priority (1st/2nd/3rd/..Boot) Specifies the boot sequence from the available devices. A device enclosed in parenthesis has been disabled in the corresponding type menu. ・ Hard Disk Drive / USB HardDisk Drive Specifies the Boot Device Priority sequence.

  • Page 44: Exit Menu

    4.2.5 Exit Menu ・Save Changes and Reset Exit system setup after saving the changes.F4 key can be used for this operation. ・Discard Changes and Exit Exit system setup without saving any changes. ESC key can be used for this operation. ・Restore Defaults Restore/Load Defaults values for all the setup options.
