- Page 1 B100PAD- M Biometric Keypad Reader INSTALLER MANUAL www.xprgroup.com...
-
Page 2: Table Of Contents
CONTENS 1. DESCRIPTION 2. SPECIFICATIONS 3. MOUNTING 4. WIRING 5. CONNECTING BIOMETRIC READERS TO EWS CONTROLLER 5.1 CONNECTING BIOMETRIC READERS IN SAME RS485 LINE WITH THE EWS CONTROLLERS 5.2 CONNECTING BIOMETRIC READERS WHEN ALL THE CONTROLLERS HAVE TCP/IP COMMUNICATION 5.3 RS485 TUNING 6. -
Page 3: Description
1. DESCRIPTION B100PAD-M is a Wiegand biometric reader for outdoors access control applications. It offers storage up to 100 fingerprints, programmable Wiegand Output (8 to 128 bits) and selectable PIN Code length. Configuration of the readers and fingerprint enrollment is done through PC Software. -
Page 4: Mounting
3. MOUNTING 4 (3 x 30mm) 1 (M3 x 6mm) If the biometric reader is installed and used outdoor, the reader MUST be fitted with MCD-MINI cover available in our accessories in order to protect the sensor from direct rainfall. The operating temperature of the product is between -15ºC - + 50ºC. If the reader is installed in an environment where the temperature can drop below -10ºC or/and if the sensor could only be exposed to direct sunlight, it is strongly recommended to install the reader inside a third party sealed wall mount box (fitted with additional heater if very low temperature) to keep a constant sensor level performance. -
Page 5: Connecting Biometric Readers To Ews Controller
5. CONNECTING BIOMETRIC READERS TO EWS C ONTROLLER - The Biometric readers can be connected to virtually any controller that conforms to Wiegand format standards (standard Wiegand 26bit or self-defined Wiegand). - The lines D0 and D1 are the Wiegand lines and the Wiegand Number is sent through them. - The RS485 line (A, B) is used for fingerprint transfer and reader settings. -
Page 6: Connecting Biometric Readers When All The Controllers Have Tcp/Ip Communication
5.2 CONNECTING BIOMETRIC READERS WHEN ALL THE CONTROLLERS HAVE TCP/IP COMMUNICATION TCP/IP Switch max. max. max. •When all the controllers are connected via TCP/IP, then the RS485 network becomes local (from Reader 1 to the Controller then to the Reader 2). •Connect the readers directly to the Rs485 terminals in each controller. -
Page 7: Connecting Biometric Readers To 3Rd Party Controller
6. CONNECTING BIOMETRIC READERS TO THIRD PARTY CONTROLLERS 3rd party controller 3rd party controller -+DO D1 -+DO D1 -+DO D1 -+DO D1 CNV200 BIOE RS485 A USB Desktop Reader RS485 B optional CNV1000 BIOMANAGER Software • Connect the lines D0, D1, Gnd and +12V to the third party controller. •... -
Page 8: Configuring The Biometric Readers In Pros Software
8. CONFIGURING THE BIOMETRIC READERS IN PROS CS SOFTWARE 8.1 ADDING BIOMETRIC READER 1. Expand the Door item to view the readers 2. Right click on the reader and select properties (8.1) 3. In the Basic tab, for “Type” of the Reader select “B100PAD”. (8.2) 4. -
Page 9: Enrolling Fingerprints From A Reader
8.2 ENROLLING FINGERPRINTS FROM A READER 1. Open the Users Window and create a new user. Click on “New User”, put a name and ID(card number) and PIN Code. (8.7) 2. Go to the “Biometric” Tab 3. Select the reader(with left click) from which the enrollment will be done. (8.8) 4. -
Page 10: Enrolling Fingerprints From Desktop Reader
8.3 ENROLLING FINGERPRINTS FROM DESKTOP READER Plug the Swipe Desktop Reader in the PC. If the device is not installed automatically use the drivers located on the web site. It is installed in the same way as a USB Device. When the desktop reader has been installed it will automatically appear in the Software. (8.13) 1. -
Page 11: Deleting Fingerprints
8.4 DELETING FINGERPRINTS In General, the fingerprints are stored in the Biometric reader and in the Software. Deleting can be done only in the readers or from both places. Deleting one user from the biometric reader Select the User Click on “Delete User”. The User together with its fingerprints will be deleted from both the software and the fingerprint readers. -
Page 12: Firmware Update
8.6 FIRMWARE UPDATE Right-click on the reader and select Firmware update menu (8.18) On the Firmware update window, click on the Browse button (8.19). The default location of the firmware files installed with PROS CS is in the folder “Firmware”. Select the firmware file with a “xhc”... -
Page 13: Entry Mode
8.9 ENTRY MODE 8.9.1 Access Code or Finger Right click on the biometric reader Select “Properties” and go to the “Biometric” tab For Entry Mode select “Access Code or Finger” (8.20) Note: All the fingers and the Access Code will send the same wiegand number (8.21) 8.9.2 Access Code and Finger Right click on the biometric reader... -
Page 14: Configuring The Biometric Readers In Biomanager
9. CONFIGURING THE BIOMETRIC READERS IN BIOMANAGER BIOMANAGER CS is software for fingerprint management of XPR Biometric readers, when used with third party access controllers. Main functions: - Fingerprint Enrollment It can be done by ANY Biometric reader in the network or by Desktop (USB) Biometric reader. - Fingerprint Transfer Finger templates can be sent to any Reader in the Network. -
Page 15: Edit Reader
If reader is online, new line is added on top of the event table If reader is not online, following line is added on top of the event table If reader is online, right click on reader and select Upload configuration Check at event table if configuration was successful 9.3 EDIT READER Right-click on the reader and select Properties... -
Page 16: Add User
9.5 ADD USER 1. Open the Users Window and create a new user. Click on “New User”, put a name and ID(card number) and Access Code. (8.7) 2. Select the reader(with left click) from which the enrollment will be done. (8.8) 3. -
Page 17: Deleting Fingerprints
9.6 DELETING FINGERPRINTS In General, the fingerprints are stored in the Biometric reader and in the Software. Deleting can be done only in the readers or from both places. Deleting one user from the biometric reader Select the User Click on “Delete User”. The User together with its fingerprints will be deleted from both the software and the fingerprint readers. -
Page 18: Custom Wiegand
9.8 CUSTOM WIEGAND BIOMANAGER CS has defined Wiegand 26, 30, 34, 40 bit as standard options and other 3 Wiegand settings as user definable. To setup custom Wiegand format Select Wiegand menu from Settings At Wiegand setup window select one from customs Wiegand Set Wiegand parameter Click on Save button Note:... -
Page 19: Wiegand Protocol Description
10. WIEGAND PROTOCOL DESCRIPTION The data is sent over the lines DATA 0 for the logic “0” and DATA 1 for the logic “1”. Both lines use inverted logic, meaning that a pulse low on DATA 0 indicates a “0” and a pulse low on DATA 1 indicates a “1”.When the lines are high, no data is being sent. Only 1 of the 2 lines ( DATA 0 / DATA 1 ) can pulse at the same time. -
Page 20: Safety Precautions
11. SAFETY PRECAUTIONS Do not install the device in a place subject to direct sun light without protective cover. Do not install the device and cabling close to a source of strong electro-magnetic fields like radio-transmitting antenna. Do not place the device near or above heating equipments. If cleaning, do not spray or splash water or other cleaning liquids but wipe it out with smooth cloth or towel.
