Lex System 2I380NX Manual

Intel bay trail-i e3845 (quad core) cpu, ddr3l 4gb, 2 x poe lan / 1 x gbe / vga / audio / usb / com / pcie mini card
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Intel Bay Trail-I E3845 (Quad Core) CPU,
DDR3L 4GB, 2 x PoE LAN / 1 x GbE / VGA /
Intel Bay Trail-I E3845 (Quad Core 1.91 GHZ) CPU,
2 x PoE LAN, 1 x GbE, 2 x PCIe mini card slots, VGA,
CAUTION
RISK OF EXPLOSION IF BATTERY IS REPLACED
BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING
TO THE INSTRUCTIONS
NO. 2I380NX
Release date: Aug. 28. 2018
2I380NX
Audio / USB / COM / PCIe mini card
Audio, SATA, USB, COM
Micro SIM Card socket, Wide Range DC-IN
All-In-One

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2I380NX and is the answer not in the manual?

Questions and answers

Summary of Contents for Lex System 2I380NX

  • Page 1 2 x PoE LAN, 1 x GbE, 2 x PCIe mini card slots, VGA, Audio, SATA, USB, COM Micro SIM Card socket, Wide Range DC-IN CAUTION RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS NO. 2I380NX Release date: Aug. 28. 2018...

  • Page 2: Table Of Contents

    2-1 UNPACKING PRECAUTION ..................2-2 UNPACKING CHECKUP ....................2-3 DIMENSION-2I380NX ....................2-4 LAYOUT-2I380NX-CONNECTOR AND JUMPER ............2-4-1 LAYOUT-2I380NX-CONNECTOR AND JUMPER BOTTOM ........2-4-2 2I380NX-CONNECTOR AND JUMPER ..............2-5 LAYOUT-2I380NX-FUNCTION MAP ................2-5-1 LAYOUT-2I380NX-FUNCTION MAP BOTTOM ............2-5-2 FUNCTION MAP-2I380NX ..................
  • Page 3 3-13 SATA INTERFACE ..................... 3-14 MICRO SIM INTERFACE ................... 3-15 PCI EXPRESS MINI CARD ..................3-16 CONNEXTOR WAFER OF COMPATIBLE BRAND AND PART NUMBER LIST ..CHAPTER 4 INTRODUCTION OF BIOS ................ 4-1 ENTER SETUP ......................4-2 BIOS MENU SCREEN & FUNCTION KEYS ..............4-3 GETTING HELP ......................
  • Page 4 Copyright This manual is copyrighted and all rights are reserved. It does not allow any non authorization in copied, photocopied, translated or reproduced to any electronic or machine readable form in whole or in part without prior written consent from the manufacturer.

  • Page 5: Warning

    Warning ! Battery Batteries on board are consumables. The life time of them are not guaranteed. 2. Fanless solution with HDD The specifi cation & limitation of HDD should be considered carefully when the fanless solution is implemented. We will not give further notifi cation in case of changes of product information and manual.

  • Page 6: Hardware Notice Guide

    Hardware Notice Guide 1. Before linking power supply with the motherboard, please attach DC-in adapter to the motherboard fi rst. Then plug the adapter power to AC outlet. Always shut down the computer normally before you move the system unit or remove the power supply from the motherboard.
  • Page 7 Photo 1 Insert Unplug...

  • Page 8: Chapter 1 General Information

    Chapter-1 General Information The 2I380NX SBC with built-in 3 x Intel Giga LAN ports, 2 x PoE, 1 x Intel GbE LAN, 1 USB 3.0 & 3 USB 2.0 ports as an economic and fl exible hardware platform for industrial communication solution.

  • Page 9: Major Feature

    1-1 Major Feature Intel Bay-Trail-I E3845 1.91GHz SOC (Quad core) Intel Bay-Trail Integrated Graphics chipset, E4845 542MHz to 792MHz render clock frequency On board DDR3L SDRAM 4GB Memory, data transfer rate of 1333MT/s Support 3 x 10 / 100 / 1000 Mbps Intel LAN ports, 1 GBE LAN, 2 PoE Support 2 x RS232 / 485 / 422 selected by BIOS, 1 x USB3.0 and 1 x USB 2.0 Support extended 1 x Mini PCIe card for mSATA/USB device, 1 x Mini PCIe card for mSATA / PCIe / USB device.

  • Page 10: Specification

    1-2 Specifi cation SOC: Bay-Trail-I E3845 1.91GHz (Quad core) Memory: DDR3L SDRAM 4GB Memory, data transfer rate of 1333MT/s Graphics: Intel Bay-Trail Integrated Graphics chipset, E4845 542MHz to 792MHz render clock frequency I/O Chip: F81801U I/O chipset for 2 ports RS232 / 485 / 422 auto selected by BIOS 3 Intel I210-IT LAN chipset or Intel I211-AT LAN chipset (Option) with 10 / 100 / 1000 Mbps for PCIe x 1 V2.1 interface.

  • Page 11: Installing The Mini Pci-E Card

    1-3 Installing the Mini PCI-e Card 2. Install a mSATA card at the angle of 45°. 1. Unfasten the round-headed M2*6 (The half size Mini PCI-e slot supports mSATA) screw for half size Mini PCI-e. 3. Fasten a round-headed M2*6 screw.

  • Page 12: Packing List

    1-4 Packing List Material Code Description Detail Specifi cation Quantity 7G1901-1280S0001 MB-2I380NX-I44-E1 LF,supper Intel Baytrail Driver,Windows 6G8006-2349-0100 LEX Product Driver DVD 7/8.1 32/64 6G6001-2203-0100 SATA DATA Cable (Red) LF,L=25cm 6G6003-1009-0100 SATA Power Cable LF,L=25cm,1*4/2.0 to 180° SATA 15p 6G6003-7330-0100 Power Cable LF,L=9cm,2.0 1*4/DC JK...

  • Page 13: Chapter 2 Hardware Installation

    Chapter-2 Hardware Installation 2-1 Unpacking Precaution This chapter provides the information how to install the hardware of 2I380NX. Please follow section 1-5, 2-1 and 2-2 to check the delivery package and unpack carefully. Please follow the jumper setting procedure. NOTE! 1.

  • Page 14: Unpacking Checkup

    2-2 Unpacking checkup First of all, please follow all necessary steps of section 2-1 to protect 2I380NX from electricity discharge. With reference to section 1-4 please check the delivery package again with following steps: 1. Unpack the 2I380NX board and keep all packing material, manual and driver disc etc, do not dispose ! 2.

  • Page 15: Dimension-2I380Nx

    2-3 Dimension-2I380NX...

  • Page 16: Layout-2I380Nx-Connector And Jumper

    2-4 Layout-2I380NX-Connector and Jumper CBT1 JSB1 CFP1 CIO1 CPO1 MPCE1 MPCE2 CPI1...

  • Page 17: Layout-2I380Nx-Connector And Jumper Bottom

    2-4-1 Layout-2I380NX-Connector and Jumper Bottom SIM1 SATA1...

  • Page 18: 2I380Nx-Connector And Jumper

    2-4-2 2I380NX-Connector and Jumper CBT1 JSB1 CFP1 CIO1 CPO1 MPCE1 MPCE2 CPI1...

  • Page 19: Layout-2I380Nx-Function Map

    2-5 Layout-2I380NX-Function MAP COM2 Audio Line out/Mic in SM-Bus Front Panel LAN1 4DI/4DO 12V/5V out COM1 PoE LAN2 Mini Card1 (SATA or mSATA /USB) PoE LAN3 Mini Card2 (PCIE or mSATA /USB) Power/LAN LED Rest Button DC-IN...

  • Page 20: Layout-2I380Nx-Function Map Bottom

    2-5-1 Layout-2I380NX-Function MAP Bottom Micro SIM Card USB2.0 Port USB3.0/2.0 Port SATA Connector...

  • Page 21: Function Map-2I380Nx

    2-5-2 Function MAP- 2I380NX Clear CMOS Audio Line out / EXT.Battery Mic in Front Panel SM-Bus 4 Digital Input / Output COM2 12V/5V out COM1 Mini Card1 (mSATA / USB) USB Port Mini Card2 (PCIe / mSATA / USB) Power/LAN LED...

  • Page 22: List Of Jumpers

    2-6 List of Jumpers JSB1: CMOS DATA Clear 2-7 Jumper Setting Description A jumper is ON as a closed circuit with a plastic cap covering two pins. A jumper is OFF as an open circuit without the plastic cap. Some jumpers have three pins, labeled 1, 2, and 3.

  • Page 23: Jsb1: Cmos Data Clear

    2-8 JSB1: CMOS DATA Clear A battery must be used to retain the motherboard confi guration in CMOS RAM. Close Pin1 and pin 2 of JSB1 to store the CMOS data. To clear the CMOS,follow the procedures below: 1. Turn off the system and unplug the AC power 2.

  • Page 24: Chapter 3 Connection

    Chapter-3 Connection This chapter provides all necessary information of the peripheral's connections, switches and indicators. Always power off the board before you install the peripherals. 3-1 List of Connectors CBT1: Li 3V Battery 1x2pin (1.25mm) Wafer CA1: Line-out/Line-in/Mic-in/SPDIF-out 2x5 pin (2.0mm) Wafer CC1 : COM 2x5pin (2.0mm) wafer CC2 :...

  • Page 25: Cmos Battery Connector

    3-2 CMOS Battery connector CBT1: 3V Battery wafer connector (1x2pin 1.25mm) PIN NO. DESCRIPTION * Batter use Li 3V / 220mA (CR2032) Note: 1.When board without Adaptor plug in, this board power RTC consumption 2.7uA 2.If adaptor always plug in RTC power consumption 0.1uA CBT1 pin1...

  • Page 26: Audio Interface

    3-3 Audio interface CA7: Line-out / Line-in / Mic-in / SPDIF-out 2x5 pin (2.0mm) Wafer PIN NO. Description PIN NO. Description Line-out-R MIC-IN Line-in-R SPDIF-OUT Line-in-L Line-out-L MIC-IN pin1...

  • Page 27: Com Interface

    3-4 COM interface COM1/2 RS232 or RS485 or RS422 form BIOS select. COM1, COM2 default support RS232. CC1/2 wafer connector (2x5pin 2.0mm)(RS232 Mode) PIN NO. Description PIN NO. Description RI/Voltage Note: The pin9 RI can be modify to Power to supply device. The power voltage can be set +12V or +5V. The RI change Voltage function is OEM need change jumper.

  • Page 28: Front Panel Pin Header

    3-5 Front Panel Pin Header CFP1: Front Panel connector 2x5pin (2.0mm) wafer PIN NO. Description PIN NO. Description Power button pin Power button GND Reset pin Reset GND Power LED- Power LED+ HDD LED- HDD LED+ LAN LED- LAN LED+ pin1 CFP1 3-6 VGA Display interface...

  • Page 29: Digital Input/Output/Watch Dog Time

    3-7 Digital Input / Output / Watch Dog Time CIO1: DIO 0--3 (2x5pin 2.0mm wafer) PIN NO. Description PIN NO. Description DI-0 DO-3 DI-1 DO-2 DI-2 DO-1 DI-3 DO-0 Note: 1. DI pin default pull up 10KΩ to +5V 2. If use need isolate circuit to control external device 3.

  • Page 30: Appendix C:f75111N I C Dio Device

    Appendix C: F75111N I C DIO device 3-7-1 IO Device:F75111 under DOS The Sample code source you can download from http://tprd.info/lexwiki/index.php/IO_Device:F75111_under_DOS Source fi le: F75111_Dos_Src.rar Binary fi le: F75111_Dos_Bin.rar USERNAME & PASSWORD: sf How to use this Demo Application 1.Boot Ms-Dos Operating System 2.execute "75WDT.EXE"...

  • Page 31: Io Device: F75111 Under Windows

    3-7-2 IO Device: F75111 under Windows The Sample code source you can download from Source fi le: F75111_DIOSrc.rar http://tprd.info/lexwiki/index.php/IO_Device:F75111 Binary fi le: F75111_DemoBin.rar USERNAME & PASSWORD: sf How to use this Demo Application 1. Press the "Start" button to test DIO function 2.
  • Page 32 p.s. f75111 send "F75111_SetWDTEnable(BYTE byteTimer)" including a parameter "timer", if there's no disable signal (F75111_SetWDTDisable()) to stop it before timer countdown to 0, System will reboot. if there's disable signal received, resent Enable WDT signal, for a loop to prevent from reboot Introduction Initial Internal F75111 port address (0x9c) defi...
  • Page 33 Set output value void F75111::InterDigitalOutput(BYTE byteValue) BYTE byteData = 0; byteData = (byteData & 0x01 )? byteValue + 0x01 : byteValue; byteData = (byteData & 0x02 )? byteValue + 0x02 : byteValue; byteData = (byteData & 0x04 )? byteValue + 0x04 : byteValue; byteData = (byteData &...

  • Page 34: Io Device: F75111 Vb6 Under Windows

    Disable WatchDog void F75111_SetWDTDisable () WriteByte(F75111_INTERNAL_ADDR,WDT_CONFIGURATION,0x00); // Disable WatchDog 3-7-3 IO Device: F75111 VB6 under Windows The Sample code source you can download from Source fi le: 75111_VB_v10.rar http://tprd.info/lexwiki/index.php/IO_Device:F75111_VB6 Binary fi le: 75111_VB_Src.rar USERNAME & PASSWORD: sf How to use this Demo Application A Function - Enable WDT timer ,Key-in the value by seconds then system will reboot after value which you key-in in left text box !! B Function - Disable WDT timer ,Push down the button then WDT timer value will be clear !!
  • Page 35 SDK Function Introduction Function EnableWDT Function EnableWDT(timer As Integer) Call WriteI2CByte(&H3, &H3) Call WriteI2CByte(&H37, timer) Call WriteI2CByte(&H36, &H73) End Function Function DisableWDT Function DisableWDT() Call WriteI2CByte(&H36, &H0) End Function Function SetDOValue Function SetDOValue(dovalue As Integer) Call WriteI2CByte(&H23, &H0) Call WriteI2CByte(&H20, &HFF) Call WriteI2CByte(&H2B, &HFF) Call WriteI2CByte(&H21, dovalue) End Function...

  • Page 36: Io Device: F75111 Under Linux

    3-7-4 IO Device: F75111 under linux The Sample code source you can download from Source fi le: F75111v2.0L.tar.gz http://tprd.info/lexwiki/index.php/IO_Device:F75111_under_linux Binary fi le: F75111v2.0LBin.tar.gz USERNAME & PASSWORD: sf How to compile source code 1. Compile source code with Code::Blocks download and install the Code::Block with command "apt-get install codeblocks" Open an exist project(F75111.cbp) in Code::Blocks, click the compile button ( add an option 'pkg-confi...
  • Page 37 1. Press the "Start" button to test DIO function 2. Press the "Enable" button to test WDT function 3. Press the "Disable" button to disable WDT 4. Check the "Enable Loop" box and press "Enable" to do WDT loop test 5.
  • Page 38 Set output value void F75111::InterDigitalOutput(BYTE byteValue) BYTE byteData = 0; byteData = (byteData & 0x01 )? byteValue + 0x01 : byteValue; byteData = (byteData & 0x02 )? byteValue + 0x02 : byteValue; byteData = (byteData & 0x04 )? byteValue + 0x04 : byteValue; byteData = (byteData &...
  • Page 39 Enable WatchDog void F75111_SetWDTEnable (BYTE byteTimer) WriteByte(F75111_INTERNAL_ADDR,WDT_TIMER_RANGE ,byteTimer); // set WatchDog range and timer WriteByte(F75111_INTERNAL_ADDR,WDT_CONFIGURATION,WDT_TIMEOUT_FLAG | WDT_ENABLE | WDT_PULSE | WDT_PSWIDTH_100MS); // Enable WatchDog, Setting WatchDog confi gure Disable WatchDog void F75111_SetWDTDisable () WriteByte(F75111_INTERNAL_ADDR,WDT_CONFIGURATION,0x00); // Disable WatchDog...

  • Page 40: Lan Interface

    3-8 LAN Interface CL1/CL2/CL3 : RJ45 LAN port Giga /100Mb (RJ45 Jack) PIN NO. Description PIN NO. Description TR0-/TX+ TR2-/NC TR0+/TX- TR2+/RX- TR1-/RX+ TR3-/NC TR1+/NC TR3+/NC CL11/CL21/CL31 : LAN port Giga /100Mb 2x5pin (2.0mm) wafer(Option) PIN NO. Description PIN NO. Description TR0-/TX+ TR0+/TX-...

  • Page 41: I 2 C Bus Interface

    3-9 I C Bus Interface CO1: I C Bus 4pin (1.25mm)Wafer PIN NO. Description +3.3V C Clock pin1 C DATA 3-10 DC Power Input CPI1: DC -in 1x4 (2.0mm)Wafer Internal connector (Red) PIN NO. Description DC-IN(12V) Note: Very important check Dc-in Voltage CPI1 pin1...

  • Page 42: Dc +12V/+5V Voltage Power Output (1X4Pin 2.0Mm Wafer)(Black)

    3-11 DC +12V/+5 Voltage Power Output (1x4pin 2.0mm Wafer) (Black) CPO1: +12V/+5V DC voltage output PIN NO. Description +12V * * Note: Attention! Check Device Power in spec CPO1 pin1...

  • Page 43: Usb Interface

    3-12 USB Interface CU1: USB 3.0/2.0 Type A Connector PIN NO. Description PIN NO. Description USB3.0 TX+ USB 2.0 D- USB3.0 TX- USB 2.0 D+ USB3.0 RX+ USB3.0 RX- CU2: USB2.0 Port Type A PIN NO. Description DATA - DATA + USB 3.0/2.0 USB 2.0...
  • Page 44 CU3/CU4: USB2.0 port (1x4pin 1.25mm Wafer) PIN NO. Description DATA - DATA + Note: 1. CU3 signal share with mini card1. 2. CU4 signal share with mini card2. CU4 CU3 pin1 pin1...

  • Page 45: Sata Interface

    3-13 SATA Interface SATA1: SATA Port 1x7pin connector PIN NO. Description Note: 1. SATA1 support SATA 2.0 spec update 3Gb/sec. 2. CPO1 provide SATA HDD power +12V, GND, +5V 3. The SATA signal share with mSATA of MPCE1, but just one can be worked in same time. SATA1...

  • Page 46: Micro Sim Interface

    3-14 Micro SIM Interface SIM1: MicroSIM Card(Push-Push) Socket Pin defi ne. Follow ISO 7816-2 Smart Card Standard. PIN NO. Description PIN NO. Description DATA Note: 1. MPCE1 Pin 8, 10,12,14,16 for MicroSIM card reader use. PIN NO. Designation Description Power connection through which operating power is supplied to the microprocessor chip in the card.

  • Page 47: Pci Express Mini Card

    3-15 PCI Express Mini card MPCE1: Support USB + SATA1 & mSATA signal share MPCE2: Support USB + PCIe & mSATA auto-detect MPCE1/MPCE2 : Full size mini card PIN NO. Description PIN NO. Description +3.3V +1.5V PCIe-CLK- PCIe-CLK+ Reset PCIe-RX-/mSATA-RX+ +3.3V PCIe-RX+/mSATA-RX- +1.5V...

  • Page 48: Connextor Wafer Of Compatible Brand And Part Number List

    3-16 Connector wafer of Compatible Brand and part number list Location CKTS PITCH Brand Name Mating connector Cable housing 2x5 10Pin 2.0mm B10B-PHDSS PHDR-10VS CBT1 1x2 2Pin 1.25mm MOLEX 53047-0210 51021-0200 2x5 10Pin 2.0mm B10B-PHDSS PHDR-10VS 2x5 10Pin 2.0mm B10B-PHDSS PHDR-10VS CFP1 2x5 10Pin...

  • Page 49: Introduction Of Bios

    Chapter-4 Introduction of BIOS The BIOS is a program located in the Flash Memory on the motherboard. This program is a bridge between motherboard and operating system. When you start the computer, the BIOS program gains control. The BIOS first operates an auto-diagnostic test called POST (Power on Self Test) for all the necessary hardware, it detects the entire hardware devices and configures the parameters of the hardware synchronization.

  • Page 50: Bios Menu Screen & Function Keys

    4-2 BIOS Menu Screen & Function Keys In the above BIOS Setup main menu of, you can see several options. We will explain these options step by step in the following pages of this chapter, but let us fi rst see a short description of the function keys you may use here: ●...

  • Page 51: Getting Help

    4-3 Getting Help Status Page Setup Menu/ Option Page Setup Menu Press F1 to pop up a help window that describes the appropriate keys to use and the possible selections for the highlighted item. To exit the Help Window, press <Esc>.

  • Page 52: Menu Bars

    4-4 Menu Bars There are six menu bars on top of BIOS screen: Main To change system basic confi guration Advanced To change system advanced confi guration Security Password settings Power PME & Power button settings Boot Exit Save setting, loading and exit options. User can press the right or left arrow key on the keyboard to switch from menu bar.

  • Page 53: Advanced

    4-6 Advanced Boot Confi guration Please refer section 4-6-1 PCI Express Confi guration Please refer section 4-6-2 Video Confi guration Please refer section 4-6-3 Thermal Confi guration Please refer section 4-6-4 SATA Confi guration Please refer section 4-6-5 Console Redirection Please refer section 4-6-6 ACPI Table / Features Control Please refer section 4-6-7...

  • Page 54: Boot Configuration

    4-6-1 Boot Confi guration Numlock Select Power-on state for Numlock, default is <ON>...

  • Page 55: Pci Express Configuration

    4-6-2 PCI Express Confi guration PCIe 1/2/3/4 confi guration settings...

  • Page 56: Pci Express Root Port 1/2/3/4

    4-6-2-1 ► PCI Express Root Port 1/2/3/4 Control the PCI Express Root Port. The optional settings are: Enabled(default), Disabled. Select PCI Express port speed. The optional settings are: Gen1(default), Gen2 Select PCIE TXE ROM support The optional settings are: Disabled(default), Enabled...

  • Page 57: Video Configuration

    4-6-3 Video Confi guration Aperture Size The optional settings are: 128MB, 256MB(default) IGD - DVMT Pre-Allocated Use this item to select DVMT 5.0 pre-allocated (fi xed) graphics memory size used by the internal graphics device. The optional settings are: 64(default)128/256/512MB IGD - DVMT Total Gfx Mem Use this item to select DVMT 5.0 total graphics memory size used by the internal graphics device The optional settings are:128M, 256M(default), MAX...

  • Page 58: Thermal Configuration

    4-6-4 Thermal Confi guration Thermal Confi guration Parameters This Value controls the temperature of the ACPI Critical Trip Point, the point in which the OS will shutdown the system. Critical Trip point is the shutdown temperature, the default value is 110˚ The CPU frequency will auto reduce when cpu temperature arrived to passive Trip point.

  • Page 59: Sata Configuration

    4-6-5 SATA Confi guration SATA Controller Use this item to Enable or Disable SATA Device. The optional settings are: Enabled(default) or Disabled Chipset SATA Mode Determine how SATA controller(s) operate. The optional settings are: IDE Mode(default), AHCI Mode. SATA Speed Indicates the maximum speed the SATA controller can support.

  • Page 60: Console Redirection

    SATA Port 1 Connected to an ODD Use this item to Enable or Disable SATA Port1 ODD function The optional settings are: Enabled(default) or Disable 4-6-6 Console Redirection Console Serial Redirect Use this item to enable or disable Console Redirection. The optional settings are: Enabled, Disabled(default).

  • Page 61: Acpi Table/Features Control

    4-6-7 ACPI Table/Features Control ACPI Table / Features Control Select ACPI sleep state the system will enter when the SUSPEND button is pressed. The optional settings: DSDT - ACPI S3 (Suspend to RAM), Enabled or Disabled(default)

  • Page 62: Security

    4-7 Security Supervisor Password To set up an Supervisor password 1. Select Supervisor Password. The screen then pops up an Create New Password dialog. 2. Enter your desired password that is no less than 3 characters and no more than 10 characters. 3.

  • Page 63: Power

    4-8 Power Wake on LAN Determines the action taken when the system power is off and the PCI power management Enable wake up event occurs. The optional settings: Enabled, Disabled(default) Power Button Instant OFF(default) : The system will be turn off directly when push the power button. Delay 4 sec : The system will be turn off...

  • Page 64: Boot

    4-9 Boot Boot type Select boot type for Dual type ,Legacy boot type or UEFI boot type, default is Dual boot type Quiet Boot The optional settings are: Enabled(default), Disabled. EFI / Legacy Device order Determine EFI device fi rst or legacy device fi rst. The optional settings: EFI device fi...

  • Page 65: Exit

    4-10 EXIT Exit Saving Changes This item allows user to reset the system after saving the changes. Save Change Without Exit This item allows user to saving the changes but doesn’t restart. Exit Discard Changes This item allows user restart the system but no saving the changes Load Optimal Default Use this item to restore the optimal default for all the setup options.

  • Page 66: Device Manaager

    4-11 Device Manager Please press the key F10 when boot up to go into the Device Manager menu Serial Port 1/2 Confi guration Please refer section 4-11-1...

  • Page 67: Sio Fintek81801U

    4-11-1 SIO FINTEK81801U Serial Port 1/2 Use this item to enable or disable serial port (COM1 or COM2). The optional settings are: Enabled(default), Disabled. Serial Port 1 Base IO Address / Interrupt / Serial Mode Use this item to select an optimal setting for super IO device. The optional settings are: IO=3F8h;...
  • Page 68 Serial Mode RS232 driver(default) : When hardware select to RS232 or RS422 mode, please enter to RS232 driver. RS485 driver : When hardware select to RS485 mode, please enter to RS485 driver. It is the auto fl ow function for RS485. Power Fail This item specifi...

  • Page 69: Chapter 5 Driver Installation

    Chapter-5 DRIVER INSTALLATION There is a system installation DVD in the package. This DVD does not only include all the drivers you need but also some other free application programs and utility programs. In addition, this DVD also includes an auto detect software telling you which hardware is installed and which driver is needed so that your system can function properly.
  • Page 70 AUTOMATIC DRIVER INSTALLATION menu...
  • Page 71 1. INF Install Intel Baytrail chipset driver 2. VGA Install onboard VGA driver 3. Serial IO Install Serial IO driver (FOR Win 7 only) 4. xHCI Install Intel USB 3.0 xHCI driver (FOR Win 7 only) 5. HD Audio Install HD Audio Codec driver 6.

  • Page 72: Inf Install Intel Baytrail Chipset Driver (Example For Win8 64Bit)

    5-1 INF Install Intel Baytrail Chipset Driver (example for WIN8 64bit) 1. At the "AUTOMATIC DRIVER INSTALLATION 2. At the "Intel® Chipset Device Software" menu" screen, click "INF". screen, click "Next". 3. At the "License Agreement" 4. At the "Readme File Information" screen, screen, click "Yes"...
  • Page 73 5. Click "Next" 6. Click "Finish" & restart computer. NOTE: SYSTEM INSTALL will auto detect fi le path For Windows 7 64/32-bit, X:\driver\INTEL\BAY\INF\WIN7\infi nst_autol.exe For Windows 8 / 8.1 32/64-bit X:\driver\INTEL\BAY\INF\WIN_8_64\infi nst_autol.exe...

  • Page 74: Vga Install Intel Baytrail Vga Driver (Example For Win8 64Bit)

    5-2 VGA Install Intel Baytrail VGA Driver (example for WIN8 64bit) 1. At the"AUTOMATIC DRIVER INSTALLATION 2. At the "Welcome to the Setup Program menu"screen, click "VGA". screen, Click "Next". 3. At the "License Agreement” screen, 4. At the "Readme File Information” screen, Click "Yes"...
  • Page 75 6. Click "Finish" to restart computer 5. At the "Setup Progress" screen, Click "Next". NOTE: SYSTEM INSTALL will auto detect fi le path For Windows 7 32-bit, X:\driver\INTEL\BAY\VGA\WIN_7_32\Setup.exe For Windows 7 64-bit X:\driver\INTEL\BAY\VGA\WIN_7_64\Setup.exe For Windows 8 / Windows 8.1 32-bit X:\ \driver\INTEL\BAY\VGA\WIN_8_32\Setup.exe For Windows 8 / Windows 8.1 64-bit X:\driver\INTEL\BAY\VGA\WIN_8_64\Setup.exe...

  • Page 76: Serial Io Install Driver Baytrail Serial Io Driver (For Windows 7 Only)

    5-3 Serial IO Install Driver Baytrail Serial IO Driver (FOR Windows 7 only) 1. At the "AUTOMATIC DRIVER INSTALLATION 2. At the "Welcome to the Setup menu" screen, click "Serial IO". Programscreen, Click "Next". 3. At the "License Agreement" screen, 4.
  • Page 77 5. At the "Ready to install the program" screen, 6. Click "Finish" and restart computer Click "Install" NOTE: SYSTEM INSTALL will auto detect fi le path For Windows 7 32-bit, X:\driver\INTEL\BAY\SERIALIO\WIN7_32Bit.msi For Windows 7 64-bit X:\driver\INTEL\BAY\SERIALIO\Win7_64Bit.msi...

  • Page 78: Xhci Install Intel Usb 3.0 Xhci Driver (For Windows 7 Only)

    5-4 xHCI Install Intel USB 3.0 xHCI Driver (FOR Windows 7 only) 1. At the"AUTOMATIC DRIVER INSTALLATION 2. At the "Welcome to the Setup Program menu" screen, Click "xHCI". screen, Click "Next". 3. At the "License Agreement" screen, 4. At the "Readme File Information" screen, Click "Yes".
  • Page 79 6. Click "Finish" to restart computer 5. At the "Setup Progress" screen, Click "Next". NOTE: SYSTEM INSTALL will auto detect fi le path For Windows 7 32 / 64-bit, X:\driver\INTEL\BAY\XHCI\Driver_Installer\Setup.exe...

  • Page 80: Hd Audio Install High Definition Audio Driver

    5-5 HD Audio Install High Defi nition Audio Driver (example for WIN8 64bit) 1. At the "AUTOMATIC DRIVER 2. Click "Next". INSTALLATION menu", click "HD Audio". 3. Click "Finish" to restart computer. NOTE: SYSTEM INSTALL will auto detect fi le path For Windows 7 32 / 64-bit, Windows 8/8.1 32 / 64-bit X:\driver\INTEL\BAY\SOUND\Win7_Win8_Win81_R273.exe...

  • Page 81: Mbi Install Intel Mbi Driver (For Win 8/8.1 Only)

    5-6 MBI Install Intel MBI Driver (FOR Win 8/8.1 only) 1. At the "AUTOMATIC DRIVER INSTALLATION 2. At the "Welcome to the Setup Program menu", click "HD Audio" screen, Click "Next". 3. At the "License Agreement" screen, 4. At the "Setup Progress" screen, Click "Yes".
  • Page 82 5. Click "Finish" to restart computer NOTE: SYSTEM INSTALL will auto detect fi le path For Windows 8/8.1 32 / 64-bit, X:\driver\INTEL\BAY\MBI\Setup.exe...

  • Page 83: Txe Install Intel Txe Driver

    5-7 TXE Install Intel TXE driver 5-7-1 TXE Install for WIN8/WIN8.1 1. At the "AUTOMATIC DRIVER INSTALLATION 2. At the "Setup" screen, Click "Next". menu", click "TXE" 3. At the "License Agreement" screen, 4. Click "Next". Click "Yes".
  • Page 84 5. Click "Finish" & restart computer NOTE: SYSTEM INSTALL will auto detect fi le path For Windows 8 32 / 64-bit, X:\driver\INTEL\BAY\TXE\WIN_8\SetupTXE.exe For Windows 8.1 32 / 64-bit, X:\driver\INTEL\BAY\TXE\WIN_8.1\SetupTXE.exe...

  • Page 85: Txe Install For Win7

    5-7-2 TXE Install for WIN7 Please install PXE Patch fi rst. 1. At the "AUTOMATIC DRIVER INSTALLATION 2. At the "Windows Update" screen, menu", click "TXE Patch" Click "Yes". 3. Click "Finish" & restart computer 4. At the "AUTOMATIC DRIVER INSTALLATION menu", click "TXE"...
  • Page 86 5. At the "TXE Setup" screen, Click "Next". 6. At the "License Agreement" screen, Click "Yes". 8. Click "Finish" & restart computer 7. Click "Next". NOTE: SYSTEM INSTALL will auto detect fi le path For Windows 7 32 / 64-bit, TXE Patch X:\driver\INTEL\BAY\TXE\WIN_7\kmdf-1.11-Win-6.1-x86.msu X:\driver\INTEL\BAY\TXE\WIN_7\kmdf-1.11-Win-6.1-x64.msu...

  • Page 87: How To Update Insyde Bios

    STEP 3. Copy the latest BIOS for your LEX motherboard from our website to your bootable disc. STEP 4. (Here take 2I380NX as an example, please enter your motherboard’s name) Insert your bootable disc into X: (X could be C:, A: or others.

  • Page 88: Appendix B:resolution List

    Appendix B: Resolution list 640 x 480 x ( 256 / 16bit / 32bit ) 800 x 600 x ( 256 / 16bit / 32bit ) 1024 x 768 x ( 256 / 16bit / 32bit ) 1152 x 864 x ( 256 / 16bit / 32bit ) 1280 x 600 x ( 256 / 16bit / 32bit ) 1280 x 720 x ( 256 / 16bit / 32bit ) 1280 x 768 x ( 256 / 16bit / 32bit )
