- Page 1 C511 Installation & Users Guide All spares available from The Engine Shed Top Station Road Brackley NN13 7UG Tel: 0845 1308060 Fax: 01280 845345 Web: www.caterparts.com Copyright Notice: All rights reserved. No parts of this manual may be reproduced in any form without...
-
Page 4: Table Of Contents
INSTRUCTION MANUAL FOR DISHWASHERS CONTENTS CHAP 1 PREFACE ........................2 CHAP 2 INSTALLATION ......................2 ........................2 NPACKING ........................3 OSITIONING ....................3 LECTRICAL CONNECTION ....................4 ATER CIRCUIT HOOKUP ..................4 ONNECTION TO THE DRAIN LINE ....................4 INSE AID AND DETERGENT CHAP 3 RISKS AND IMPORTANT WARNINGS .............. -
Page 5: Chap 1 Preface
INSTRUCTION MANUAL FOR DISHWASHERS Chap 1 PREFACE This manual contains important safety warnings relating to installation, use and maintenance. Failure to observe the instructions in the enclosed documentation may compromise the safety of the appliance and immediately voids the warranty. Warnings: Keep all documentation in the vicinity of the appliance;... -
Page 6: Positioning
INSTRUCTION MANUAL FOR DISHWASHERS 2.2 Positioning • Check that there are no objects or materials in the installation area which may be damaged by the steam emitted by the appliance during operation, or if there are, make sure they are properly protected. •... -
Page 7: Water Circuit Hookup
INSTRUCTION MANUAL FOR DISHWASHERS 2.4 Water circuit hookup The appliance must be connected to its water supply with a flexible hose. A shut off valve (cock) must be installed between the water supply line and the appliance's solenoid valve. The cock must be close to the appliance. •... -
Page 8: Chap 3 Risks And Important Warnings
INSTRUCTION MANUAL FOR DISHWASHERS Chap 3 RISKS AND IMPORTANT WARNINGS • This appliance is intended solely for the use for which has been designed. Any other use is improper and hazardous. • The specialised technician responsible for installing the appliance must instruct the user on its operation and any attendant safety measures, including practical demonstrations. -
Page 9: Chap 4 Using The Machine
INSTRUCTION MANUAL FOR DISHWASHERS Chap 4 USING THE MACHINE 4.1 Key and symbols Referring to Fig.1: ON/OFF BUTTON 4 INFORMATION DISPLAY PROGRAMME SELECTION BUTTON 5 STATUS BAR (LED) START BUTTON 6 CHECK BAR (LED) Switching the dishwasher on Referring to Fig. 2 •... -
Page 10: Continuous Washing (*Optional)
INSTRUCTION MANUAL FOR DISHWASHERS Continuous washing (*optional) • This is an extended cycle; the time varies according to the model. • The cycle duration may be varied as required by pressing START (3) during the wash cycle, to interrupt the wash and start the rinse phase. 4.6 Automatic cycle start-up This function is used to make the chosen cycle start automatically when the door is closed. -
Page 11: Displaying Information
INSTRUCTION MANUAL FOR DISHWASHERS • Make sure the overflow has been removed. • Close the door and switch the dishwasher on. • Press the PROGRAMME SELECTION button (2) for the resin regeneration cycle; rEG will appear on the display. • Press the START button (3) to start a cycle. -
Page 12: Chap 5 Maintenance
INSTRUCTION MANUAL FOR DISHWASHERS Chap 5 MAINTENANCE 5.1 General rules Before doing any maintenance, completely drain out all water, shut off the power supply and close the water supply cock. Do not use water under pressure - it can damage the electrical equipment. Only wash the body panelling when it is cold, using only product specifically designed for steel. -
Page 13: Chap 6 Self Diagnostics
INSTRUCTION MANUAL FOR DISHWASHERS Chap 6 SELF DIAGNOSTICS The machine is equipped with a self-diagnosis system that registers and warns of a number of malfunctions. Fault Description and possible remedies No rinsing. The rinsing cycle was not completed correctly. Make sure that the rinsing nozzles are clean. -
Page 14: Chap 7 Settings
INSTRUCTION MANUAL FOR DISHWASHERS Chap 7 SETTINGS The following settings should only be configured by a qualified technician. The parameters listed below can be set during installation of afterwards, accessing the settings menu as follows: • Machine in standby with door open. •... -
Page 15: Number Of Cycles To Regenerate Resins
INSTRUCTION MANUAL FOR DISHWASHERS 7.1 Number of cycles to regenerate resins The number of cycles between one resin regeneration and the next depends on the hardness of the local water, and should be set in accordance with the table shown. Set the parameter dH in the settings menu as described in the paragraph: °F °F...
