- Page 1 All manuals and user guides at all-guides.com USR-G760c User Manual h.usriot.com USR-G760c User Manual File Version: V1.1 Jinan USR IOT Technology Limited / 37 www.usriot.com...
-
Page 2: Table Of Contents
4.2.4. Specific Symbol Instructions......................... 18 4.3. AT Instruction Set..............................19 4.4. AT Instructions..............................20 4.4.1. AT................................20 4.4.2. AT+H................................20 4.4.3. AT+Z................................21 4.4.4. AT+E................................21 4.4.5. AT+ENTM..............................21 4.4.6. AT+WKMOD............................. 21 4.4.7. AT+CMDPW............................. 22 Jinan USR IOT Technology Limited / 37 www.usriot.com... - Page 3 4.4.39. AT+HEARTEN............................32 4.4.40. AT+HEARTDT............................32 4.4.41. AT+HEARTTP............................32 4.4.42. AT+HEARTTM............................33 4.4.43. AT+HTPTP............................. 33 4.4.44. AT+HTPURL............................33 4.4.45. AT+HTPSV............................. 34 4.4.46. AT+HTPHD.............................34 4.4.47. AT+HTPTO............................. 34 4.4.48. AT+HTPFLT............................35 4.4.49. AT+DSTNUM............................35 4.4.50. AT+SMSEND............................35 4.4.51. AT+CISMSSEND...........................36 Jinan USR IOT Technology Limited / 37 www.usriot.com...
- Page 4 All manuals and user guides at all-guides.com USR-G760c User Manual h.usriot.com 4.4.52. AT+SMSFLT............................36 4.4.53. AT+SMSPH............................36 5. Contact Us..................................37 6. Disclaimer..................................37 7. Update History................................37 Jinan USR IOT Technology Limited / 37 www.usriot.com...
-
Page 5: Quick Start
1. Quick Start This chapter aims at getting start USR-G760c quickly. It’s recommended that user read this chapter systemically and operate it according to instruction to make a scientific knowledge. Following chapter will introduce specific details and instruction, user can read interested chapter according to need. -
Page 6: Product Overview
2. Product Overview 2.1. Brief Introduction USR-G760c is a 3G DTU which is apply to CDMA2000 network type, and supports CDMA2000 1xEV-DO Revision 0 and A high speed access. With “Transparent transmission” as core function and highly usability, user can integrate it to system, to realize data transmission based on CDMA2000 2.2. -
Page 7: Parameters
103 x 105 x 28(mm) Transparent transmission mode Work Mode Serial command mode Software Setting Command AT+command structure Parameters User Configuration setting software Form 1 Module Parameters 2.4. Hardware Introduction Figure 2 Hardware Interface Jinan USR IOT Technology Limited / 37 www.usriot.com... -
Page 8: Dimensions
USR-G760c User Manual h.usriot.com 2.5. Dimensions Figure 3 Haredware Dimensions 3. Functions This chapter introduce the functions of module, as the following diagram shown, you can get an overall knowledge of it. Jinan USR IOT Technology Limited / 37 www.usriot.com... -
Page 9: Parameters Setting
Below is the same. Setup by AT commands 1. Set work mode to be SMS transmit mode: AT+WKMOD=SMS 2. Set destination phone number: AT+DSTNUM=15866668888 3. Set filter SMS source phone number: AT+SMSFLT=ON Jinan USR IOT Technology Limited / 37 www.usriot.com... -
Page 10: Network Transparent Transmission Mode
USR-G760c support 2 socket connections online at the same time: socket A and socket B, they are independent. This DTU only support working at TCP Client and UDP Client. -
Page 11: Httpd Client Mode
Some applications need the serial device to request data from HTTP server. But these places with serial devices, maybe not convenient to access the Internet through a router. If there exist BS SIGNAL, we can build a bridge for serial device and HTTP server with USR-G760c. Setup by AT command 1. -
Page 12: Uart Frame Mechanism
3.3.1. Time Frame When USR-G760c receive data from UART, it will keep checking the time interval of two adjacent bytes. If the time interval is greater than or equal to a “time threshold”, the frame is finished. Or the module will keep receiving data until data is greater than or equal to 1K, then send this frame to network by TCP or UDP packet. -
Page 13: Length Frame
3.3.2. Length Frame When USR-G760c receive data from UART, it will keep checking the received number of bytes. If the number of bytes is greater than or equal to a “length threshold”, the frame is finished. Then module will send this frame to network by TCP or UDP packet. -
Page 14: Heartbeat Packet
In the application of server sending fixed query command to device, to reduce the traffic, user can choose to send heartbeat packet(query command) to serial device instead of send query command from the server. 3.4.4. Indicator Light The status indicator light of USR-G760c: POWER,WORK, STA, LINKA, LINKB Jinan USR IOT Technology Limited / 37... -
Page 15: Reload By Hardware
2. Click “Upgrade”, select correct firmware in the pop-up window 3. It shows “F,G,R” information in the software. 4. Press Reload button, power on USR-G760c, it will begin download firmware process, now release the reload button. Until download finished, power off the USR-G760c. Then power on again. -
Page 16: At Command
Serial device send “AT+ENTM” to module. Module send “OK” after receiving “AT+ENTM” and get into previous mode. Device will know module get back to previous work mode when receiving “OK” Jinan USR IOT Technology Limited / 37 www.usriot.com... -
Page 17: Command Format
Execute command or query <AT+><CMD>?<CR> current parameter Query the range/type of <AT+><CMD>=?<CR> parameters in the command Execute command or query <AT+><CMD><CR> current parameter value Set the parameter values for the <AT+><CMD>=<PARA><CR> command Jinan USR IOT Technology Limited / 37 www.usriot.com... -
Page 18: The Format Of "Response" In Commands
In AT command, these are specific symbols: Parameters can’t include these sumbols derectly, user need to escape in advance. Escape regulation: use [] to enclose the HEX of specific symbols, means input an ASCII code which is Jinan USR IOT Technology Limited / 37 www.usriot.com... -
Page 19: At Instruction Set
Query link status of socket A SOCKBLK Query link status of socket B SOCKATO Query/Set timeout of socket A short connection SOCKBTO Query/Set timeout of socket B short connection Registration packet instruction Jinan USR IOT Technology Limited / 37 www.usriot.com... -
Page 20: At Instructions
Function: Test command, used to test whether current device is active Format: Query: AT+H{CR} {CR}{LF}OK{CR}{LF}{CR}{LF}OK{CR}{LF} 4.4.2. AT+H Function: help command Format: Query: AT+H{CR} {CR}{LF}help message{CR}{LF}{CR}{LF}OK{CR}{LF} Parameters: Jinan USR IOT Technology Limited / 37 www.usriot.com... -
Page 21: At+Z
Execute specified function: AT+ENTM{CR} {CR}{LF}OK{CR}{LF} 4.4.6. AT+WKMOD Function: Query/Set device work mode Format: Query current parameter values: AT+WKMOD{CR} or AT+WKMOD?{CR} {CR}{LF}+WKMOD:mode{CR}{LF}{CR}{LF}OK{CR}{LF} Set: AT+WKMOD=mode{CR} {CR}{LF}OK{CR}{LF} Parameters: Jinan USR IOT Technology Limited / 37 www.usriot.com... -
Page 22: At+Cmdpw
Query current parameter values: AT+CSQ{CR} or AT+CSQ?{CR} {CR}{LF}+CSQ: rssi,ber {CR}{LF}{CR}{LF}OK{CR}{LF} Parameters: rssi: received signal strength indicator 0, equal to or less than 125 dBm 1~30, round numbers (31×（125－|rssi|）/ 50) dBm Jinan USR IOT Technology Limited / 37 www.usriot.com... -
Page 23: At+Reld
Function: Query firmware version Format: Query current parameter values: AT+VER{CR} or AT+VER?{CR} {CR}{LF}+VER:version{CR}{LF}{CR}{LF}OK{CR}{LF} Parameters: version: firmware version number 4.4.14. AT+SN Function: Query SN code Format: Jinan USR IOT Technology Limited / 37 www.usriot.com... -
Page 24: At+Iccid
{CR}{LF}OK{CR}{LF} Parameters: baud: baud rate, continus value range from 1200~460800 data bit, including: 5: 5 6: 6 7: 7 8: 8 stop bit, including: Jinan USR IOT Technology Limited / 37 www.usriot.com... -
Page 25: At+Uartft
length: packet length, range from 1~1000 bytes, pls refer to chapter 3.3 4.4.20. AT+RFCEN Function: Query/Set whether enable the analogous RFC2217 function Format: Query current parameter values: AT+RFCEN{CR} or AT+RFCEN?{CR} {CR}{LF}+RFCEN:status{CR}{LF}{CR}{LF}OK{CR}{LF} Set: AT+RFCEN=status{CR} Jinan USR IOT Technology Limited / 37 www.usriot.com... -
Page 26: At+Apn
address: destination server address, the address can be domain name or IP address port: destination server port, range from 1~65535 4.4.23. AT+SOCKB Function: Query/Set parameters of socket B Format: Query current parameter values: AT+SOCKB{CR} or AT+SOCKB?{CR} {CR}{LF}+SOCKB:protocol,address,port{CR}{LF}{CR}{LF}OK{CR}{LF} Jinan USR IOT Technology Limited / 37 www.usriot.com... -
Page 27: At+Sockaen
Set: AT+SOCKBEN=status{CR} {CR}{LF}OK{CR}{LF} Parameters: status: status of socket B, including: “on”: enable “off”: disable 4.4.26. AT+SOCKASL Function: Query/Set the link type in transmission of socket A Jinan USR IOT Technology Limited / 37 www.usriot.com... -
Page 28: At+Sockbsl
AT+SOCKALK{CR} or AT+SOCKALK?{CR} {CR}{LF}+SOCKALK:status{CR}{LF}{CR}{LF}OK{CR}{LF} Parameters: status: link status of socket A, including: “on”: connect “off”: desconnect 4.4.29. AT+SOCKBLK Function: Query whether socket B link established Format: Jinan USR IOT Technology Limited / 37 www.usriot.com... -
Page 29: At+Sockato
Query current parameter values: AT+SOCKIND{CR} or AT+SOCKIND?{CR} {CR}{LF}+SOCKIND:status{CR}{LF}{CR}{LF}OK{CR}{LF} Set: AT+SOCKIND=status{CR} {CR}{LF}OK{CR}{LF} Parameters: status: function of indicating which socket is data from, including: “on”: open “off”: close Jinan USR IOT Technology Limited / 37 www.usriot.com... -
Page 30: At+Regen
“CLOUD”: cloud function “USER”: user defined 4.4.35. AT+REGID Function: Query/Set registration ID Format: Query current parameter values: AT+REGID{CR} or AT+REGID?{CR} {CR}{LF}+REGID:id{CR}{LF}{CR}{LF}OK{CR}{LF} Set: AT+REGID=id{CR} {CR}{LF}OK{CR}{LF} Parameters: Jinan USR IOT Technology Limited / 37 www.usriot.com... -
Page 31: At+Regdt
Function: Query/Set registration parameters of USR cloud function Format: Query current parameter values: AT+CLOUD{CR} or AT+CLOUD?{CR} {CR}{LF}+CLOUD:id,password{CR}{LF}{CR}{LF}OK{CR}{LF} Set: AT+CLOUD=id,password{CR} {CR}{LF}OK{CR}{LF} Parameters: id: registration ID of USR cloud function, length is 20 bytes Jinan USR IOT Technology Limited / 37 www.usriot.com... -
Page 32: At+Hearten
4.4.41. AT+HEARTTP Function: Query/Set send type of heartbeat packet Format: Query current parameter values: AT+HEARTTP{CR} or AT+HEARTTP?{CR} {CR}{LF}+HEARTTP:type{CR}{LF}{CR}{LF}OK{CR}{LF} Set: AT+HEARTTP=type{CR} {CR}{LF}OK{CR}{LF} Parameters: type: send type, including: Jinan USR IOT Technology Limited / 37 www.usriot.com... -
Page 33: At+Hearttm
Format: Query current parameter values: AT+HTPURL{CR} or AT+HTPURL?{CR} {CR}{LF}+HTPURL:URL{CR}{LF}{CR}{LF}OK{CR}{LF} Set: AT+HTPURL=URL{CR} {CR}{LF}OK{CR}{LF} Parameters: URL: URL of HTTP request, example /1.php[3F], escape regulation pls refer to chapter 4.2.4 Jinan USR IOT Technology Limited / 37 www.usriot.com... -
Page 34: At+Htpsv
Function: Query/Set timeout time of HTTP request Format: Query current parameter values: AT+HTPTO{CR} or AT+HTPTO?{CR} {CR}{LF}+HTPTO:time{CR}{LF}{CR}{LF}OK{CR}{LF} Set: AT+HTPTO=time{CR} {CR}{LF}OK{CR}{LF} Parameters: time: timeout time of HTTP request, range from 1~600s Jinan USR IOT Technology Limited / 37 www.usriot.com... -
Page 35: At+Htpflt
Parameters: number: destination phone number of SMS type: encode type, including: 2: ASCII code, no compression 3: UCS8, both English and Chinese data: data of SMS Jinan USR IOT Technology Limited / 37 www.usriot.com... -
Page 36: At+Cismssend
Format: Query current parameter values: AT+SMSPH{CR} or AT+SMSPH?{CR} {CR}{LF}+SMSPH:status{CR}{LF}{CR}{LF}OK{CR}{LF} Set: AT+SMSPH=status{CR} {CR}{LF}OK{CR}{LF} Parameters: status: whether display SMS source phone number “on”: open “off”: close Jinan USR IOT Technology Limited / 37 www.usriot.com... - Page 37 6. Disclaimer This document provide the information of USR-G760c products, hasn’t been granted any theintellectual property license by forbid speak or other ways either explicitly or implicitly. Except for the duty of sales conditions and conditional declarations, we don’t take any other responsibilities. We don’t warrant the products sales and use explicitly or implicitly, including particular purpose merchantability and marketability, the tort liability of any other patent right, copyright, intellectual property right.
