Installation And Operation Manual
This manual is available for free download on the manufacturer's web site. It is a copyrighted document.
Re-sale is strictly prohibited. The manufacturer may update this manual from time to time and cannot be
responsible for problems, injuries, or damages arising out of the use of information contained in any manual
obtained from unauthorized sources.
Printed in Canada
www.valcourtinc.com
Stove Builder International Inc.
250 rue Copenhague, Saint-Augustin-de-Desmaures (Quebec),
After-sale service: 418-908-8002
E-mail: tech@sbi-international.com
READ AND KEEP THIS MANUAL FOR REFERENCE
US ENVIRONMENTAL PROTECTION AGENCY
PHASE II CERTIFIED WOOD FIREPLACE
Listed to standards ULC-S610 and UL 127
Manufactured by:
Canada, G3A 2H3
FP12 Mundo
by an accredited laboratory
45707A
09-09-2016
