global_main.book.book Page 1 Monday, July 19, 2021 6:36 PM
OWNER'S MANUAL
WASHING MACHINE
Before beginning installation, read these instructions
carefully. This will simplify installation and ensure that the
product is installed correctly and safely. Leave these
instructions near the product after installation for future
reference.
ENGLISH
FV1413S2BA
MFL71671243
Rev.00_082521
Copyright © 2021 LG Electronics Inc. All Rights Reserved.
www.lg.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FV1413S2BA and is the answer not in the manual?

Questions and answers

Related Manuals for LG FV1413S2BA

Summary of Contents for LG FV1413S2BA

  • Page 1 This will simplify installation and ensure that the product is installed correctly and safely. Leave these instructions near the product after installation for future reference. ENGLISH FV1413S2BA www.lg.com MFL71671243 Copyright © 2021 LG Electronics Inc. All Rights Reserved. Rev.00_082521...

  • Page 2: Table Of Contents

    Preparing the Wash Load ................23 Adding Detergents and Softeners ..............23 Programme Table ....................27 Extra Options and Functions ................31 SMART FUNCTIONS LG ThinQ Application ..................37 Smart Diagnosis ....................39 MAINTENANCE Cleaning After Every Wash................41 Cleaning the Appliance Periodically & Performing an Emergency Water Evacuation......................42...

  • Page 3: Safety Instructions

    global_main.book.book Page 3 Monday, July 19, 2021 6:36 PM SAFETY INSTRUCTIONS SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE The following safety guidelines are intended to prevent unforeseen risks or damage from unsafe or incorrect operation of the appliance. The guidelines are separated into ‘WARNING’ and ‘CAUTION’ as described below.
  • Page 4 global_main.book.book Page 4 Monday, July 19, 2021 6:36 PM SAFETY INSTRUCTIONS • Children should be supervised to ensure that they do not play with the appliance. • If the power cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.
  • Page 5 global_main.book.book Page 5 Monday, July 19, 2021 6:36 PM SAFETY INSTRUCTIONS • Do not modify the power plug provided with the appliance. If it does not fit the power outlet, have a proper outlet installed by a qualified electrician. • This appliance is equipped with a power cord having an equipment- earthing / grounding conductor (earthing pin) and a grounding power plug.
  • Page 6 • Do not touch the door during a high temperature programme. • In case of a water leak from the appliance or flood, disconnect the power plug and contact the LG Electronics customer information centre. • Turn off water taps to relieve pressure on hoses and valves and to minimize leakage if a break or rupture should occur.
  • Page 7 • Only qualified service personnel from LG Electronics service centre should disassemble, repair, or modify the appliance. Contact an LG Electronics customer information centre if you move and install the appliance in a different location.

  • Page 8: Installation Parts And Specifications

    global_main.book.book Page 8 Monday, July 19, 2021 6:36 PM INSTALLATION INSTALLATION Parts and Specifications NOTE • Appearance and specifications may change without notice to improve the quality of the appliance. Front View Rear View Control Panel Power Plug Detergent Dispenser Drawer Transit Bolts Drum Drain Hose...
  • Page 9 Page 9 Monday, July 19, 2021 6:36 PM INSTALLATION Specifications Model FV1413S2BA Power Supply 220‒240 V~, 50 Hz Product Weight 73 kg Dimension(mm) D’’ D’ 1145...
  • Page 10 global_main.book.book Page 10 Monday, July 19, 2021 6:36 PM INSTALLATION Accessories *1 The included accessories vary depending on the model you purchased. Cold Supply Hose Anti–slip Sheets*1 Spanner Elbow Bracket for Securing Drain Hose Caps for Covering Transit Bolt Holes Tie Strap*1...

  • Page 11: Installation Place Requirements

    global_main.book.book Page 11 Monday, July 19, 2021 6:36 PM INSTALLATION Installation Place Index Clearance (mm) Requirements Before installing the appliance, check the following information to make sure that the appliance should be installed in a correct place. WARNING Installation Location •...

  • Page 12: Unpacking The Appliance

    • You can purchase rubber cups (part No. codes and ordinances. 4620ER4002B) from the LG service centre. Unpacking the Appliance Ventilation Lifting the Appliance Off the • Make sure that air circulation around the...

  • Page 13: Levelling The Appliance

    global_main.book.book Page 13 Monday, July 19, 2021 6:36 PM INSTALLATION Starting with the bottom two transit bolts • If the appliance rocks when pushing the top use the spanner (included) to fully loosen all plate of the appliance diagonally, adjust the feet transit bolts by turning them counterclockwise.
  • Page 14 If this occurs, install the anti- stand or elevated surface unless it is slip sheets under the levelling feet and adjust the manufactured by LG Electronics for use with this level. model. Clean the floor to attach the anti-slip sheets.

  • Page 15: Connecting The Water Supply Hose

    global_main.book.book Page 15 Monday, July 19, 2021 6:36 PM INSTALLATION Connecting the Water Connecting the Hose to the Water Tap Supply Hose Connecting Screw-Type Hose to Tap with Thread Note for Connection Screw the supply hose connector onto the water supply tap.
  • Page 16 global_main.book.book Page 16 Monday, July 19, 2021 6:36 PM INSTALLATION completely to the tap and then tighten the connector latch plate. Make sure the adapter hose by screwing it to the right. locks into place. Connecting One Touch Type Hose to Tap Without Thread Unscrew the adapter ring plate and loose...

  • Page 17: Installing The Drain Hose

    global_main.book.book Page 17 Monday, July 19, 2021 6:36 PM INSTALLATION • Make sure that the hose should not be kinked or • When installing the drain hose to a sink, secure it trapped. tightly with string. Installing the Drain Hose Installing the Drain Hose with the Elbow Bracket The drain hose should not be placed higher than...

  • Page 18: Operation Operation Overview

    global_main.book.book Page 18 Monday, July 19, 2021 6:36 PM OPERATION OPERATION Operation Overview CAUTION Using the Appliance • Remove items from the flexible door seal gasket to prevent clothing and door seal damage. Before the first wash, select the Cotton wash programme and add a half amount of the detergent.
  • Page 19 global_main.book.book Page 19 Monday, July 19, 2021 6:36 PM OPERATION • Now select a wash temperature and spin speed. Pay attention to the fabric care label of your clothes. • Pressing the Start/Pause button without selecting a programme will cause the Cotton programme to begin immediately, using the default settings.

  • Page 20: Control Panel

    • This allows you to select an additional programmes and will light when selected. Remote Start With the LG ThinQ app, you can use a smartphone to control your appliance remotely. • In order to use this function, refer to SMART FUNCTIONS.
  • Page 21 global_main.book.book Page 21 Monday, July 19, 2021 6:36 PM OPERATION Description Customizing Washing Programme Buttons Use these buttons to adjust the water temperature or spin speed settings for the selected programme. • The current settings are shown in the display. •...
  • Page 22 global_main.book.book Page 22 Monday, July 19, 2021 6:36 PM OPERATION Description AI DD • AI DD provides the appropriate drum rotation actions after load sensing is completed. • is activated when the Cotton, Mixed Fabric, and Easy Care programmes are selected and operated.

  • Page 23: Preparing The Wash Load

    global_main.book.book Page 23 Monday, July 19, 2021 6:36 PM OPERATION Preparing the Wash Load NOTE Sort the wash load for best washing results, and • The dashes under the symbol give you then prepare the clothes according to the symbols information about the type of fabric and the on their care labels.
  • Page 24 global_main.book.book Page 24 Monday, July 19, 2021 6:36 PM OPERATION detergents that are suitable for Drum (front • Part load: 1/2 of the normal amount. load) type washers. • Minimum load: 1/3 of full load. • If too many suds occur, reduce the detergent amount.
  • Page 25 global_main.book.book Page 25 Monday, July 19, 2021 6:36 PM OPERATION • The ezDispense drawer has two CAUTION compartments. Put the liquid detergent into the right hand side compartment and the • Close lid and cover of the compartment securely liquid fabric softener or liquid detergent into before use.
  • Page 26 global_main.book.book Page 26 Monday, July 19, 2021 6:36 PM OPERATION Open the detergent dispenser drawer. NOTE • The manual dispenser cannot be used for dispensing pre-wash detergent. • When adding detergent tablets and water softener, be sure to turn off the ezDispense function.

  • Page 27: Programme Table

    global_main.book.book Page 27 Monday, July 19, 2021 6:36 PM OPERATION Programme Table Washing Programme Cotton 40 °C (Cold to 95 °C) Max. Load: Rating Description Washes normally soiled clothes by combining various drum motions. Cotton+ 60 °C (Cold to 60 °C) Max.
  • Page 28 global_main.book.book Page 28 Monday, July 19, 2021 6:36 PM OPERATION Hand/Wool 30 °C (Cold to 40 °C) Max. Load 2 kg Description Washes hand-washable and machine-washable delicate clothes such as washable wool, lingerie, dresses etc. • Use detergent for machine washable woolens Sportswear 40 °C (Cold to 40 °C) Max.
  • Page 29 global_main.book.book Page 29 Monday, July 19, 2021 6:36 PM OPERATION Extra Options *1 This option is automatically inserted in the programme and can not be deselected. NOTE • Rinse+, Delay End and Add Item options can be selected for every washing programme in the table below.
  • Page 30 global_main.book.book Page 30 Monday, July 19, 2021 6:36 PM OPERATION Spin Speed Programme Default Available Mixed Fabric 1000 rpm Easy Care 1400 rpm Silent Wash 800 rpm Up to 1000 rpm Allergy Care 1400 rpm Delicates 800 rpm Up to 800 rpm Hand/Wool 800 rpm Up to 800 rpm...

  • Page 31: Extra Options And Functions

    global_main.book.book Page 31 Monday, July 19, 2021 6:36 PM OPERATION Extra Options and Press the Power button. Functions Add detergent. You can use the extra options and functions to customize the programmes. Select a washing programme. Customizing a Washing Programme Customize the washing programme (Temp., Spin, Rinse+ and Intensive) as necessary.
  • Page 32 global_main.book.book Page 32 Monday, July 19, 2021 6:36 PM OPERATION Press the Start/Pause button. NOTE Add Item • Selecting this option will tumble the clothes You can use this option in order to add or remove briefly every few minutes for up to 30 minutes clothes after the washing programme has started.
  • Page 33 global_main.book.book Page 33 Monday, July 19, 2021 6:36 PM OPERATION Changing Dispense Level for a Single • The delay time is the time to the end of the programme, not the start. The actual running Load time may vary due to water temperature, clothes and other factors.
  • Page 34 global_main.book.book Page 34 Monday, July 19, 2021 6:36 PM OPERATION Using both Dispensers for Liquid NOTE Detergent • The Delicates, Hand/Wool,Sportswear, and Tub Clean cycles turn the ezDispense function off by default. Changing Default Dispense Amounts The default settings are configured to dispense 42 ml of detergent and 30 ml of softener for 4-6 kg of NOTE normally soiled laundry.
  • Page 35 global_main.book.book Page 35 Monday, July 19, 2021 6:36 PM OPERATION Press and hold the Dispenser 1 and Dispenser Press the Power button. 2 buttons at the same time for 3 seconds. Press and hold the Spin button for 3 seconds to Press the Dispenser 2 button to light up the clean the connected hose.
  • Page 36 global_main.book.book Page 36 Monday, July 19, 2021 6:36 PM OPERATION Press and hold the Delay End and Add Item buttons at the same time for 3 seconds to deactivate this function. Beep On/Off This appliance plays a melody when it starts and stops.

  • Page 37: Smart Functions

    Page 37 Monday, July 19, 2021 6:36 PM SMART FUNCTIONS SMART FUNCTIONS LG ThinQ Application notifications on a smartphone. The notifications are triggered even if the LG ThinQ application is off. The LG ThinQ application allows you to communicate with the appliance using a smartphone.
  • Page 38 Use a smartphone to control your appliance wireless router manual. remotely. You can also monitor your cycle • LG ThinQ is not responsible for any network operation so you know how much time is left in the connection problems or any faults, cycle.

  • Page 39: Smart Diagnosis

    LG ThinQ application. 20 cm between the device and the body. • Launch the LG ThinQ application and select the Smart Diagnosis feature in the menu. Follow the instructions provided in the LG ThinQ Open Source Software Notice application.
  • Page 40 global_main.book.book Page 40 Monday, July 19, 2021 6:36 PM SMART FUNCTIONS Place the mouthpiece of your smartphone close to the logo. Press and hold the Temp. button for 3 seconds or longer while holding the smartphone mouthpiece to the logo until the data transfer is complete.

  • Page 41: Maintenance

    global_main.book.book Page 41 Monday, July 19, 2021 6:36 PM MAINTENANCE MAINTENANCE WARNING • Unplug the appliance before cleaning to avoid the risk of electric shock. Failure to follow this warning may result in serious injury, fire, electric shock, or death. •...

  • Page 42: Cleaning The Appliance Periodically & Performing An Emergency Water Evacuation

    global_main.book.book Page 42 Monday, July 19, 2021 6:36 PM MAINTENANCE Cleaning the Appliance WARNING Periodically & Performing • Leave the door open to dry inside of the an Emergency Water appliance only if the children are supervised at home. Evacuation Tub Clean Cleaning the Water Inlet Filter This is a special function to help clean the inside of...
  • Page 43 global_main.book.book Page 43 Monday, July 19, 2021 6:36 PM MAINTENANCE Cleaning the Drain Pump Filter CAUTION and Performing an Emergency • Be careful when draining, as the water may be Water Evacuation hot. The drain filter collects threads and small objects •...
  • Page 44 global_main.book.book Page 44 Monday, July 19, 2021 6:36 PM MAINTENANCE Open the lids. Securely close the covers on the ezDispense compartments. Clean the inserts with warm water. Wipe off any moisture with a dry towel or cloth • Rinse the drawer in warm water to dissolve after cleaning.

  • Page 45: Troubleshooting

    Operation of your appliance can lead to errors and malfunctions. The following tables contain possible causes and notes for resolving an error message or malfunction. It is recommended to read the tables carefully below in order to save your time and money that may cost for calling to LG Electronics service centre.
  • Page 46 • Check and clean the drain filter. Door sensor malfunctions. dE dE1 dEz dE4 DOOR ERROR • Please call LG service centre. You can find your local LG service centre phone number in the warranty card. This is a control error. CONTROL ERROR •...
  • Page 47 global_main.book.book Page 47 Monday, July 19, 2021 6:36 PM TROUBLESHOOTING ezDispense Error Messages Symptoms Possible Cause & Solution The amount of liquid detergent in the detergent compartment did not E d1 decrease. ezDispense ERROR 1 After putting the detergent into the detergent compartment, it was left for a long time and the detergent hardened.
  • Page 48 global_main.book.book Page 48 Monday, July 19, 2021 6:36 PM TROUBLESHOOTING Symptoms Possible Cause & Solution Thumping sound Heavy clothes may produce a thumping sound. This is usually normal. • If the sound continues, the appliance is probably out of balance. Stop and redistribute the clothes.
  • Page 49 global_main.book.book Page 49 Monday, July 19, 2021 6:36 PM TROUBLESHOOTING Symptoms Possible Cause & Solution Appliance does not Control panel has powered off due to inactivity. operate. • This is normal. Press the Power button to turn the appliance on. Appliance is unplugged.
  • Page 50 global_main.book.book Page 50 Monday, July 19, 2021 6:36 PM TROUBLESHOOTING Symptoms Possible Cause & Solution Appliance is not filling Inlet filter clogged. properly. • Make sure the inlet filters on the fill valves are not clogged. Inlet hoses may be kinked. •...
  • Page 51 global_main.book.book Page 51 Monday, July 19, 2021 6:36 PM TROUBLESHOOTING Symptoms Possible Cause & Solution Staining Bleach or softener is dispensed too soon. • Dispenser compartment is overfilled. It makes bleach or softer dispensed rapidly. Always measure bleach or softener to prevent overfilling. •...
  • Page 52 global_main.book.book Page 52 Monday, July 19, 2021 6:36 PM TROUBLESHOOTING ezDispense Symptoms Possible Cause & Solution Refill Alarm continues Detergent/softener has built up on the fluid level sensor. to display when • Open the compartment covers and clean the insides of the ezDispense detergent/softener is compartments with warm water.
  • Page 53 • Find the Wi-Fi network connected to your smartphone and remove it, then not connected to the register your appliance on LG ThinQ. Wi-Fi network. Mobile data for your smartphone is turned on. • Turn off the Mobile data of your smartphone and register the appliance using the Wi-Fi network.
  • Page 54 global_main.book.book Page 54 Monday, July 19, 2021 6:36 PM Memo...
  • Page 55 global_main.book.book Page 55 Monday, July 19, 2021 6:36 PM Memo...
  • Page 56 global_main.book.book Page 55 Monday, July 19, 2021 6:36 PM...
