Summary of Contents for QNAP QuCPE-701 Series

  • Page 1 QuCPE-701x QuCPE-7010 QuCPE-7012 User Guide Document Version: 4 07/07/2021...

  • Page 2: Table Of Contents

    QuCPE-701x User Guide Contents 1. Preface About This Guide............................3 Audience...............................3 Document Conventions..........................3 2. Product Overview About the QuCPE-701x..........................4 Hardware Specifications..........................4 Package Contents............................6 Components..............................6 Front Panel............................... 7 Rear Panel..............................8 System Board............................8 Safety Information............................9 Installation Requirements........................... 10 3.
  • Page 3 VCCI Notice..............................41 BSMI Notice..............................42 SJ/T 11364-2006............................42...

  • Page 4: Preface

    QuCPE-701x User Guide 1. Preface About This Guide This guide provides information about the device and step-by-step instructions on installing the hardware. It also provides instructions on basic operations and troubleshooting information. Audience This document is intended for consumers and storage administrators. This guide assumes that the user has a basic understanding of storage and backup concepts.

  • Page 5: Product Overview

    Hardware Specifications Warning If your QNAP product has hardware defects, return the product to QNAP or a QNAP- authorized service center for maintenance or replacement. Any attempt to repair or perform maintenance procedures on the product by you or an unauthorized third party invalidates the warranty.
  • Page 6 Memory slots 8 x DDR4 UDIMM or RDIMM Note Use only QNAP memory modules to maintain system performance and stability. For devices with more than one memory slot, use QNAP modules with identical specifications. Using unsupported modules may degrade performance, cause errors, or prevent the operating system from starting.

  • Page 7: Package Contents

    • Rail kits are not included with the NAS and must be purchased separately. For details, contact an authorized reseller or go to http://shop.qnap.com. • Information on rail kit installation can be found in the installation guide included in the rail kit package.

  • Page 8: Front Panel

    QuCPE-701x User Guide Front Panel Component Component Gigabit Ethernet activity LED LCD panel Gigabit Ethernet speed LED LCD enter button 10 Gigabit Ethernet activity LED LCD select button 10 Gigabit Ethernet speed LED Reset button USB 2.0 Type-A port Warning LED Console port (RJ45) USB 3.2 Gen 1 Type-A port Drive LED...

  • Page 9: Rear Panel

    QuCPE-701x User Guide Rear Panel Component Component Power supply unit 1 Power button Power supply unit 2 PCIe full-height covers System Board Product Overview...

  • Page 10: Safety Information

    QuCPE-701x User Guide Component Component PCIe slot (PCIe 3.0 x8) Memory slots (blue) Note Install memory modules in blue slots first. Memory slots 2.5-inch HDD/SSD slots Network module slot Safety Information The following instructions help ensure personal safety and environmental safety. Read these instructions carefully before performing any operations.

  • Page 11: Installation Requirements

    • Flat, anti-static surface without exposure to direct sunlight, liquids, or chemicals Hardware and peripherals • Storage drives For the list of compatible drive models, go to https:// www.qnap.com/compatibility. • Network cable Tools • Phillips #1 or #2 screwdriver • Flat head screwdriver • Anti-static wrist strap...

  • Page 12: Installation And Configuration

    QuCPE-701x User Guide 3. Installation and Configuration This chapter provides specific hardware and firmware installation and configuration steps. Hardware Installation This section provides information on installing drives, memory modules, and expansion cards. Installing 2.5-inch Solid-state Drives Warning • Installing a drive deletes all data on the drive. •...
  • Page 13 QuCPE-701x User Guide 5. Remove the drive tray. a. Loosen the screws. b. Pull the tray out. 6. Install a drive on the tray. a. Place the drive on the tray so that the holes on the sides of the drive are aligned with the holes on the sides of the tray.
  • Page 14 QuCPE-701x User Guide 7. Attach the drive tray. a. Attach the screws. 8. Attach the case cover. 9. Attach the screws. Installation and Configuration...

  • Page 15: Replacing Memory Modules

    This device also comes with two ECC memory modules. ECC memory modules provide extra protection from undetected data corruption. Use only QNAP memory modules to maintain system performance and stability. You can purchase QNAP memory modules from authorized resellers. For details on slot numbering and color, see System Board.
  • Page 16 QuCPE-701x User Guide • Other moving components: Keep your hands and other body parts away from other moving components. 1. Power off the device. 2. Disconnect the power cord from the electrical outlet. 3. Disconnect all cables and external attachments. 4.
  • Page 17 QuCPE-701x User Guide Note Attempting to remove a module that is not completely released may damage the module and the motherboard. b. Verify that the module has tilted upward and is completely released from the slot. c. Hold the module by the edges. d.
  • Page 18 QuCPE-701x User Guide 7. Attach the case cover. 8. Attach the screws. 9. Connect all cables and external attachments. 10. Power on the device. 11. Verify that the module is recognized by the device. a. Log on to QNE as administrator. b.

  • Page 19: Installing Expansion Cards

    QuCPE-701x User Guide Installing Expansion Cards The QuCPE-701x series supports selected expansion cards, some of which require QNAP PCIe brackets. QNAP-branded expansion cards purchased from the company website are shipped with the brackets necessary to fit the QuCPE-701x series. Warning •...
  • Page 20 QuCPE-701x User Guide 5. Remove the PCIe cover. a. Remove the screws that secure the cover to the bracket. Installation and Configuration...
  • Page 21 QuCPE-701x User Guide b. Pull the cover away from the slot. Installation and Configuration...
  • Page 22 QuCPE-701x User Guide 6. Install the expansion card. a. Hold the card by the edges. b. Insert the card into the slot. Installation and Configuration...
  • Page 23 QuCPE-701x User Guide c. Attach the screws. Installation and Configuration...
  • Page 24 QuCPE-701x User Guide 7. Attach the case cover. 8. Attach the screws. Installation and Configuration...

  • Page 25: Qne Installation

    QuCPE-701x User Guide 9. Connect all cables and external attachments. 10. Connect the power cord to the electrical outlet. 11. Power on the device. QNE Installation The QuCPE-701x uses the QNE operating system. You can install QNE using any of the following methods. Method Description Requirements...

  • Page 26: Installing Qne Using Stand-Alone Mode

    • Confirm password: Enter your password again. 8. Click Next. 9. Specify the time zone, date, and time. QNAP recommends connecting to an NTP server to ensure that the device follows the Coordinated Universal Time (UTC) standard. 10. Click Apply.

  • Page 27: Installing Qne Using Cloud Management Mode

    3. Run Qfinder Pro on a computer that is connected to the same local area network. Note To download Qfinder Pro, go to https://www.qnap.com/utilities. 4. Locate the switch in the list and then double-click the name or IP address. The Smart Installation Guide opens in the default web browser.

  • Page 28: Basic Operations

    QuCPE-701x User Guide 4. Basic Operations This chapter describes basic device operations. Buttons Power Button Operation User Action Result Power on Press the button once. The device powers on. Power off Press and hold the button for 1.5 The device powers off. seconds.

  • Page 29: Lcd Panel

    QuCPE-701x User Guide Basic system reset User Action Result Advanced system Press and hold the The default factory settings are restored. reset button for 15 seconds. • To retrieve old data after an advanced system reset, recreate the previous folder structure on the device. LCD Panel The LCD panel allows you to perform the following operations: •...
  • Page 30 QuCPE-701x User Guide Status Description System Status Flashes green and red alternately every • The drive is being formatted. 0.5 seconds • The device is being initialized. • The operating system is being updated. • RAID rebuilding is in progress. •...

  • Page 31: Audio Alert

    QuCPE-701x User Guide Status Description Gigabit Ethernet Green The network connection is operating at 1 speed Gbps. Orange The network connection is operating at 100 Mbps. There is no network connection. Gigabit Ethernet Green A network connection has been activity established.

  • Page 32: Troubleshooting

    2. Remove all drives. 3. Power on the device. 4. Locate the device using Qfinder Pro. 5. Reinsert the drives. 6. Continue with the QNE installation. Support and Other Resources QNAP provides the following resources: Resource Documentation https://download.qnap.com Compatibility List https://www.qnap.com/compatibility Expansion Unit Compatibility http://www.qnap.com/go/compatibility-expansion...

  • Page 33: Glossary

    Enables you to access QNAP devices over the internet without configuring complex port forwarding settings Qfinder Pro QNAP utility that lets you locate and access QNAP NAS devices in your local area network QNAP operating system for the QuCPE device...

  • Page 34: Notices

    No license, express or implied, by estoppels or otherwise, to any intellectual property rights is granted by this document. Except as provided in QNAP's terms and conditions of sale for such products, QNAP assumes no liability whatsoever, and QNAP disclaims any express or implied warranty, relating to sale and/or use of QNAP products including liability or warranties relating to fitness for a particular purpose, merchantability, or infringement of any patent, copyright or other intellectual property right.
  • Page 35 QuCPE-701x User Guide Free Software Foundation, use the GNU General Public License for most of our software; it applies also to any other work released this way by its authors. You can apply it to your programs, too. When we speak of free software, we are referring to freedom, not price. Our General Public Licenses are designed to make sure that you have the freedom to distribute copies of free software (and charge for them if you wish), that you receive source code or can get it if you want it, that you can change the software or use pieces of it in new free programs, and that you know you can do these things.
  • Page 36 QuCPE-701x User Guide tells the user that there is no warranty for the work (except to the extent that warranties are provided), that licensees may convey the work under this License, and how to view a copy of this License. If the interface presents a list of user commands or options, such as a menu, a prominent item in the list meets this criterion.
  • Page 37 QuCPE-701x User Guide You may convey verbatim copies of the Program's source code as you receive it, in any medium, provided that you conspicuously and appropriately publish on each copy an appropriate copyright notice; keep intact all notices stating that this License and any non-permissive terms added in accord with section 7 apply to the code;...
  • Page 38 QuCPE-701x User Guide the object code. If the place to copy the object code is a network server, the Corresponding Source may be on a different server (operated by you or a third party) that supports equivalent copying facilities, provided you maintain clear directions next to the object code saying where to find the Corresponding Source.
  • Page 39 QuCPE-701x User Guide a. Disclaiming warranty or limiting liability differently from the terms of sections 15 and 16 of this License; or b. Requiring preservation of specified reasonable legal notices or author attributions in that material or in the Appropriate Legal Notices displayed by works containing it; or c.
  • Page 40 QuCPE-701x User Guide An “entity transaction” is a transaction transferring control of an organization, or substantially all assets of one, or subdividing an organization, or merging organizations. If propagation of a covered work results from an entity transaction, each party to that transaction who receives a copy of the work also receives whatever licenses to the work the party's predecessor in interest had or could give under the previous paragraph, plus a right to possession of the Corresponding Source of the work from the predecessor in interest, if the predecessor has it or can get it with reasonable efforts.
  • Page 41 QuCPE-701x User Guide If conditions are imposed on you (whether by court order, agreement or otherwise) that contradict the conditions of this License, they do not excuse you from the conditions of this License. If you cannot convey a covered work so as to satisfy simultaneously your obligations under this License and any other pertinent obligations, then as a consequence you may not convey it at all.

  • Page 42: Ce Notice

    Important Any modifications made to this device that are not approved by QNAP Systems, Inc. may void the authority granted to the user by the FCC to operate this equipment. VCCI Notice この装置は、クラス...
  • Page 43 QuCPE-701x User Guide BSMI Notice 警告使用者：這是甲類的資訊產品，在居住的環境中使用時，可能會造成射頻干擾，在 這種情況下，使用者會被要求採取某些適當的對策。 SJ/T 11364-2006 本产品符合中国 RoHS 标准。以下表格标示此产品中某有毒物质的含量符合中国 RoHS 标准规定的限量要求。 本产品上会附有”环境友好使用期限”的标签，此期限是估算这些物质”不会有泄漏或突变”的年限。本产品 可能包含有较短的环境友好使用期限的可替换元件，像是电池或灯管，这些元件将会单独标示出来。 部件名称 有毒有害物质或元素 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 (Pb) (Hg) (Cd) (CR(VI)) (PBB) (PBDE) 壳体 显示 印刷电路板 金属螺帽 电缆组装 风扇组装 电力供应组装 0 电池 O: 表示该有毒有害物质在该部件所有物质材料中的含量均在 SJ/T11363-2006 标准规定的限量要求以下。 X: 表示该有毒有害物质至少在该部件的某一均质材料中的含量超出...
