Read the following safety cautions for your safety.

Please read the following safety matters for your safety. This User's Manual describes circumstances that may

inflict injury onto drivers and others with the following notations (Warning, Caution, Notice, Information).

Notations used within this User's Manual

Safety

Warnings

Failure to observe the safety instructions within this category could result in serious injury or death.

Safety

Cautions

Failure to observe the safety instructions within this category could result in accident related injuries or damage to the vehicle.

WARNING

• Possible Serious Injury or

Death

• Failure to observe safety

instructions in the 'Warning"

category could result in

serious injury or death.

CAUTION

• Possible Moderate or Minor

Injury

• Failure to observe safety

instructions in the "Caution"

category can result in

moderate or minor injury.

Information

• Additional information tips

and instructions are indicated

by this symbol (international

symbol for information).

NOTICE

• Possible vehicle damage

Failure to observe instructions

in the "Notice" category

could result in damage

to the vehicle.

Table of Contents

Need help?

Do you have a question about the AM943DMAN and is the answer not in the manual?

Questions and answers

Summary of Contents for Hyundai Mobis AM943DMAN

Page 1 Read the following safety cautions for your safety. Please read the following safety matters for your safety. This User's Manual describes circumstances that may inflict injury onto drivers and others with the following notations (Warning, Caution, Notice, Information). Notations used within this User's Manual Safety Warnings Failure to observe the safety instructions within this category could result in serious injury or death.
Page 2: Before Use
Before Use Thank you for purchasing this Audio System. ® iPod ® This user's manual explains how to use the Audio System. iPod is a registered trademark of Apple Inc. Before using the product, read the contents of this user's manual carefully and use this product safely.
Page 3 시작하기 전에 Basic Thank you for purchasing this Audio System. ® iPod ® This user's manual explains how to use the Audio System. iPod is a registered trademark of Apple Inc.  Warnings and Cautions Before using the product, read the contents of this user's manual carefully and use this product safely.
Page 4: Warnings And Cautions
1 Basic Warnings and Cautions Safety Cautions Safety Warnings Operating the device while driving could lead to accidents due to a lack of attention to external surroundings. First park the vehicle before operating the device. Do not stare at the screen while driving. Staring at the screen for prolonged periods of time could lead to traffic accidents.
Page 5: Component Names And Functions
1 Basic Component Names and Functions Name Description EJECT Press to insert or eject disc Head Unit DISC-IN LED LED that indicates whether a disc is inserted DISP Turns the monitor display on/off RESET Forced system termination and system restart •...
Page 6: Steering Remote Controller
1 Basic Name Description Steering Remote Controller • Each time this key is pressed, the mode is changed in order of FM1→ FM2→ FMA→ AM→ AMA→ USB or iPod→ AUX My Music →BT Audio [MODE • If the media is not connected or a disc is not inserted, corresponding modes will be disabled.
Page 7 Audio  Switching between Radio/Media Mode  Radio Mode  Audio CD Mode  MP3 CD Mode  USB Mode  iPod Mode  AUX Mode  My Music Mode  Bluetooth® Audio Mode...
Page 8: Switching To Radio Mode
2 Audio Switching between Radio/Media Mode Switching to Radio Mode Switching to Media Mode Pressing the [MEDIA] key will change the Pressing the [RADIO] key will change the operating mode in order of CD  USB(iPod) operating mode in order of FM1 → FM2 → ...
Page 9: Radio Mode
2 Audio Radio Mode Basic Mode Screen Name Description RDS_01 Mode Display Displays currently operating mode Frequency current frequency Preset Displays current preset number [1] ~ [6] Preset Displays saved presets Display Automatically saves frequencies with superior Autostore reception to Preset buttons RDS Menu Displays the RDS Menu 12:05...
Page 10 2 Audio Using Radio Mode Searching Radio Frequencies Using Seek Selecting /Saving Presets Auto Store Press the [1]~[6] buttons to play the Press the [SEEK(<)],[TRACK(>)] keys to Press the [Autostore] button to desired preset. play the previous/next frequency. automatically save receivable frequencies to Preset buttons.
Page 11 2 Audio Scan RDS Menu Press the [RDS Menu] button to set the Press and hold the [TA/SCAN] key (over AF (Alternative Frequency), Region and 0.8 seconds) to preview frequencies with News features. superior reception for 5 seconds each. Information •...
Page 12 2 Audio Program Type TA (Traffic Announcement) (Icon) Press the [PTY/FOLDER] key to search Press the [TA/SCAN] key to turn the TA for the desired Program type. (Traffic Announcement) feature On/Off. RDS_05 RDS_04 Turn the [TUNE/FILE] knob left/right to search for the desired program type. Once you find the desired program type, press the [TUNE/FILE] knob.
Page 13: Audio Cd Mode
2 Audio Audio CD Mode Precautions upon handling discs • This device has been manufactured to be compatible with • The use of CD-R/CD-RW discs attached with labels may software bearing the following logo marks. result in disc slot jams or difficulties in disc removal. Such discs may also result in noise while playing.
Page 14: Mp3 File Information
2 Audio MP3 File Information 2. Sampling Frequencies (Hz) • Supported Audio Formats ※ Using the scroll feature allows you to see the ISO 9660 Level 1 MPEG1 MPEG2 MPEG2.5 File entire name of files with names that are too long 44100 22050 11025...
Page 15 2 Audio • Compatibility by Disc Type 3. When naming files with MP3/WMA file extensions, write 1. Playing MIXED CDs: First plays the audio CD, then plays the using only Korean and English. (Languages other than compressed file(s). Korean and English are not supported and are displayed as 2.
Page 16: Basic Mode Screen
2 Audio Basic Mode Screen Name Description Mode Displays currently operating mode Operation From Repeat/Shuffle/Scan, displays the State currently operating function Track Displays information about the current track Information EU_CD_01 Play State Displays the play/pause state Displays the current play time and total play Play Time time Shows detailed information about the current...
Page 17 2 Audio Using Audio CD Mode Playing/Pausing CD Tracks Changing Tracks Selecting from the List Press the [(∨)SEEK], [TRACK(∧)] keys to Once an audio CD is inserted, the mode Turn the [TUNE/FILE] knob left/right to move to the previous or next track. will automatically start and begin playing.
Page 18 2 Audio Shuffle List Audio CD Mode Menu Within this mode, you will have access to Press the [Shuffle] button to play tracks in Press the [List] button to display the track the Info, Shuffle, Repeat and List features. random order. Press the button again to list screen.
Page 19 2 Audio MP3 CD Mode Basic Mode Screen Name Description Mode Displays currently operating mode EU_MP3_CD_01 Operation From Repeat/Shuffle/Scan, displays the currently operating function. State File Index Displays the current file number File Info Displays information about the current file Play State Displays the play/pause state Play Time...
Page 20 2 Audio Using MP3 CD Mode Scan Information • Pressing the [(∨)SEEK] key after the file Playing/Pausing MP3 Files has been playing for 3 seconds will start Press and hold the [TA/SCAN] key (over the current file from the beginning. 0.8 seconds) to play the first 10 seconds Once an MP3 disc is inserted the mode •...
Page 21 2 Audio MP3 CD Mode Menu Repeat Information Within this mode, you will have access to • When the ‘Folder File’ option is set as the Info, Shuffle, Repeat, Copy and List Press the [Repeat] button to repeat the the default display within Display setup, features.
Page 22 2 Audio List Press the [List] button to display the file list screen. EU_MP3_CD_0 Turn the [TUNE/FILE] knob left/right to search for files. Once the desired file is displayed, press the knob to select and play.
Page 23: Usb Mode
2 Audio USB Mode Before playing a USB MP3 • Do not use the USB I/F to charge • Some USB devices may not be • Connect the USB device after turning on supported due to compatibility issues. batteries or USB accessories that the engine.
Page 24 2 Audio • The device may not support normal operation when using formats such as HDD Type, CF, or SD Memory. • The device will not support files locked by DRM (Digital Rights Management.) • USB memory sticks used by connecting an Adaptor (SD Type or CF Type) may not be properly recognized.
Page 25 2 Audio Basic Mode Screen Name Description Mode Displays currently operating mode Operation From Repeat/Shuffle/Scan, displays the currently operating function. Status File Index Displays the current file number File Info Displays information about the current file EU_USB_01 Play State Displays the play/pause state Play Time Displays the current play time Info...
Page 26: Using Usb Mode
2 Audio Using USB Mode Rewinding / Fast-forwarding Files Changing Files Playing/Pausing USB Files Press the [(∨)SEEK], [TRACK(∧)] keys to While playing, press and hold the move to the previous or next file. [(∨)SEEK], [TRACK(∧)] keys (over 0.8 Once a USB is connected, the mode will seconds) to rewind or fast-forward the automatically start and begin playing a current file.
Page 27 2 Audio USB Mode Menu Information Repeat Within this mode, you will have access to • When the ‘Folder File’ option is set as the Info, Shuffle, Repeat, Copy and List the default display within Display setup, features. Press the [Repeat] button to repeat the the album/artist/file information are current file or folder.
Page 28 2 Audio List Press the [List] button to display the file list screen. EU_USB_02 Turn the [TUNE/FILE] knob left/right to search for files. Once the desired file is displayed, press the knob to select and play.
Page 29: Ipod Mode
2 Audio iPod Mode Using iPod Devices (iPod is a registered trademark of Apple Inc.) • In order to play the iPod by operating the • Skipping or improper operation may occur keys, you must use the dedicated iPod cable depending on the characteristics of your •...
Page 30 2 Audio Basic Mode Screen Name Description Mode Displays currently operating mode Operation From Repeat/Shuffle, displays the currently iPod 12:05 State operating function 1/10000 Song Index Displays the current song/total number of songs  Album Name Song Info Displays information about the current song ...
Page 31 2 Audio Using iPod Mode Playing/Pausing iPod Songs Changing Songs Searching Categories Press the [(∨)SEEK], [TRACK(∧)] keys to Once an iPod is connected, the mode will Turn the [TUNE/FILE] knob left/right to move to the previous or next song. automatically start and begin playing an search for the desired category.
Page 32 2 Audio iPod Mode Menu Repeat Category Menu Within this mode, you will have access to Within the iPod Category menu, you will Press the [Repeat] button to repeat the the Shuffle, Repeat and List features. have access to the [], [Home], and [] current song.
Page 33: Using Aux Mode
2 Audio AUX Mode Using AUX Mode Connecting an External Device Caution • Connecting a connector jack to the Press the [MEDIA] key ▶ Select [AUX] AUX terminal without an external device will convert the system to AUX mode, but only output noise. When an external device is not being used, also remove the connector jack.
Page 34: My Music Mode
2 Audio My Music Mode Basic Mode Screen Name Description Mode Displays currently operating mode Operation From Repeat/Shuffle/Scan, displays the currently State operating function. File Index Displays the current file/total number of files File Info Displays information about the current file EU_My_01 Play State Displays the play/pause state...
Page 35 2 Audio Using My Music Mode Changing Files Playing/Pausing My Music Files Rewinding / Fast-forwarding Files Press the [(∨)SEEK], [TRACK(∧)] keys to While playing, press and hold the move to the previous or next file. [(∨)SEEK], [TRACK(∧)] keys (over 0.8 seconds) to rewind or fast-forward the EU_My_05 current file.
Page 36 2 Audio My Music Mode Menu List Shuffle Within this mode, you will have access to the Info, Shuffle, Repeat, Delete and List Press the [Shuffle] button to play files in Press the [List] button to display the file features. random order.
Page 37 2 Audio List Menu After selecting the files you want to delete, From the List screen, it is possible to press the [Delete] button to delete the delete files you previously saved into My selected files. Music. Information •If there is memory available, up to My_04 6,000 files can be saved.
Page 38: Bluetooth® Audio Mode
2 Audio Bluetooth® Audio Mode About Using Bluetooth® Audio Bluetooth® Audio Mode can be used only when a Bluetooth® phone has been connected. (However, A2DP must be connected). While Bluetooth® Audio is playing, if the Bluetooth® phone is connected, then the music will also stop. Bluetooth®...
Page 39 2 Audio Using Bluetooth® Audio Mode Information Setting Connection • If the Bluetooth® audio is not operating If a Bluetooth® device has not been properly, check whether the feature is Playing/Pausing Bluetooth® Audio connected, press the [SETUP] key turned off at [SETUP] ▶ [Phone] ▶ ▶[Phone] button to display the [Audio streaming].
Page 40 Bluetooth®  About Using Bluetooth®  Pairing a Bluetooth® Device  Connecting Bluetooth®  Using Bluetooth®...
Page 41: Using Bluetooth® Handsfree
3 Bluetooth® About Using Bluetooth® Using Bluetooth® Handsfree Precautions for Safe Driving Bluetooth® Handsfree is a feature that enables drivers What is Bluetooth®? to practice safe driving. Connecting the head unit with a Bluetooth® phone allows the user to conveniently make Bluetooth®...
Page 42 3 Bluetooth® Cautions upon Connecting Bluetooth® The Handsfree call volume and quality may differ depending on the mobile phone. Phones Before connecting the head unit with the mobile phone, check to see that the mobile phone supports Bluetooth® features. • Bluetooth® features supported within the vehicle are as follows.
Page 43: Pairing A Bluetooth® Device
3 Bluetooth® Pairing a Bluetooth® Device Pairing [PHONE] Key / [] Key on Name Description the Steering Remote Controller Name of device as shown 1. Device when searching from your When No Devices have been Paired Bluetooth® device What is Bluetooth® Pairing? Passkey used to pair the 2.
Page 44 3 Bluetooth® Information Pairing through [PHONE] Setup Information • The waiting period during phone pairing • If Bluetooth® devices are paired but Press the [SETUP] key ▶ Select [Phone] will last for one minute. The pairing none are currently connected, pressing ▶...
Page 45: Connecting Bluetooth
3 Bluetooth® Press the [SETUP] key ▶ Select [Phone] Connecting Bluetooth® ▶ Select [Paired Phone List] 12:05 Connecting a Device Setup 12:05 Press the [SETUP] key ▶ Select [Phone] 폰>등록 폰 목록 ▶Select [Paired Phone List] 트랙 01 ▶ Phone name 1 ▲...
Page 46: Disconnecting A Device
3 Bluetooth® Disconnecting a Device Deleting a Device Information • When deleting the currently connected Press the [SETUP] key ▶ Select [Phone] Press the [SETUP] key ▶ Select [Phone] device, the device will automatically be ▶Select [Paired Phone List] ▶Select [Paired Phone List] disconnected to proceed with the deleting process.
Page 47: Using Bluetooth
3 Bluetooth® Information Calling by Dialing a Number Using Bluetooth® • If you press the [Call History] button but Press the [PHONE] key ▶ Select [Dial there is no call history data, a prompt is Phone Menu Screen Number] displayed which asks whether to download call history data.
Page 48: Answering Calls
3 Bluetooth® Answering Calls During a Handsfree Call Answering a Call Information • When the incoming call pop-up is Answering a call with a Bluetooth® device displayed, most AV and SETUP mode Phone 12:05 connected will display the following features will not operate. Only the call screen.
Page 49: Call History
3 Bluetooth® Information Call History Contacts • The call history list will display up to 30 Press the [PHONE] key ▶ Select [Contacts] Press the [PHONE] key ▶ Select [Call outgoing, incoming, and missed calls. • Upon downloading call histories, History] previously saved histories are deleted.
Page 50 3 Bluetooth® Information • Up to 1,000 contacts can be copied into car contacts. • Upon downloading contacts, previously saved contacts will be deleted. • Downloading is not possible if the contacts download feature is turned off within the Bluetooth® device. Also, some devices may require device authorization upon attempting to download.
Page 51 Voice Recognition  Before Using Voice Recognition  Using Voice Recognition  Command List...
Page 52: Voice Recognition
4 Voice Recognition Before Using Voice Recognition Phone related voice commands can be used only when a When using the voice recognition feature, only commands Bluetooth® device is connected. listed within the user's manual are supported. When making calls by stating a name, the corresponding Be aware that during the operation of the voice recognition contact must be downloaded and stored within the audio system, pressing any key other than the [VR] key or...
Page 53: Using Voice Recognition
4 Voice Recognition Information Using Voice Recognition Re-starting Voice Recognition • If voice recognition is in [Expert Mode], then the system will only say a “Beep~” Starting Voice Recognition While system waits for a command ▶ • To change the Normal Mode/Expert Shortly press the [VR] key on the steering Mode setting, go to [SETUP] ▶...
Page 54: Ending Voice Recognition
4 Voice Recognition Ending Voice Recognition Illustration on Using Voice Recognition While Voice Recognition is operating ▶ Starting Voice Recognition Ending Voice Recognition Press and hold the [VR] key on the steering remote controller (over 0.8 seconds) Please say a command DING~ Information Please say a command...
Page 55: Voice Command List
4 Voice Recognition Voice Command List •Common Commands: These are commands that can be used in all situation. (However, some commands may not be supported in special circumstances.) Command Function Command Function ∙ When currently listening to the FM radio, More Help Provides guidance on commands that can maintains the current state.
Page 56 4 Voice Recognition Command Function Command Function Media Moves to the most recently played media AUX (Auxiliary) Plays the connected external device screen. Bluetooth® Plays the music saved in connected Bluetooth® Play Track 1~30 If a music CD has been inserted, plays the Audio Wireless Technology device.
Page 57 4 Voice Recognition · FM/AM radio commands: Commands that can be used · Audio CD commands: Commands that can be used while listening to FM, AM radio. whiled listening to Audio CD. Command Function Command Function Preset 1~6 Plays the broadcast saved in Preset 1~6. Region off Disable Region feature Auto Store...
Page 58 4 Voice Recognition ·MP3 CD / USB commands : Commands that can be iPod Commands: Commands that can be use while used while listening to music files saved in CD and USB playing iPod Command Function Command Function Random Randomly plays the files within the current All Random Randomly plays all saved songs.
Page 59 4 Voice Recognition ·Bluetooth® Wireless Technology Audio Commands: ·My Music Commands: Commands that can be used Commands that can be used while playing Phone Music. while playing My Music Command Function Command Function Random Randomly plays all saved files. Play Plays the currently paused song.
Page 60 Setup  Setup  Using Setup...
Page 61 5 Setup Setup Basic Mode Screen Name Description Display Sets display related settings Sound Sets sound related settings Clock Sets clock/date related settings /Day Phone Sets phone related settings EU_Setup System Sets system related settings...
Page 62: Using Setup
5 Setup Display Settings Using Setup Pop-up Mode Starting Mode Press the [SETUP] key ▶ Select [Display] Adjusting the Brightness ▶ Select [Pop-up Mode] Press the [SETUP] key to display the Press the [SETUP] key ▶ Select [Display] Setup screen. ▶...
Page 63 5 Setup Text Scroll MP3 Information Display Press the [SETUP] key ▶ Select [Display] Press the [SETUP] key ▶ Select [Display] ▶ Select [Scroll text] ▶ Select [Song Info] EU_Setup_0 EU_Setup_0 This feature is used to change the This feature is used to scroll text information displayed within USB and displayed on the screen when it is too MP3 CD modes.
Page 64: Sound Settings
5 Setup Sound Settings SDVC (Speed Dependent Volume Control) Virtual Sound Press the [SETUP] key ▶ Select [Sound] Press the [SETUP] key ▶ Select [Sound] Sound Settings ▶ Select [Speed Dependent Vol] ▶ Select [Virtual Sound] Press the [SETUP] key ▶ Select [Sound] EU_Setup_0 EU_Setup_0 ▶...
Page 65 5 Setup Clock/Date Setting Voice Recognition Setting Calendar Setting Clock Setting Press the [SETUP] key ▶ Select [Sound] Press the [SETUP] key ▶ Select Press the [SETUP] key ▶ Select [Clock/Day] ▶ Select [Volume Dialog] [Clock/Day] ▶ Select [Clock Settings] ▶...
Page 66 5 Setup Clock/Date Setting Time Format Clock Display Automatic RDS Time Press the [SETUP] key ▶ Select [Clock/Day] ▶ Select [Automatic RDS Press the [SETUP] key ▶ Select Press the [SETUP] key ▶ Select Time] [Clock/Day] ▶ Select [Clock Display [Clock/Day] ▶Select [Time Format] (Power off)] EU_Setup_Clock_0...
Page 67: Bluetooth Setting
5 Setup Bluetooth® Setting Viewing Paired Phone List Downloading Contacts Before Downloading Contacts Press the [SETUP] key ▶ Select [Phone] ▶ Select [Paired Phone List] • Only contacts within connected phones can Pairing a New Device be downloaded. Also check to see that your mobile phone supports the download feature.
Page 68 5 Setup Setup 12:05 Auto Download (Contacts) Audio Streaming [SETUP] 키를 누른 후 ▶ [화면] 선택 ▶ 폰>마이크 음량 설정 [밝기조정] 선택 Press the [SETUP] key ▶ Select [Phone] Press the [SETUP] key ▶ Select [Phone] ▶ Select [Audio Streaming] ▶...
Page 69: System Setting
5 Setup System Setting Language Voice Recognition Mode Setting Memory Information Press the [SETUP] key ▶ Select [System] Press the [SETUP] key ▶ Select [System] ▶ Select [Voice Recognition System] ▶ Select [Language] [Press the [SETUP] key ▶ Select [System] ▶ Select [Memory Information] Setup_15 EU_Setup_1 EU_Setup_Lang...
Page 70 MAP DATABASE HOTLINE M & SOFT AMERICA MAP CENTER TEL : 888-757-0010 WEBSITE : www.mapnsoft.com This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
