SHARP CORPORATION
SERVICE MANUAL
MODEL
SMC1585BS
In the interest of user-safety the oven should be restored to its original
condition and only parts identical to those speci ed should be used.
WARNING TO SERVICE PERSONNEL: Microwave ovens contain
circuitry capable of producing very high voltage and current,
contact with following parts may result in a severe, possibly fatal,
electrical shock. (High Voltage Capacitor, High Voltage Power
Transformer, Magnetron, High Voltage Recti er Assembly, High
Voltage Harness etc..)
TABLE OF CONTENTS
This document has been published to be used for after
sales service only.
The contents are subject to change without notice.
S5608SMC1585B
CONVECTION
MICROWAVE OVEN
SMC1585BS
SMC1585BB
SMC1585BW
SMC1585BS
Page
Advertisement
Table of Contents
Related Manuals for Sharp SMC1585BS
Summary of Contents for Sharp SMC1585BS
-
Page 1: Table Of Contents
SMC1585BS SERVICE MANUAL S5608SMC1585B CONVECTION MICROWAVE OVEN SMC1585BS SMC1585BB MODEL SMC1585BW SMC1585BS In the interest of user-safety the oven should be restored to its original condition and only parts identical to those speci ed should be used. WARNING TO SERVICE PERSONNEL: Microwave ovens contain... -
Page 2: Precautions To Be Observed Before And During Service To Avoid Possible Exposure To Excessive Microwave Energy
Before servicing an operative unit, perform a microwave emission check as per the Microwave Measurement Procedure outlined in this service manual. If microwave emissions level is in excess of the speci ed limit, contact SHARP ELECTRONICS CORPORATION immediately @1-800-237-4277. If the unit operates with the door open, service person should 1) tell the user not to operate the oven and 2) contact SHARP ELECTRONICS CORPORATION and Food and Drug Administration's Center for Devices and Radiological Health immediately. -
Page 3: Warning To Service Personnel
SMC1585BS WARNING TO SERVICE PERSONNEL Microwave ovens contain circuitry capable of pro- ducing very high voltage and current, contact with following parts may result in a severe, possibly fatal, electrical shock. (Example) High Voltage Capacitor, High Voltage Power Trans- former, Magnetron, High Voltage Recti er Assem- bly, High Voltage Harness etc.. - Page 4 SMC1585BS MICROWAVE MEASUREMENT PROCEDURE (CANADA) After adjustment of the door switches are completed individually or collectively, switch test and microwave leakage test must be performed with survey instrument and test result must be con rmed to meet the requirement of the performance standard for microwave ovens as undermentioned.
-
Page 5: Microwave Measurement Procedure
SMC1585BS MICROWAVE MEASUREMENT PROCEDURE A. Requirements: 1) Microwave leakage limit (Power density limit): The power density of microwave radiation emitted by a microwave oven should not exceed 1mW/cm at any point 5cm or more from the external surface of the oven, measured prior to acquisition by a... -
Page 6: Foreword And Warning
SMC1585BB SMC1585BW FOREWORD OPERATION This Manual has been prepared to provide Sharp Electronics Corp. Service Personnel with Operation and Service Information for the SHARP CONVECTION MICROWAVE OVEN , SMC1585B# TROUBLESHOOTING GUIDE It is recommended that service personnel carefully study the entire text of... -
Page 7: Product Specifications
SMC1585BS SPECIFICATION ITEM DESCRIPTION Power Requirements 120 Volts USA / 117 Volts Canadian 13.0 Amperes (Microwave) / 13.0 Amperes (Convection) 60 Hertz / Single phase, 3 wire grounded Power Output 900 watts (IEC 705 Test Procedure) Operating frequency of 2450MHz... - Page 8 SMC1585BS Electrical Requirements The electrical requirements are a 115 -120 volt 60 Hz, AC only, Grounded 3-Pronged Plug Receptacle Box 15 or 20 amp. fused electrical supply. It is recommended that a separate circuit serving only this appliance be provided. When installing this appli- ance, observe all applicable codes and ordinances.
-
Page 9: Operation
(Figure O-1). switch contacts rst open, and then the contacts of the primary interlock relay and the secondary interlock switch 1. The display will show "SHARP SIMPLY THE BEST PRESS close. CLEAR AND PRESS CLOCK". - Page 10 SMC1585BS 4. When the oven temperature reaches the selected preheat 6-2. The heating element operates through the heater relay temperature, the following operations occur: (RY3) contacts and the power transformer operates 4-1 The heater relay is de-energized by the control unit through the primary interlock relay (RY2) contacts.
- Page 11 SMC1585BS FIRE SENSING FEATURE (MICROWAVE MODE) Cooking Sequence. 1. Touch SENSOR COOK pad. This model incorporates a sensing feature which will stop the NOTE: The oven should not be operated on SENSOR oven's operation if there is a re in the oven cavity during COOK immediately after plugging in the unit.
- Page 12 SMC1585BS SCHEMATIC DIAGRAM NOTE: CONDITION OF OVEN 1. DOOR CLOSED. 2. CLOCK APPEARS ON DISPLAY. SW unit (15Vdc) #3(L) #1(+) #1(N) MAGNETRON OVEN #2(-) CONV. NOISE FILTER THERMAL THERMAL THERMAL CUT-OUT CUT-OUT CUT-OUT N.O. (RY1) COM. (RY1) POWER TRANSFORMER FUSE VRS1 COM.
- Page 13 SMC1585BS SCHEMATIC 1. DOOR CLOSED. 2. MIX COOKING PAD TOUCHED. 3. COOKING TIME PROGRAMMED. 4. “START” PAD TOUCHED. RY2 AND RY3 WILL ALTERNATELY CLOSE. DURING COOK CYCLE. MAGNETRON CONV. THERMAL TEMPERATURE NOISE FILTER CUT-OUT FUSE FUSE COM. POWER (RY1) TRANSFORMER N.O.
- Page 14 SMC1585BS activating both interlock switches. The primary interlock system Under normal operation, the temperature fuse remains closed. consists of the door sensing switch and primary interlock relay However, when abnormally high temperatures are reached located on the control circuit board.
-
Page 15: Troubleshooting Guide
SMC1585BS is channelled through the cavity to remove steam and vapors 3-3. The damper is held in the closed position during the given o from the heating foods. It is then exhausted at the top of convection cooking operation. the oven cavity into a condensation compartment. - Page 16 SMC1585BS (SENSOR CONDITION OFF CONDITION COOKING CONDITION (MICROWAVE) (CONVECTION) COOKING) POSSIBLE CAUSE DEFECTIVE PARTS MAGNETRON POWER TRANSFORMER H.V. RECTIFIER ASSEMBLY HIGH VOLTAGE CAPACITOR SECONDARY INTERLOCK SWITCH PRIMARY INTERLOCK SYSTEM MONITOR SWITCH MONITOR FUSE MAGNETRON TEMPERATURE FUSE CONV. THERMAL CUT-OUT CONVECTION HEATER...
-
Page 17: Test Procedure
SMC1585BS TEST PROCEDURES PROCEDURE COMPONENT TEST LETTER MAGNETRON ASSEMBLY TEST 1. Disconnect the power supply cord, and then remove outer case. 2. Open the door and block it open. 3. Discharge high voltage capacitor. 4. To test for an open lament, isolate the magnetron from the high voltage circuit. A continuity check across the magnetron lament leads should indicate less than 1 ohm. - Page 18 SMC1585BS TEST PROCEDURES PROCEDURE COMPONENT TEST LETTER HIGH VOLTAGE RECTIFIER TEST 1. Disconnect the power supply cord, and then remove outer case. 2. Open the door and block it open. 3. Discharge high voltage capacitor. 4. Isolate the recti er from the circuit. Using the highest ohm scale of the meter, read the resistance across the terminals and observe, reverse the leads to the recti er terminals and observe meter reading.
- Page 19 SMC1585BS TEST PROCEDURES PROCEDURE COMPONENT TEST LETTER PRIMARY INTERLOCK RELAY (RY2) 1. Disconnect the power supply cord, and then remove outer case. 2. Open the door and block it open. 3. Discharge high voltage capacitor. 4. Disconnect two (2) wire leads from the male tab terminals of the Primary Interlock Relay (RY2). Check the state of the relay contacts using a ohmmeter.
- Page 20 SMC1585BS TEST PROCEDURES PROCEDURE COMPONENT TEST LETTER 4. A continuity check across the temperature fuse terminals should indicate a closed circuit unless the temperature of the magnetron reaches approximately 302˚F(150˚C). An open temperature fuse indicates overheating of the magnetron. Check for restricted air ow to the magnetron, especially the cooling duct and cooling fan.
- Page 21 SMC1585BS TEST PROCEDURES PROCEDURE COMPONENT TEST LETTER 8. Reconnect the power supply cord after the outer case is installed. 9. Run the oven and check all functions. DAMPER MOTOR TEST When the power cord is plugged into the wall receptacle and 120 volts A.C. is supplied to the damper motor, the motor operates until the damper is opened and the damper switch closes.
- Page 22 SMC1585BS TEST PROCEDURES PROCEDURE COMPONENT TEST LETTER NOISE FILTER TEST 1. Disconnect the power supply cord, and then remove outer case. 2. Open the door and block it open. 3. Discharge high voltage capacitor. 4. Disconnect the lead wires from the terminal the noise lter. Using an...
- Page 23 SMC1585BS TEST PROCEDURES PROCEDURE COMPONENT TEST LETTER a) When touching the pads, a certain group of pads do not produce a signal. b) When touching the pads, no pads produce a signal. 2-2 In connection with indicators a) At a certain digit, all or some segments do not light up.
- Page 24 SMC1585BS TEST PROCEDURES PROCEDURE COMPONENT TEST LETTER Shut-o , Cook and Heater Relays Test These relays are operated by D.C. voltage Check voltage at the relay coil with a D.C. voltmeter during the microwave cooking operation or convection cooking condition.
- Page 25 SMC1585BS TEST PROCEDURES PROCEDURE COMPONENT TEST LETTER 6) Reconnect all leads removed from components during testing. 7) Re-install the outer case (cabinet). 8) Reconnect the power supply cord after the outer case is installed. 9) Run the oven and check all functions.
- Page 26 SMC1585BS TEST PROCEDURES PROCEDURE COMPONENT TEST LETTER (3) Close the door. (4) Touch SENSOR COOK pad and then touch the number pad 1. And touch Start pad. Now, the oven is in the sensor cooking condition and "BAKED POTATO" will appear in the display.
-
Page 27: Touch Control Panel
SMC1585BS TEST PROCEDURES PROCEDURE COMPONENT TEST LETTER (18) Carry out "Water load cooking test" again and ensure that the oven works properly. Plunger Ω ± R1, R2 : 1% 1/2W Ω ± R3 : 4.3k 5% 1/4W Ω ± R4 :... - Page 28 SMC1585BS DESCRIPTION OF LSI LSI(IZA797DR): The I/O signals of the LSI(IZA797DR) are detailed in the following table. Connected to GND. Anode (segment) of Fluorescent Display light-up voltage: -30V. Vp voltage of power source circuit input. AVSS Power source voltage: -5V.
- Page 29 SMC1585BS Magnetron high-voltage circuit driving signal. To turn on and o the cook relay(RY2). In P-90 (approx. 90% power) 30 sec. 2 sec. P-HI operation, the signals holds "L" level P-80 (approx. 80% power) 26 sec. 6 sec. during microwave cooking and "H" level P-70 (approx.
- Page 30 SMC1585BS Signal coming from touch key. When any one of G-1 line keys on key matrix is touched, a corresponding signal from P10 - P17 will be input into P27. When no key is touched, the signal is held at "L" level.
- Page 31 SMC1585BS Segment data signal. Signal similar to P23. Key strobe signal. Signal applied to touch-key section. A pulse signal is input to P24-P27 terminal while one of G-5 line keys on key matrix is touched. 49-53 P07-P03 Segment data signal.
- Page 32 SMC1585BS TOUCH CONTROL PANEL SERVICING 1. Precautions for Handling Electronic Components 5) Re-connect the power supply cord after the outer case is This unit uses CMOS LSI in the integral part of the circuits. installed. When handling these parts, the following precautions should 6) Run the oven and check all functions.
- Page 33 SMC1585BS PRECAUTIONS FOR USING LEAD-FREE SOLDER 1. Employing lead-free solder The "Main PWB" of this model employs lead-free solder. This is indicated by the "LF" symbol printed on the PWB and in the service manual. The su x letter indicates the alloy type of the solder.
-
Page 34: Component Replacement And Adjustment Procedure
1. Door does not close rmly. 2. Door hinge, support or latch hook is damaged. WARNING FOR WIRING To prevent an electric shock, take the following precau- 3) Sharp edge: tions. Bottom plate, Oven cavity, Waveguide ange, Chassis 1. Before wiring, support and other metallic plate. - Page 35 SMC1585BS CAUTION: 1. DISCONNECT OVEN FROM POWER SUP PLY BEFORE REMOVING OUTER CASE. 2. DISCHARGE THE HIGH VOLTAGE CAPACI- TOR BEFORE TOUCHING ANY OVEN COM- PONENTS OR WIRING. NOTE: When replacing the outer case, the 2 special Torx screws must be reinstalled in the same Special screw locations.
- Page 36 SMC1585BS POSITIVE LOCK CONNECTOR (NO-CASE TYPE) REMOVAL ® Terminal 1. Disconnect the power supply cord and then remove outer case. Positive lock® connector 2. Open the oven door and block it open. 3. Discharge high voltage capacitor. Push 4. Push the lever of positive lock connector.
- Page 37 SMC1585BS (4) screws holding rear cabinet to bottom plate and three (3) take heating element out of heating element holders. screws holding to heater unit assembly and two (2) screws 12.Heating element is free. holding steam duct to top of oven cavity. Disconnect wire NOTE: After installed the heating element completely, leads from power supply cord terminals.
-
Page 38: Pictorial Diagram
SMC1585BS to the fan duct. CAUTION: 21. Now, the fan motor is free. Do not hit the fan blade strongly when installed because the bracket may be dis gured. INSTALLATION Make sure that the fan blade rotates smooth after 1. Install the fan motor to the fan duct with the two (2) screws installation. - Page 39 SMC1585BS 5. Disconnect wire leads from each of the switches and fuse The secondary interlock switch is in the lower position and holder. the door sensing switch is in the upper position and the 6. Remove two (2) screws holding latch hook to oven ange.
- Page 40 SMC1585BS Note: The door on a microwave oven is designed to act as an electronic seal preventing the leakage of UPPER OVEN HINGE microwave energy from oven cavity during cook cycle. This function does not require that door be airtight, moisture (condensation)-tight or light-tight.
- Page 41 SMC1585BS CN101 C106 C101 C105 C202 L101 C201 C201 L201...
-
Page 42: Control Panel Circuit
SMC1585BS ＋... -
Page 43: Printed Wiring Board
R-930CS-F Figure S-3. Printed Wiring Board... -
Page 44: Parts List
SMC1585BS PARTS LIST PART LIST N ote: The parts marked "Δ" may cause undue microwave exposure. The parts marked "*" are used in voltage more than 250V. R EF. NO. PART NO. DESCRIPTION Q'TY PRICE CODE ELECTRICAL PARTS... - Page 45 SMC1585BS R EF. NO. PART NO. DESCRIPTION Q'TY PRICE CODE FANGTA166WRK0 Control panel back plate assy MLEVFA057WRW0 Open lever NSFTTA042WRE0 Open shaft XEPS730P10XS0 Screw ; control unit mtg. XCPS740P12000 Screw ; control panel bacj plate mtg. XOTS740P12RV0 Screw ; 4mm x 12 mm...
- Page 46 SMC1585BS R EF. NO. PART NO. DESCRIPTION Q'TY PRICE CODE 5- 8 MSPRTA192WRE0 Latch head spring 5- 9 LANGKA918WRW0 Thermal plate U 5-10 LANGKA919WRW0 Thermal plate R 5-11 XCPS740P08000 Screw; 4mm x 8mm 5-12 XEBS730P08000 Screw; 3mm x 8mm...
-
Page 47: Packing And Accessories
1. MODEL NUMBER 3. PART NO. 2. REF. NO. 4. DESCRIPTION Order Parts from the authrized SHARP parts Distributor for your area. Defective parts required return should be returned as indicated in the Service Policy. PACKING AND ACCESSORIES TRAY HOLDER... - Page 48 SMC1585BS OVEN AND CABINET PARTS...
- Page 49 SMC1585BS CONTROL PANEL PARTS 3-2-7 7-20 3-2-5 3-2-2 3-2-6 7-20 DOOR PARTS 3-2-4 3-2-3 5-12 5-13 5-11 5-11 5-11 5-10 5-11 MISCELLANEOUS Actual wire harness may be di erent than illustration. '06 SHARP CORP. (1S0.800E)
- Page 50 EndPage COPYRIGHT © 2006 BY SHARP CORPORATION ALL RIGHTS RESERVED. No part of this publication may be reproduced, stored in retrieval systems, or transmitted in anyform or by any means, electronic, mechanical, photocopying, re- cording, or other wise, without prior written permission...
