Maximum Weight Capacity:
Top Shelf: 135 Lbs
Middle Shelves: 50 Lbs Each
Bottom Shelves: 50 Lbs Each
M
O
D
E
L
VW60C
ASSEMBLY INSTRUCTIONS
Important! Read all warnings before starting assembly.
For technical assistance or troubleshooting please
call 1-855-998-4326 or visit www.sibrandssupport.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the VW60C and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Vidao VW60C

Summary of Contents for Vidao VW60C

  • Page 1 Maximum Weight Capacity: Top Shelf: 135 Lbs Middle Shelves: 50 Lbs Each Bottom Shelves: 50 Lbs Each VW60C ASSEMBLY INSTRUCTIONS Important! Read all warnings before starting assembly. For technical assistance or troubleshooting please call 1-855-998-4326 or visit www.sibrandssupport.com...

  • Page 2: Read This First

    • Contact a professional if you have any doubts about safe and secure TV furniture • Schoenfeld International Inc. and VIDAO assembly. are not responsible for any personal injury or product damage due to mishandling, •...
  • Page 3 TV) on the bottom shelf • When in use, this furniture must be placed on Schoenfeld International Inc. and VIDAO will a flat, level and solid surface. not be responsible for failure to assemble as directed or for the improper assembly, use or •...
  • Page 4 IMPORTANT Before you begin: Open, identify and count all parts prior to assembly. Lay out parts on a flat and non- abrasive surface. You will need the parts identified on page 5 and 6 of this instruction manual. NOTE: IT IS VERY IMPORTANT TO USE GLUE WITH DOWELS. EXCESS GLUE CAN BE WIPED OFF WITH DAMP CLOTH.
  • Page 5 Parts and Hardware List Please read completely through the instructions and verify that all listed parts and hardware are present before beginning assembly. A- Top Panel (Qty. 1) B- Bottom Panel (Qty. 1) C- Left Side Panel (Qty. 1) D- Left Partition Panel (Qty. 1) E- Right Side Panel (Qty.
  • Page 6 Parts and Hardware List Please read completely through the instructions and verify that all listed parts and hardware are present before beginning assembly. (1) Cam Lock (2) Cam Bolt (3) M8 x 30 mm Wood Dowel (Qty. 20+1 extra) (Qty. 20+1 extra) (Qty.
  • Page 7 Cam Bolt (20 used in this step) ② 1. Unpack the unit and confirm that you have all the hardware and required parts. Assemble the unit on a carpeted floor or the empty carton to avoid any scratching. 2. Securely screw the Cam Bolts (2) into the designated small holes on the Top Panel (A), Bottom Panel (B) and Side Panels (C and E) using a Phillips screwdriver.
  • Page 8 Cam Lock M8 x 30 mm Wood Dowel (3 used in this step) (2 used in this step) ① ③ 3. Attach the Bottom Back Stretcher (I) to the Bottom Panel (B) with two 30 mm Wood Dowels (3) and three Cam Locks (1).
  • Page 9 M8 x 30 mm Wood Dowel M4 x 50 mm Screw (4 used in this step) (4 used in this step) ③ ⑦ 4. Attach the Partition Panels (D and F) to the Bottom Panel (B) with four 30 mm Wood Dowels (3) and four 50 mm Screws (7) as shown.
  • Page 10 Cam Lock M8 x 30 mm Wood Dowel (6 used in this step) (6 used in this step) ① ③ 5. Attach the Left Side Panel (C) to the Bottom Panel (B) and Bottom Back Stretcher (I) with three 30 mm Wood Dowels (3) and three Cam Locks (1).
  • Page 11 Cam Lock M8 x 30 mm Wood Dowel (3 used in this step) (2 used in this step) ① ③ 7. Attach the Bottom Front Stretcher (H) to the Bottom Panel (B) with two 30 mm Wood Dowels (3) and three Cam Locks (1) as shown.
  • Page 12 M4 x 50 mm Screw (4 used in this step) ⑦ 8. Fasten the Bottom Front Stretcher (H) to the Side Panels (C and E) with four 50 mm Screws (7).
  • Page 13 M8 x 20 mm Wood Dowel M4 x 25 mm Screw (4 used in this step) (8 used in this step) ④ ⑥ 9. Attach the Bottom Front Molding (G) to the Bottom Front Stretcher (H) with four 20 mm Wood Dowels (4) and eight 25 mm Screws (6).
  • Page 14 M3.5 x 15 mm Screw Triangle Metal Plate Flat Head (8 used in this step) (2 used in this step) 10. Using the pilot holes as a guide, fasten two Triangle Metal Plates (13) at the bottom joints between Side Panels (C and E) and Bottom Front Stretcher (H) with eight 15 mm Flat Head Screws (5).
  • Page 15 Floor Leveler (2 used in this step) 11. Screw two Floor Levelers (14) into the installed Triangle Metal Plates (13).
  • Page 16 Cam Lock (8 used in this step) ① M8 x 30 mm Wood Dowel (8 used in this step) ③ 12. Attach the Top Panel (A) to the vertical panels (C, D, E and F) with eight 30 mm Wood Dowels (3) and eight Cam Locks (1).
  • Page 17 M3.5 x 15 mm Washer Head Screw (24 used in this step) ⑧ 13. Now, go back and securely tighten all the Cam Locks and the Screws. Make sure that all the parts are tight and there are no gaps between the parts. This will help keep the unit square. 14.
  • Page 18 Shelf Pin (12 used in this step) ⑩ 15. Stand the unit upright. 16. Insert the Shelf Pins (10) into the desired holes in the sides of the compartments. Make sure you place the four Shelf Pins in the same level so the shelf is not tilted. Tilt and rest the Adjustable Shelves (L and M) onto the Shelf Pins (10) with the end notches of the Shelf fit onto the Shelf Pins properly.
  • Page 19 Knob Knob Bolt (2 used in this step) (2 used in this step) 17. Attach one Knob (11) to the front side of each Door (K) with the provided Knob Bolt (12). How to adjust the European adjustable hinges on doors Shipping may cause doors to go out of alignment.
  • Page 20 18. Pick up one Door (K) and attach the extended Hinge Arms to the Hinge Bases installed on Left Side Panel (C). Loosen the bolt on the back of Hinge Base for an easy fit. Align and insert the “U” slot on Hinge Arm under the bolt head on the back of Hinge Base.
  • Page 21 Cam Lock Cover Rubber Bumper (8 used in this step) (4 used in this step) 21. Plug the Cam Lock Covers (9) onto the visible Cams Locks to conceal the Cams. 22. Peel off the Rubber Bumpers (15) from the bumper card and stick them at the outer corners of the Doors (K) where they come in contact with the Partition Panels (D and F).
  • Page 22 NOTE: You must install the strip stopper to prevent the TV from tipping when placing your flat panel television directly on the console. 23. Remove the paper backing from the Stop Rail (N), then properly align the Stop Rail with the top edge of the stopper template on the Top Panel (A).
  • Page 23 Tools required: Phillips screwdriver, Power Drill, 3/8” Drill Bit and Rubber Mallet. 25. Ask for assistance to position the assembled unit at the desired location against a wall. If necessary, adjust the installed Floor Levelers (14) at the bottom of the mantel to level the unit. Now, follow the instructions printed on the plastic bag containing the Tipping Restraint Hardware to attach the tip-over restraints to the unit and the wall.
  • Page 24 We warrant this product to you, the original purchaser at the time of purchase printed on a dated store receipt from an authorized VIDAO retailer and for a period of six-years thereafter that our furniture product and all it’s parts and components are free of defects in material and workmanship under normal use.
