QUICK SETUP GUIDE
32" 1080p
60Hz LED TV
NS-32D510NA19
INCLUDED ACCESSORIES
Remote control and two AAA batteries
TV stands
M4 screws (12 mm length) (4 pcs.)
FIND YOUR USER GUIDE ONLINE!
1 Go to www.insigniaproducts.com.
2 Use the search bar to find NS-32D510NA19
3 Select Support & Downloads.
4 Next to User Guide, select the language you want.
STOP
Do not plug your power cord in until all
other devices have been connected.
Before using your new product, please read these instructions to prevent any damage.
START HERE
1
How do I attach the stand to my TV? (not for wall mounting)
You'll need: Soft surface and Phillips screwdriver
Place your TV face-down on a cushioned, clean surface.
Align the screw holes on the TV stands with the holes on the bottom of your TV, then secure
each stand to your TV with two of the provided screws.
M4 screws (12 mm length)
FEATURES
Remote control sensor
Indicator light / Power
DIGITAL OPTICAL
VIDEO
AUDIO OUT
OUTPUT
Note: Images do not necessarily represent the exact design of your television.
MAKING CONNECTIONS
2
How do I watch TV (cable, satellite, or antenna) or connect a device, such as a DVD or Blu-ray player,
game console, or tablet?
HDMI
(BEST)
Best video quality
AV
(GOOD)
VIDEO
COAXIAL
(GOOD)
L
R
- AUDIO -
AV IN
ANT/CABLE
WALL MOUNT
How do I prepare my TV for wall mounting? (not for use with a TV stand)
You'll need: Soft surface and Phillips screwdriver
Before you mount your TV, make sure that:
• You remove the stands.
• The bracket supports the weight of your TV.
A
Carefully place your TV face-down on a cushioned, clean surface.
B
See the instructions that came with your wall mount for more information
about how to correctly mount your TV.
A
OR
B
Your TV has four VESA mounting holes on the back. If you attach a wall-mount bracket to the
back of your TV, the bracket must be securely attached, using all four holes. If you do not
use all four mounting holes, your TV may fall and cause property damage or personal injury.
See the documentation that came with your wall-mount for complete mounting instructions.
WHICH CABLES DO YOU HAVE?
Multi-purpose jacks: You can plug any device that uses HDMI into any HDMI jack.
However, certain devices must be connected to the HDMI 1 (ARC) jack. See the instructions
that came with your ARC device for more information.
L
- AUDIO -
R
AV IN
HDMI2
HDMI1(ARC)
NS-32D510NA19
VESA Mounting Pattern
VESA mount(mm): 100 x100 mm-M4, 10mm length
AUDIO/VIDEO OUT
