Operator's Manual
C510
AUTOMATIC FLOOR SCRUBBER
● Please read this Operator's Manual carefully and make sure fully
understand before using the appliance.
● Please keep this Manual for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C510 and is the answer not in the manual?

Questions and answers

Summary of Contents for Mclennan C510

  • Page 1 Operator’s Manual C510 AUTOMATIC FLOOR SCRUBBER ● Please read this Operator’s Manual carefully and make sure fully understand before using the appliance. ● Please keep this Manual for future reference.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Warranty ..........................3 Safety Instructions ......................3 Machine Set-Up ........................4 Machine Specification ......................5 Daily Operation and Maintenance ..................5 How to Install Batteries ....................5 How to Charge the Batteries ................... 6 How to Install the Squeegee ................... 6 How to Install Pad Holder and Brush ................

  • Page 3: Warranty

    Warranty C510 by MC takes pride in producing high quality, durable products. C510 by MC product carries a limited one(1) year warranty against defects in workmanship and materials from the date of purchase under normal commercial use. Warranty does not apply to defects due to direct or indirect abuse, negligence, misuse, accidents, repairs or alterations and lack of maintenance.

  • Page 4: Machine Set-Up

    Machine Set-Up 1. Adjustable handle 10. Suction hose 19,Skirt 2. Control panel 11. Adjust wheel 20, Metal belt 3. Drain out hose 12, Butterfly nut 21,Guide wheel 4. Supplementary protector 13, Adjust knob,squeegee 22,Cap for solution tank 5. Power switch 14, Squeegee body 23,Recovery tank 6.

  • Page 5: Machine Specification

    Machine Specification Automatic Scrubber C510 Brush Width 20in Squeegee Width 33.5in Solution Tank 20Gal Recovery Tank 23Gal Brush Rotation 175rpm Efficiency 27976sq.ft/h Voltage Vacuum Motor Power 0.73HP Brush Motor Power 0.73HP Traction motor 0.53HP Weight 418lbs Length x Width x Height...

  • Page 6: How To Charge The Batteries

    How to Charge the Batteries Caution: Only use a battery charger designed for the machine. Failure to do so can result in damage to the batteries. Plug the charger red plug to the machine charging plug located near the key switch. Plug the other charger plug to 220V/120V wall outlet.

  • Page 7: How To Lower/Raise The Brush/Pad

    6. Hold the handle(1), lift the metal start level(figure in the right), the machine starts to move, release the start level, the machine stops. 7. Turn the speed adjust knob to" " side, you speed up the machine, while to " "...

  • Page 8: How To Control Excess Foam In The Recovery Tank

    area. You can go forward or backward and pick up solution. How to Control Excess Foam in the Recovery Tank Watch the liquid as it accumulates in the recovery tank. If you notice excess foaming, stop the machine. Add the recommended amount of chemical defoamer in the recovery tank (23).
  • Page 9 Problem: Possible Cause: Solution is not being Vacuum motor is not running picked up Water filter is clogged Recovery tank is full Squeegee or vacuum hose is clogged, broken or disconnected Bad seal at tank cover, vacuum motor or squeegee Worn or misaligned squeegee blades.
