Shop fox W1759 Instructions

Model W1759
3.5 Gallon Parts Washer
Phone #: (360) 734-3482 • Online Tech Support: tech-support@shopfox.biz • Web: www.shopfox.biz

Introduction

This heavy-duty welded steel parts washer has a 6 gallon
work-space volume, but is designed to hold a maximum of
3.5 gallons of liquid. Do not overfill.

Specifications

• Overall Size ..........................13"D x 17"W x 9.5"H
• Tub Depth ....................................... 8.5" Deep
• Maximum Liquid Level ....... 3.5 Gallons or 4.5" Deep
• Minimum Liquid Level ..........2 Gallons or 2.5" Deep
• Nozzle Diameter ....................................3.5mm
• Pump Motor ...................... 110V, 0.7 Amp, 60 Hz
• Pump Output ....................................... 30 GPM
• Net Weight ..........................................20 lbs.

Choosing Your Cleaning Solution

Not every cleaning solution is safe to use in your parts
washer. NEVER USE GASOLINE, KEROSENE, FUELS,
STRIPPERS, OR ACIDS OF ANY KIND IN THIS PARTS
WASHER. We recommend non-flammable cleaning solu-
tions with a PH between 6-8, but due to the changing for-
mulas of cleaning solutions, and changing laws and regula-
tions we cannot name a specific solution for you. Some
solutions can be highly flammable and may damage pump
and motor seals, and others can react with what you may
be cleaning and produce harmful fumes.
If you are in doubt about any aspect of your selected
solution, contact the solution manufacturer or refer to
the Materials Safety Data Sheet (MSDS) information, which
can be found on the internet. It is your responsibility to
select a safe solution.
